This velocity inlet/outlet boundary condition for pressure boundary where the pressure is specified. A zero-gradient is applied for outflow (as defined by the flux); for inflow, the velocity is obtained from the flux with the specified inlet direction. More...

Inheritance diagram for pressureInletOutletParSlipVelocityFvPatchVectorField:

[legend]

Collaboration diagram for pressureInletOutletParSlipVelocityFvPatchVectorField:

[legend]

Public Member Functions
	TypeName ("pressureInletOutletParSlipVelocity")
	Runtime type information. More...

	pressureInletOutletParSlipVelocityFvPatchVectorField (const pressureInletOutletParSlipVelocityFvPatchVectorField &, const fvPatch &, const DimensionedField< vector, volMesh > &, const fieldMapper &)
	Construct by mapping given. More...

	pressureInletOutletParSlipVelocityFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &, const dictionary &)
	Construct from patch, internal field and dictionary. More...

	pressureInletOutletParSlipVelocityFvPatchVectorField (const pressureInletOutletParSlipVelocityFvPatchVectorField &)=delete
	Disallow copy without setting internal field reference. More...

	pressureInletOutletParSlipVelocityFvPatchVectorField (const pressureInletOutletParSlipVelocityFvPatchVectorField &, const DimensionedField< vector, volMesh > &)
	Copy constructor setting internal field reference. More...

virtual tmp< fvPatchVectorField >	clone (const DimensionedField< vector, volMesh > &iF) const
	Construct and return a clone setting internal field reference. More...

virtual bool	assignable () const
	Return true: this patch field is altered by assignment. More...

const word &	rhoName () const
	Return the name of rho. More...

word &	rhoName ()
	Return reference to the name of rho to allow adjustment. More...

const word &	phiName () const
	Return the name of phi. More...

word &	phiName ()
	Return reference to the name of phi to allow adjustment. More...

virtual void	updateCoeffs ()
	Update the coefficients associated with the patch field. More...

virtual void	write (Ostream &) const
	Write. More...

virtual void	operator= (const fvPatchField< vector > &pvf)

Detailed Description

This velocity inlet/outlet boundary condition for pressure boundary where the pressure is specified. A zero-gradient is applied for outflow (as defined by the flux); for inflow, the velocity is obtained from the flux with the specified inlet direction.

A slip condition is applied tangential to the patch.

Usage

Property	Description	Required	Default value
`phi`	flux field name	no	phi
`rho`	density field name	no	rho

Example of the boundary condition specification:

    <patchName>
    {
        type            pressureInletOutletParSlipVelocity;
        value           uniform (0 0 0);
    }

Note: Sign conventions:

positive flux (out of domain): apply zero-gradient condition
negative flux (into of domain): derive from the flux with specified direction

See also: Foam::mixedFvPatchVectorField Foam::pressureDirectedInletOutletVelocityFvPatchVectorField

Source files

Definition at line 95 of file pressureInletOutletParSlipVelocityFvPatchVectorField.H.

Constructor & Destructor Documentation

◆ pressureInletOutletParSlipVelocityFvPatchVectorField() [1/4]

pressureInletOutletParSlipVelocityFvPatchVectorField	(	const pressureInletOutletParSlipVelocityFvPatchVectorField &	ptf,
		const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const fieldMapper &	mapper
	)

Construct by mapping given.

pressureInletOutletParSlipVelocityFvPatchVectorField onto a new patch

Definition at line 56 of file pressureInletOutletParSlipVelocityFvPatchVectorField.C.

◆ pressureInletOutletParSlipVelocityFvPatchVectorField() [2/4]

pressureInletOutletParSlipVelocityFvPatchVectorField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const dictionary &	dict
	)

Construct from patch, internal field and dictionary.

Definition at line 34 of file pressureInletOutletParSlipVelocityFvPatchVectorField.C.

References dict, DimensionedField< Type, GeoMesh, PrimitiveField >::dimensions(), fvPatchField< Type >::operator, p, and Foam::Zero.

Here is the call graph for this function:

◆ pressureInletOutletParSlipVelocityFvPatchVectorField() [3/4]

pressureInletOutletParSlipVelocityFvPatchVectorField ( const pressureInletOutletParSlipVelocityFvPatchVectorField & )

delete

Disallow copy without setting internal field reference.

◆ pressureInletOutletParSlipVelocityFvPatchVectorField() [4/4]

pressureInletOutletParSlipVelocityFvPatchVectorField	(	const pressureInletOutletParSlipVelocityFvPatchVectorField &	pivpvf,
		const DimensionedField< vector, volMesh > &	iF
	)

Copy constructor setting internal field reference.

Definition at line 71 of file pressureInletOutletParSlipVelocityFvPatchVectorField.C.

Member Function Documentation

◆ TypeName()

TypeName ( "pressureInletOutletParSlipVelocity" )

Runtime type information.

◆ clone()

virtual tmp<fvPatchVectorField> clone ( const DimensionedField< vector, volMesh > & iF ) const

inlinevirtual

Construct and return a clone setting internal field reference.

Definition at line 149 of file pressureInletOutletParSlipVelocityFvPatchVectorField.H.

◆ assignable()

virtual bool assignable ( ) const

inlinevirtual

Return true: this patch field is altered by assignment.

Definition at line 170 of file pressureInletOutletParSlipVelocityFvPatchVectorField.H.

◆ rhoName() [1/2]

const word& rhoName ( ) const

inline

Return the name of rho.

Definition at line 179 of file pressureInletOutletParSlipVelocityFvPatchVectorField.H.

◆ rhoName() [2/2]

word& rhoName ( )

inline

Return reference to the name of rho to allow adjustment.

Definition at line 185 of file pressureInletOutletParSlipVelocityFvPatchVectorField.H.

◆ phiName() [1/2]

const word& phiName ( ) const

inline

Return the name of phi.

Definition at line 191 of file pressureInletOutletParSlipVelocityFvPatchVectorField.H.

◆ phiName() [2/2]

word& phiName ( )

inline

Return reference to the name of phi to allow adjustment.

Definition at line 197 of file pressureInletOutletParSlipVelocityFvPatchVectorField.H.

◆ updateCoeffs()

void updateCoeffs ( )

virtual

Update the coefficients associated with the patch field.

Definition at line 86 of file pressureInletOutletParSlipVelocityFvPatchVectorField.C.

References DimensionedField< Type, GeoMesh, PrimitiveField >::dimensions(), Foam::dimMassFlux, Foam::dimVolumetricFlux, Foam::exit(), Foam::FatalError, FatalErrorInFunction, n, Foam::neg(), and Foam::nl.

Here is the call graph for this function:

◆ write()

void write ( Ostream & os ) const

virtual

Write.

Definition at line 133 of file pressureInletOutletParSlipVelocityFvPatchVectorField.C.

References fvPatchField< Type >::write(), and Foam::writeEntry().

Here is the call graph for this function:

◆ operator=()

void operator= ( const fvPatchField< vector > & pvf )

virtual

Definition at line 147 of file pressureInletOutletParSlipVelocityFvPatchVectorField.C.

References fvPatchField< Type >::operator=().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/finiteVolume/fields/fvPatchFields/derived/pressureInletOutletParSlipVelocity/pressureInletOutletParSlipVelocityFvPatchVectorField.H
src/finiteVolume/fields/fvPatchFields/derived/pressureInletOutletParSlipVelocity/pressureInletOutletParSlipVelocityFvPatchVectorField.C
