Container class to provide injection data for reacting parcels. More...

Inheritance diagram for reactingParcelInjectionData:

Collaboration diagram for reactingParcelInjectionData:

Public Member Functions
	TypeName ("reactingParcelInjectionData")
	Runtime type information. More...

	reactingParcelInjectionData ()
	Null constructor. More...

	reactingParcelInjectionData (const dictionary &dict)
	Construct from dictionary. More...

	reactingParcelInjectionData (Istream &is)
	Construct from Istream. More...

virtual	~reactingParcelInjectionData ()
	Destructor. More...

const scalarList &	Y () const
	Return const access to the list of mass fractions. More...

scalarList &	Y ()
	Return access to the mass fractions. More...

Public Member Functions inherited from thermoParcelInjectionData
	TypeName ("thermoParcelInjectionData")
	Runtime type information. More...

	thermoParcelInjectionData ()
	Null constructor. More...

	thermoParcelInjectionData (const dictionary &dict)
	Construct from dictionary. More...

	thermoParcelInjectionData (Istream &is)
	Construct from Istream. More...

virtual	~thermoParcelInjectionData ()
	Destructor. More...

scalar	T () const
	Return const access to the temperature. More...

scalar	Cp () const
	Return const access to the specific heat capacity. More...

scalar &	T ()
	Return access to the temperature. More...

scalar &	Cp ()
	Return access to the specific heat capacity. More...

Public Member Functions inherited from momentumParcelInjectionData
	TypeName ("momentumParcelInjectionData")
	Runtime type information. More...

	momentumParcelInjectionData ()
	Null constructor. More...

	momentumParcelInjectionData (const dictionary &dict)
	Construct from dictionary. More...

	momentumParcelInjectionData (Istream &is)
	Construct from Istream. More...

virtual	~momentumParcelInjectionData ()
	Destructor. More...

const point &	x () const
	Return const access to the position. More...

const vector &	U () const
	Return const access to the velocity. More...

scalar	d () const
	Return const access to the diameter. More...

scalar	rho () const
	Return const access to the density. More...

scalar	mDot () const
	Return const access to the mass flow rate. More...

point &	x ()
	Return access to the position. More...

vector &	U ()
	Return access to the velocity. More...

scalar &	d ()
	Return access to the diameter. More...

scalar &	rho ()
	Return access to the density. More...

scalar &	mDot ()
	Return access to the mass flow rate. More...

Protected Attributes
scalarList	Y_
	List of mass fractions. More...

Protected Attributes inherited from thermoParcelInjectionData
scalar	T_
	Temperature [K]. More...

scalar	Cp_
	Specific heat capacity [J/kg/K]. More...

Protected Attributes inherited from momentumParcelInjectionData
point	x_
	Position [m]. More...

vector	U_
	Velocity [m/s]. More...

scalar	d_
	Diameter [m]. More...

scalar	rho_
	Density [kg/m^3]. More...

scalar	mDot_
	Mass flow rate [kg/s]. More...

Friends
Ostream &	operator<< (Ostream &os, const reactingParcelInjectionData &data)
	Ostream operator. More...

Istream &	operator>> (Istream &is, reactingParcelInjectionData &data)
	Istream operator. More...

Detailed Description

Container class to provide injection data for reacting parcels.

Source files

Definition at line 66 of file reactingParcelInjectionData.H.

Constructor & Destructor Documentation

◆ reactingParcelInjectionData() [1/3]

reactingParcelInjectionData ( )

Null constructor.

Definition at line 37 of file reactingParcelInjectionData.C.

◆ reactingParcelInjectionData() [2/3]

reactingParcelInjectionData ( const dictionary & dict )

Construct from dictionary.

Definition at line 44 of file reactingParcelInjectionData.C.

◆ reactingParcelInjectionData() [3/3]

reactingParcelInjectionData ( Istream & is )

Construct from Istream.

Definition at line 30 of file reactingParcelInjectionDataIO.C.

References IOstream::check(), and reactingParcelInjectionData::Y_.

Here is the call graph for this function:

◆ ~reactingParcelInjectionData()

~reactingParcelInjectionData ( )

virtual

Destructor.

Definition at line 55 of file reactingParcelInjectionData.C.

Member Function Documentation

◆ TypeName()

TypeName ( "reactingParcelInjectionData" )

Runtime type information.

◆ Y() [1/2]

const Foam::scalarList & Y ( ) const

inline

Return const access to the list of mass fractions.

Definition at line 30 of file reactingParcelInjectionDataI.H.

References reactingParcelInjectionData::Y_.

◆ Y() [2/2]

Foam::scalarList & Y ( )

inline

Return access to the mass fractions.

Definition at line 36 of file reactingParcelInjectionDataI.H.

Friends And Related Function Documentation

◆ operator<<

Ostream& operator<<	(	Ostream &	os,
		const reactingParcelInjectionData &	data
	)

friend

Ostream operator.

◆ operator>>

Istream& operator>>	(	Istream &	is,
		reactingParcelInjectionData &	data
	)

friend

Istream operator.

Member Data Documentation

◆ Y_

scalarList Y_

protected

List of mass fractions.

Definition at line 75 of file reactingParcelInjectionData.H.

Referenced by Foam::operator>>(), reactingParcelInjectionData::reactingParcelInjectionData(), and reactingParcelInjectionData::Y().

The documentation for this class was generated from the following files:

src/lagrangian/parcel/submodels/Reacting/InjectionModel/ReactingLookupTableInjection/reactingParcelInjectionData.H
src/lagrangian/parcel/submodels/Reacting/InjectionModel/ReactingLookupTableInjection/reactingParcelInjectionData.C
src/lagrangian/parcel/submodels/Reacting/InjectionModel/ReactingLookupTableInjection/reactingParcelInjectionDataI.H
src/lagrangian/parcel/submodels/Reacting/InjectionModel/ReactingLookupTableInjection/reactingParcelInjectionDataIO.C
