This boundary condition provides a total pressure condition for patches in a rotating frame. More...

Inheritance diagram for rotatingTotalPressureFvPatchScalarField:

Collaboration diagram for rotatingTotalPressureFvPatchScalarField:

Public Member Functions
	TypeName ("rotatingTotalPressure")
	Runtime type information. More...

	rotatingTotalPressureFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
	Construct from patch, internal field and dictionary. More...

	rotatingTotalPressureFvPatchScalarField (const rotatingTotalPressureFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fieldMapper &)
	Construct by mapping given rotatingTotalPressureFvPatchScalarField. More...

	rotatingTotalPressureFvPatchScalarField (const rotatingTotalPressureFvPatchScalarField &)=delete
	Disallow copy without setting internal field reference. More...

	rotatingTotalPressureFvPatchScalarField (const rotatingTotalPressureFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
	Copy constructor setting internal field reference. More...

virtual tmp< fvPatchScalarField >	clone (const DimensionedField< scalar, volMesh > &iF) const
	Construct and return a clone setting internal field reference. More...

virtual void	updateCoeffs ()
	Update the coefficients associated with the patch field. More...

virtual void	write (Ostream &) const
	Write. More...

Public Member Functions inherited from totalPressureFvPatchScalarField
	TypeName ("totalPressure")
	Runtime type information. More...

	totalPressureFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
	Construct from patch, internal field and dictionary. More...

	totalPressureFvPatchScalarField (const totalPressureFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fieldMapper &)
	Construct by mapping given totalPressureFvPatchScalarField. More...

	totalPressureFvPatchScalarField (const totalPressureFvPatchScalarField &)=delete
	Disallow copy without setting internal field reference. More...

	totalPressureFvPatchScalarField (const totalPressureFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
	Copy constructor setting internal field reference. More...

Public Member Functions inherited from dynamicPressureFvPatchScalarField
	TypeName ("dynamicPressure")
	Runtime type information. More...

	dynamicPressureFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
	Construct from patch, internal field and dictionary. More...

	dynamicPressureFvPatchScalarField (const dynamicPressureFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fieldMapper &)
	Construct by mapping given dynamicPressureFvPatchScalarField. More...

	dynamicPressureFvPatchScalarField (const dynamicPressureFvPatchScalarField &)=delete
	Disallow copy without setting internal field reference. More...

	dynamicPressureFvPatchScalarField (const dynamicPressureFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
	Copy constructor setting internal field reference. More...

virtual void	map (const fvPatchScalarField &, const fieldMapper &)
	Map the given fvPatchField onto this fvPatchField. More...

virtual void	reset (const fvPatchScalarField &)
	Reset the fvPatchField to the given fvPatchField. More...

Additional Inherited Members
Protected Member Functions inherited from dynamicPressureFvPatchScalarField
void	updateCoeffs (const scalarField &p0p, const scalarField &K0mKp)
	Update the coefficients associated with the patch field. More...

Protected Attributes inherited from totalPressureFvPatchScalarField
const word	UName_
	Name of the velocity field. More...

const word	phiName_
	Name of the flux field. More...

Protected Attributes inherited from dynamicPressureFvPatchScalarField
const word	rhoName_
	Name of the density field used to normalise the mass flux. More...

const word	psiName_
	Name of the compressibility field used to calculate the wave speed. More...

const scalar	gamma_
	Heat capacity ratio. More...

scalarField	p0_
	Reference pressure. More...

Detailed Description

This boundary condition provides a total pressure condition for patches in a rotating frame.

Usage

Property	Description	Required	Default value
`U`	velocity field name	no	U
`phi`	flux field name	no	phi
`rho`	density field name	no	none
`psi`	compressibility field name	no	none
`gamma`	ratio of specific heats (Cp/Cv)	yes
`p0`	static pressure reference	yes
`origin`	origin of rotation in Cartesian co-ordinates	yes
`axis`	axis of rotation	yes
`omega`	angular velocity of the frame	no

Example of the boundary condition specification:

    <patchName>
    {
        type            rotatingTotalPressure;
        U               U;
        phi             phi;
        rho             rho;
        psi             psi;
        gamma           1.4;
        p0              uniform 1e5;
        origin          (0 0 0);
        axis            (0 0 1);
        omega           100 [rpm];
    }

The omega entry is a Function1 of time, see Foam::Function1s.

See also: Foam::totalPressureFvPatchScalarField Foam::Function1s

Source files

Definition at line 137 of file rotatingTotalPressureFvPatchScalarField.H.

Constructor & Destructor Documentation

◆ rotatingTotalPressureFvPatchScalarField() [1/4]

rotatingTotalPressureFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const dictionary &	dict
	)

Construct from patch, internal field and dictionary.

Definition at line 34 of file rotatingTotalPressureFvPatchScalarField.C.

Referenced by rotatingTotalPressureFvPatchScalarField::clone().

Here is the caller graph for this function:

◆ rotatingTotalPressureFvPatchScalarField() [2/4]

rotatingTotalPressureFvPatchScalarField	(	const rotatingTotalPressureFvPatchScalarField &	psf,
		const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const fieldMapper &	mapper
	)

Construct by mapping given rotatingTotalPressureFvPatchScalarField.

onto a new patch

Definition at line 49 of file rotatingTotalPressureFvPatchScalarField.C.

◆ rotatingTotalPressureFvPatchScalarField() [3/4]

rotatingTotalPressureFvPatchScalarField ( const rotatingTotalPressureFvPatchScalarField & )

delete

Disallow copy without setting internal field reference.

◆ rotatingTotalPressureFvPatchScalarField() [4/4]

rotatingTotalPressureFvPatchScalarField	(	const rotatingTotalPressureFvPatchScalarField &	psf,
		const DimensionedField< scalar, volMesh > &	iF
	)

Copy constructor setting internal field reference.

Definition at line 65 of file rotatingTotalPressureFvPatchScalarField.C.

Member Function Documentation

◆ TypeName()

TypeName ( "rotatingTotalPressure" )

Runtime type information.

◆ clone()

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, volMesh > & iF ) const

inlinevirtual

Construct and return a clone setting internal field reference.

Reimplemented from totalPressureFvPatchScalarField.

Definition at line 193 of file rotatingTotalPressureFvPatchScalarField.H.

References rotatingTotalPressureFvPatchScalarField::rotatingTotalPressureFvPatchScalarField().

Here is the call graph for this function:

◆ updateCoeffs()

void updateCoeffs ( )

virtual

Update the coefficients associated with the patch field.

Reimplemented from totalPressureFvPatchScalarField.

Definition at line 81 of file rotatingTotalPressureFvPatchScalarField.C.

References Foam::mag(), Foam::magSqr(), Foam::neg(), dynamicPressureFvPatchScalarField::updateCoeffs(), and dimensioned< Type >::value().

Here is the call graph for this function:

◆ write()

void write ( Ostream & os ) const

virtual

Write.

Reimplemented from totalPressureFvPatchScalarField.

Definition at line 107 of file rotatingTotalPressureFvPatchScalarField.C.

References totalPressureFvPatchScalarField::write(), and Foam::writeEntry().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/finiteVolume/fields/fvPatchFields/derived/rotatingTotalPressure/rotatingTotalPressureFvPatchScalarField.H
src/finiteVolume/fields/fvPatchFields/derived/rotatingTotalPressure/rotatingTotalPressureFvPatchScalarField.C
