Base-class for thermodynamic properties based on density. More...

Inheritance diagram for rhoThermo:

[legend]

Collaboration diagram for rhoThermo:

Classes
class	implementation

Public Member Functions
virtual	~rhoThermo ()
	Destructor. More...

virtual tmp< volScalarField >	rho () const =0
	Density [kg/m^3]. More...

virtual tmp< scalarField >	rho (const label patchi) const =0
	Density for patch [kg/m^3]. More...

virtual volScalarField &	rho ()=0
	Return non-const access to the local density field [kg/m^3]. More...

Public Member Functions inherited from basicThermo
	TypeName ("basicThermo")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, basicThermo, fvMesh,(const fvMesh &mesh, const word &phaseName),(mesh, phaseName))
	Declare run-time constructor selection table. More...

virtual	~basicThermo ()
	Destructor. More...

virtual const IOdictionary &	properties () const =0
	Properties dictionary. More...

virtual IOdictionary &	properties ()=0
	Non-const access the properties dictionary. More...

virtual const fvMesh &	mesh () const =0
	Return const access to the mesh. More...

virtual const word &	phaseName () const =0
	Phase name. More...

word	phasePropertyName (const word &name) const
	Name of a property for a given phase. More...

void	validate (const string &app, const word &) const
	Check that the thermodynamics package is consistent. More...

void	validate (const string &app, const word &, const word &) const
	Check that the thermodynamics package is consistent. More...

virtual void	correct ()=0
	Update properties. More...

virtual word	thermoName () const =0
	Name of the thermo physics. More...

virtual bool	incompressible () const =0
	Return true if the equation of state is incompressible. More...

virtual bool	isochoric () const =0
	Return true if the equation of state is isochoric. More...

virtual Switch	dpdt () const =0
	Should the dpdt term be included in the enthalpy equation. More...

virtual tmp< volScalarField >	W () const =0
	Molecular weight [kg/kmol]. More...

virtual tmp< scalarField >	W (const label patchi) const =0
	Molecular weight for patch [kg/kmol]. More...

virtual const volScalarField &	T () const =0
	Temperature [K]. More...

virtual volScalarField &	T ()=0
	Temperature [K]. More...

virtual const volScalarField &	he () const =0
	Enthalpy/Internal energy [J/kg]. More...

virtual volScalarField &	he ()=0
	Enthalpy/Internal energy [J/kg]. More...

virtual const volScalarField &	Cp () const =0
	Heat capacity at constant pressure [J/kg/K]. More...

virtual const volScalarField &	Cv () const =0
	Heat capacity at constant volume [J/kg/K]. More...

virtual const volScalarField &	Cpv () const =0
	Heat capacity at constant pressure/volume [J/kg/K]. More...

virtual tmp< volScalarField >	he (const volScalarField &p, const volScalarField &T) const =0
	Enthalpy/Internal energy. More...

virtual tmp< volScalarField::Internal >	he (const volScalarField::Internal &p, const volScalarField::Internal &T) const =0
	Enthalpy/Internal energy. More...

virtual tmp< scalarField >	he (const scalarField &T, const labelList &cells) const =0
	Enthalpy/Internal energy for cell-set [J/kg]. More...

virtual tmp< scalarField >	he (const scalarField &T, const label patchi) const =0
	Enthalpy/Internal energy for patch [J/kg]. More...

virtual tmp< volScalarField::Internal >	he (const volScalarField::Internal &T, const fvSource &model, const volScalarField::Internal &source) const =0
	Enthalpy/Internal energy for source [J/kg]. More...

virtual tmp< scalarField >	he (const scalarField &T, const fvSource &model, const scalarField &source, const labelUList &cells) const =0
	Enthalpy/Internal energy for source [J/kg]. More...

virtual tmp< volScalarField >	hs () const =0
	Sensible enthalpy [J/kg]. More...

virtual tmp< volScalarField >	hs (const volScalarField &p, const volScalarField &T) const =0
	Sensible enthalpy. More...

virtual tmp< volScalarField::Internal >	hs (const volScalarField::Internal &p, const volScalarField::Internal &T) const =0
	Sensible enthalpy. More...

virtual tmp< scalarField >	hs (const scalarField &T, const labelList &cells) const =0
	Sensible enthalpy for cell-set [J/kg]. More...

virtual tmp< scalarField >	hs (const scalarField &T, const label patchi) const =0
	Sensible enthalpy for patch [J/kg]. More...

virtual tmp< volScalarField >	ha () const =0
	Absolute enthalpy [J/kg]. More...

virtual tmp< volScalarField >	ha (const volScalarField &p, const volScalarField &T) const =0
	Absolute enthalpy. More...

virtual tmp< volScalarField::Internal >	ha (const volScalarField::Internal &p, const volScalarField::Internal &T) const =0
	Absolute enthalpy. More...

virtual tmp< scalarField >	ha (const scalarField &T, const labelList &cells) const =0
	Absolute enthalpy for cell-set [J/kg]. More...

