Public Member Functions | Static Public Member Functions | Protected Attributes | List of all members
solidBodyMotionFunction Class Referenceabstract

Base class for defining solid-body motions. More...

Inheritance diagram for solidBodyMotionFunction:
Inheritance graph
[legend]
Collaboration diagram for solidBodyMotionFunction:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("solidBodyMotionFunction")
 Runtime type information. More...

 declareRunTimeSelectionTable (autoPtr, solidBodyMotionFunction, dictionary,(const dictionary &SBMFCoeffs, const Time &runTime),(SBMFCoeffs, runTime))

 solidBodyMotionFunction (const dictionary &SBMFCoeffs, const Time &runTime)
 Construct from the SBMFCoeffs dictionary and Time. More...

 solidBodyMotionFunction (const solidBodyMotionFunction &)=delete
 Disallow default bitwise copy construction. More...

virtual autoPtr< solidBodyMotionFunction > clone () const =0
 Construct and return a clone. More...

virtual ~solidBodyMotionFunction ()
 Destructor. More...

virtual septernion transformation () const =0
 Return the solid-body motion transformation septernion. More...

virtual bool read (const dictionary &SBMFCoeffs)=0
 Update properties from given dictionary. More...

virtual void writeData (Ostream &) const
 Write in dictionary format. More...

void operator= (const solidBodyMotionFunction &)=delete
 Disallow default bitwise assignment. More...


Static Public Member Functions

static autoPtr< solidBodyMotionFunction > New (const dictionary &SBMFCoeffs, const Time &runTime)
 Select constructed from the SBMFCoeffs dictionary and Time. More...


Protected Attributes

dictionary SBMFCoeffs_

const Time & time_


Detailed Description

Base class for defining solid-body motions.

Source files

Definition at line 59 of file solidBodyMotionFunction.H.

Constructor & Destructor Documentation

◆ solidBodyMotionFunction() [1/2]

solidBodyMotionFunction ( const dictionary &  SBMFCoeffs,
const Time &  runTime
)

Construct from the SBMFCoeffs dictionary and Time.

Definition at line 39 of file solidBodyMotionFunction.C.

◆ solidBodyMotionFunction() [2/2]

solidBodyMotionFunction ( const solidBodyMotionFunction &  )
delete

Disallow default bitwise copy construction.

◆ ~solidBodyMotionFunction()

~solidBodyMotionFunction ( )
virtual

Destructor.

Definition at line 58 of file solidBodyMotionFunction.C.

Member Function Documentation

◆ TypeName()

TypeName ( "solidBodyMotionFunction"  )

Runtime type information.

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable ( autoPtr  ,
solidBodyMotionFunction  ,
dictionary  ,
(const dictionary &SBMFCoeffs, const Time &runTime)  ,
(SBMFCoeffs, runTime)
)

◆ clone()

virtual autoPtr<solidBodyMotionFunction> clone ( ) const
pure virtual

Construct and return a clone.

Implemented in sixDoFMotion, SDA, rotatingMotion, oscillatingRotatingMotion, oscillatingLinearMotion, multiMotion, linearMotion, and axisRotationMotion.

◆ New()

Foam::autoPtr< Foam::solidBodyMotionFunction > New ( const dictionary &  SBMFCoeffs,
const Time &  runTime
)
static

Select constructed from the SBMFCoeffs dictionary and Time.

Definition at line 30 of file solidBodyMotionFunctionNew.C.

References Foam::endl(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, Foam::Info, dictionary::lookup(), and Foam::nl.

Referenced by multiSolidBodyMotionSolver::multiSolidBodyMotionSolver(), and multiMotion::read().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ transformation()

virtual septernion transformation ( ) const
pure virtual

Return the solid-body motion transformation septernion.

Implemented in sixDoFMotion, SDA, rotatingMotion, oscillatingRotatingMotion, oscillatingLinearMotion, multiMotion, linearMotion, and axisRotationMotion.

◆ read()

bool read ( const dictionary &  SBMFCoeffs)
pure virtual

Update properties from given dictionary.

Implemented in sixDoFMotion, SDA, rotatingMotion, oscillatingRotatingMotion, oscillatingLinearMotion, multiMotion, linearMotion, and axisRotationMotion.

Definition at line 64 of file solidBodyMotionFunction.C.

References dictionary::optionalSubDict(), and Foam::type().

Referenced by axisRotationMotion::read(), linearMotion::read(), multiMotion::read(), oscillatingLinearMotion::read(), oscillatingRotatingMotion::read(), rotatingMotion::read(), SDA::read(), and sixDoFMotion::read().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ writeData()

void writeData ( Ostream &  os) const
virtual

Write in dictionary format.

Definition at line 72 of file solidBodyMotionFunction.C.

◆ operator=()

void operator= ( const solidBodyMotionFunction &  )
delete

Disallow default bitwise assignment.

Member Data Documentation

◆ SBMFCoeffs_

dictionary SBMFCoeffs_
protected

Definition at line 65 of file solidBodyMotionFunction.H.

Referenced by axisRotationMotion::clone(), linearMotion::clone(), multiMotion::clone(), oscillatingLinearMotion::clone(), oscillatingRotatingMotion::clone(), rotatingMotion::clone(), SDA::clone(), and sixDoFMotion::clone().

◆ time_

const Time& time_
protected

Definition at line 66 of file solidBodyMotionFunction.H.

Referenced by axisRotationMotion::clone(), linearMotion::clone(), multiMotion::clone(), oscillatingLinearMotion::clone(), oscillatingRotatingMotion::clone(), rotatingMotion::clone(), SDA::clone(), and sixDoFMotion::clone().

The documentation for this class was generated from the following files:
