relativeVelocityModel Class Reference

Inheritance diagram for relativeVelocityModel:

Collaboration diagram for relativeVelocityModel:

Public Member Functions
	TypeName ("relativeVelocityModel")
	Runtime type information. More...
	declareRunTimeSelectionTable (autoPtr, relativeVelocityModel, dictionary,(const dictionary &dict, const incompressibleDriftFluxMixture &mixture, const uniformDimensionedVectorField &g),(dict, mixture, g))
	Declare runtime constructor selection table. More...
	relativeVelocityModel (const dictionary &dict, const incompressibleDriftFluxMixture &mixture, const uniformDimensionedVectorField &g)
	Construct from components. More...
	relativeVelocityModel (const relativeVelocityModel &)=delete
	Disallow default bitwise copy construction. More...
virtual	~relativeVelocityModel ()
	Destructor. More...
const incompressibleDriftFluxMixture &	mixture () const
	Mixture properties. More...
const volVectorField &	Udm () const
	Return the diffusion velocity of the dispersed phase. More...
virtual tmp< volScalarField >	UdmCoeff () const =0
	Return the diffusion velocity coefficient. More...
tmp< volVectorField >	acceleration () const
	Return the dispersed phase acceleration. More...
tmp< volSymmTensorField >	tauDm () const
	Return the stress tensor due to the phase transport. More...
tmp< volVectorField >	divDevTau () const
	Return the div stress tensor due to the phase transport. More...
virtual void	correct ()
	Update the diffusion velocity. More...
void	operator= (const relativeVelocityModel &)=delete
	Disallow default bitwise assignment. More...

Static Public Member Functions
static autoPtr< relativeVelocityModel >	New (const dictionary &dict, const incompressibleDriftFluxMixture &mixture, const uniformDimensionedVectorField &g)

Protected Attributes
const incompressibleDriftFluxMixture &	mixture_
	Mixture properties. More...
const uniformDimensionedVectorField &	g_
	Acceleration due to gravity. More...
volVectorField	Udm_
	Dispersed diffusion velocity. More...

Detailed Description

Source files

• relativeVelocityModel.H
• relativeVelocityModel.C

Definition at line 49 of file relativeVelocityModel.H.

Constructor & Destructor Documentation

relativeVelocityModel() [1/2]

relativeVelocityModel	(	const dictionary &	dict,
		const incompressibleDriftFluxMixture &	mixture,
		const uniformDimensionedVectorField &	g
	)

Construct from components.

Definition at line 72 of file relativeVelocityModel.C.

relativeVelocityModel() [2/2]

relativeVelocityModel ( const relativeVelocityModel &  )

delete

Disallow default bitwise copy construction.

~relativeVelocityModel()

~relativeVelocityModel ( )

virtual

Destructor.

Definition at line 139 of file relativeVelocityModel.C.

Member Function Documentation

TypeName()

TypeName

(

"relativeVelocityModel"

)

Runtime type information.

declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		relativeVelocityModel	,
		dictionary	,
		(const dictionary &dict, const incompressibleDriftFluxMixture &mixture, const uniformDimensionedVectorField &g)	,
		(dict, mixture, g)
	)

Declare runtime constructor selection table.

New()

Foam::autoPtr< Foam::relativeVelocityModel > New ( const dictionary &  dict, const incompressibleDriftFluxMixture &  mixture, const uniformDimensionedVectorField &  g  )

static

Definition at line 100 of file relativeVelocityModel.C.

References Foam::abort(), dict, Foam::endl(), Foam::FatalIOError, FatalIOErrorInFunction, Foam::Info, dictionary::lookup(), Foam::nl, and dictionary::optionalSubDict().

Here is the call graph for this function:

mixture()

const incompressibleDriftFluxMixture& mixture ( ) const

inline

Mixture properties.

Definition at line 121 of file relativeVelocityModel.H.

References relativeVelocityModel::mixture_.

Udm()

const volVectorField& Udm ( ) const

inline

Return the diffusion velocity of the dispersed phase.

Definition at line 127 of file relativeVelocityModel.H.

References relativeVelocityModel::Udm_.

UdmCoeff()

virtual tmp<volScalarField> UdmCoeff ( ) const

pure virtual

Return the diffusion velocity coefficient.

Udm = UdmCoeff*acceleration

Implemented in simple, MichaelsBolger, and general.

acceleration()

Foam::tmp< Foam::volVectorField > acceleration

(

)

const

Return the dispersed phase acceleration.

Including buoyancy and flow curvature

Definition at line 146 of file relativeVelocityModel.C.

References Foam::fvc::grad().

Here is the call graph for this function:

tauDm()

Foam::tmp< Foam::volSymmTensorField > tauDm

(

)

const

Return the stress tensor due to the phase transport.

Definition at line 165 of file relativeVelocityModel.C.

References GeometricField< Type, GeoMesh, PrimitiveField >::New(), and Foam::sqr().

Here is the call graph for this function:

divDevTau()

Foam::tmp< Foam::volVectorField > divDevTau

(

)

const

Return the div stress tensor due to the phase transport.

Definition at line 181 of file relativeVelocityModel.C.

References Foam::fvc::div().

Here is the call graph for this function:

correct()

void correct ( )

virtual

Update the diffusion velocity.

Definition at line 187 of file relativeVelocityModel.C.

operator=()

void operator= ( const relativeVelocityModel &  )

delete

Disallow default bitwise assignment.

Member Data Documentation

mixture_

const incompressibleDriftFluxMixture& mixture_

protected

Mixture properties.

Definition at line 62 of file relativeVelocityModel.H.

Referenced by relativeVelocityModel::mixture().

g_

const uniformDimensionedVectorField& g_

protected

Acceleration due to gravity.

Definition at line 65 of file relativeVelocityModel.H.

Udm_

volVectorField Udm_

mutableprotected

Dispersed diffusion velocity.

Definition at line 68 of file relativeVelocityModel.H.

Referenced by relativeVelocityModel::Udm().

---

The documentation for this class was generated from the following files:

• applications/modules/incompressibleDriftFlux/relativeVelocityModels/relativeVelocityModel/relativeVelocityModel.H
• applications/modules/incompressibleDriftFlux/relativeVelocityModels/relativeVelocityModel/relativeVelocityModel.C