virtual tmp< scalarField >	ha (const scalarField &T, const label patchi) const =0
	Absolute enthalpy for patch [J/kg]. More...

virtual tmp< scalarField >	Cp (const scalarField &T, const label patchi) const =0
	Heat capacity at constant pressure for patch [J/kg/K]. More...

virtual tmp< scalarField >	Cv (const scalarField &T, const label patchi) const =0
	Heat capacity at constant volume for patch [J/kg/K]. More...

virtual tmp< scalarField >	Cpv (const scalarField &T, const label patchi) const =0
	Heat capacity at constant pressure/volume for patch [J/kg/K]. More...

tmp< volScalarField >	gamma () const
	Gamma = Cp/Cv []. More...

tmp< scalarField >	gamma (const scalarField &T, const label patchi) const
	Gamma = Cp/Cv for patch []. More...

virtual tmp< volScalarField >	The (const volScalarField &h, const volScalarField &p, const volScalarField &T0) const =0
	Temperature from enthalpy/internal energy. More...

virtual tmp< scalarField >	The (const scalarField &h, const scalarField &T0, const labelList &cells) const =0
	Temperature from enthalpy/internal energy for cell-set. More...

virtual tmp< scalarField >	The (const scalarField &h, const scalarField &T0, const label patchi) const =0
	Temperature from enthalpy/internal energy for patch. More...

virtual const volScalarField &	kappa () const =0
	Thermal conductivity of mixture [W/m/K]. More...

template<class FieldType >
const Foam::basicThermo &	lookupThermo (const FieldType &f)

template<class Thermo >
Foam::autoPtr< Thermo >	New (const fvMesh &mesh, const word &phaseName)

Additional Inherited Members
Static Public Member Functions inherited from basicThermo
static word	phasePropertyName (const word &name, const word &phaseName)
	Name of a property for a given phase. More...

template<class FieldType >
static const basicThermo &	lookupThermo (const FieldType &f)
	Lookup the thermo associated with the given field. More...

static wordList	splitThermoName (const word &thermoName, const int nCmpt)
	Split name of thermo package into a list of the components names. More...

static List< Pair< word > >	thermoNameComponents (const word &thermoName)
	Split name of thermo package into a list of named components names. More...

template<class Thermo >
static autoPtr< Thermo >	New (const fvMesh &, const word &phaseName=word::null)
	Generic New for each of the related thermodynamics packages. More...

static autoPtr< basicThermo >	New (const fvMesh &, const word &phaseName=word::null)
	Specialisation of the Generic New for basicThermo. More...

Protected Member Functions inherited from basicThermo
wordList	heBoundaryTypes ()
	Enthalpy/internal energy field boundary types. More...

wordList	heBoundaryBaseTypes ()
	Enthalpy/internal energy field boundary base types. More...

HashTable< word >	heSourcesTypes ()
	Enthalpy/internal energy field sources types. More...

Static Protected Member Functions inherited from basicThermo
static volScalarField &	lookupOrConstruct (const fvMesh &mesh, const char *name)
	Lookup and the named field, or construct it as MUST-READ if it is. More...

template<class Thermo , class Table >
static Table::iterator	lookupCstrIter (const dictionary &thermoTypeDict, Table tablePtr, const int nCmpt, const char cmptNames[], const word &thermoTypeName)
	Get the constructor iterator for the given thermo dictionary and. More...

template<class Thermo , class Table >
static Table::iterator	lookupCstrIter (const dictionary &thermoDict, Table *tablePtr)
	Get the constructor iterator for the given thermo dictionary and. More...

Detailed Description

Base-class for thermodynamic properties based on density.

See also: Foam::basicThermo

Source files

Definition at line 51 of file rhoThermo.H.

Constructor & Destructor Documentation

◆ ~rhoThermo()

~rhoThermo ( )

virtual

Destructor.

Definition at line 55 of file rhoThermo.C.

Member Function Documentation

◆ rho() [1/3]

virtual tmp<volScalarField> rho ( ) const

pure virtual

Density [kg/m^3].

Implements basicThermo.

Implemented in rhoThermo::implementation.

Referenced by compressibleInterPhaseThermophysicalTransportModel::alphaEff(), compressibleInterPhaseTransportModel::compressibleInterPhaseTransportModel(), Cole::fDeparture(), compressibleInterPhaseThermophysicalTransportModel::kappaEff(), and compressibleMultiphaseVoF::pressureCorrector().

Here is the caller graph for this function:

◆ rho() [2/3]

virtual tmp<scalarField> rho ( const label patchi ) const

pure virtual

Density for patch [kg/m^3].

Implements basicThermo.

Implemented in rhoThermo::implementation.

◆ rho() [3/3]

virtual volScalarField& rho ( )

pure virtual

Return non-const access to the local density field [kg/m^3].

Implemented in rhoThermo::implementation.

The documentation for this class was generated from the following files:

src/thermophysicalModels/basic/rhoThermo/rhoThermo.H
src/thermophysicalModels/basic/rhoThermo/rhoThermo.C
