Public Member Functions | Static Public Member Functions | Friends | List of all members
polynomialTransport< Thermo, PolySize > Class Template Reference

Transport package using polynomial functions of temperature for the dynamic viscosity and thermal conductivity: More...

Inheritance diagram for polynomialTransport< Thermo, PolySize >:
Inheritance graph
[legend]
Collaboration diagram for polynomialTransport< Thermo, PolySize >:
Collaboration graph
[legend]

Public Member Functions

 polynomialTransport (const Thermo &t, const Polynomial< PolySize > &muPoly, const Polynomial< PolySize > &kappaPoly)
 Construct from components. More...

 polynomialTransport (const word &, const polynomialTransport &)
 Construct as named copy. More...

 polynomialTransport (const word &name, const dictionary &dict)
 Construct from name and dictionary. More...

autoPtr< polynomialTransport > clone () const
 Construct and return a clone. More...

scalar mu (const scalar p, const scalar T) const
 Dynamic viscosity [kg/m/s]. More...

scalar kappa (const scalar p, const scalar T) const
 Thermal conductivity [W/m/K]. More...

void write (Ostream &os) const
 Write to Ostream. More...

void operator+= (const polynomialTransport &)

void operator*= (const scalar)


Static Public Member Functions

static word typeName ()
 Return the instantiated type name. More...


Friends

polynomialTransport operator+ (const polynomialTransport &, const polynomialTransport &)

polynomialTransport operator* (const scalar, const polynomialTransport &)

Ostream & operator (Ostream &, const polynomialTransport &)


Detailed Description

template<class Thermo, int PolySize = 8>
class Foam::polynomialTransport< Thermo, PolySize >

Transport package using polynomial functions of temperature for the dynamic viscosity and thermal conductivity:

    mu = muCoeffs[0] + muCoeffs[1]*T + muCoeffs[2]*sqr(T)
       + muCoeffs[3]*pow3(T) + muCoeffs[4]*pow4(T)
       + muCoeffs[5]*pow(T, 5) + muCoeffs[6]*pow(T, 6)
       + muCoeffs[7]*pow(T, 7)

    kappa = kappaCoeffs[0] + kappaCoeffs[1]*T + kappaCoeffs[2]*sqr(T)
       + kappaCoeffs[3]*pow3(T) + kappaCoeffs[4]*pow4(T)
       + kappaCoeffs[5]*pow(T, 5) + kappaCoeffs[6]*pow(T, 6)
       + kappaCoeffs[7]*pow(T, 7)

The polynomial function is templated on the order of the polynomial which defaults to 8.

Usage
Property Description
muCoeffs<8> Dynamic viscosity polynomial coefficients
kappaCoeffs<8> Thermal conductivity polynomial coefficients

Example of the specification of the transport properties:

    transport
    {
        muCoeffs<8>     (1000 -0.05 0.003 0 0 0 0 0);
        kappaCoeffs<8>  (2000 -0.15 0.023 0 0 0 0 0);
    }
Source files
See also
Foam::Polynomial

Definition at line 120 of file polynomialTransport.H.

Constructor & Destructor Documentation

◆ polynomialTransport() [1/3]

polynomialTransport ( const Thermo &  t,
const Polynomial< PolySize > &  muPoly,
const Polynomial< PolySize > &  kappaPoly
)
inline

Construct from components.

Definition at line 31 of file polynomialTransportI.H.

◆ polynomialTransport() [2/3]

polynomialTransport ( const word &  name,
const polynomialTransport< Thermo, PolySize > &  pt
)
inline

Construct as named copy.

Definition at line 45 of file polynomialTransportI.H.

◆ polynomialTransport() [3/3]

polynomialTransport ( const word &  name,
const dictionary &  dict
)

Construct from name and dictionary.

Definition at line 32 of file polynomialTransport.C.

Member Function Documentation

◆ clone()

Foam::autoPtr< Foam::polynomialTransport< Thermo, PolySize > > clone
inline

Construct and return a clone.

Definition at line 59 of file polynomialTransportI.H.

◆ typeName()

static word typeName ( )
inlinestatic

Return the instantiated type name.

Definition at line 158 of file polynomialTransport.H.

◆ mu()

Foam::scalar mu ( const scalar  p,
const scalar  T
) const
inline

Dynamic viscosity [kg/m/s].

Definition at line 71 of file polynomialTransportI.H.

References Foam::T().

Here is the call graph for this function:

◆ kappa()

Foam::scalar kappa ( const scalar  p,
const scalar  T
) const
inline

Thermal conductivity [W/m/K].

Definition at line 82 of file polynomialTransportI.H.

References Foam::T().

Here is the call graph for this function:

◆ write()

void write ( Ostream &  os) const

Write to Ostream.

Definition at line 59 of file polynomialTransport.C.

References dictionary::add(), token::BEGIN_BLOCK, Foam::decrIndent(), dict, dictionaryName::dictName(), token::END_BLOCK, Foam::endl(), Foam::incrIndent(), Foam::indent(), Foam::name(), Foam::nl, and Foam::vtkWriteOps::write().

Here is the call graph for this function:

◆ operator+=()

void operator+= ( const polynomialTransport< Thermo, PolySize > &  )
inline

Definition at line 95 of file polynomialTransportI.H.

References Foam::mag(), Foam::operator+=(), and Y.

Here is the call graph for this function:

◆ operator*=()

void operator*= ( const scalar  s)
inline

Definition at line 116 of file polynomialTransportI.H.

References s().

Here is the call graph for this function:

Friends And Related Function Documentation

◆ operator+

polynomialTransport operator+ ( const polynomialTransport< Thermo, PolySize > &  ,
const polynomialTransport< Thermo, PolySize > &
)
friend

◆ operator*

polynomialTransport operator* ( const  scalar,
const polynomialTransport< Thermo, PolySize > &
)
friend

◆ operator

Ostream& operator ( Ostream &  ,
const polynomialTransport< Thermo, PolySize > &
)
friend
The documentation for this class was generated from the following files:
