Abstract base class for multi-variate surface interpolation schemes. More...

Inheritance diagram for multivariateSurfaceInterpolationScheme< Type >:

[legend]

Collaboration diagram for multivariateSurfaceInterpolationScheme< Type >:

Classes
class	fieldScheme
	surfaceInterpolationScheme sub-class returned by operator(field) More...

class	fieldTable
	fieldTable More...

Public Member Functions
virtual const word &	type () const =0
	Runtime type information. More...

	declareRunTimeSelectionTable (tmp, multivariateSurfaceInterpolationScheme, Istream,(const fvMesh &mesh, const fieldTable &fields, const surfaceScalarField &faceFlux, Istream &is),(mesh, fields, faceFlux, is))

	multivariateSurfaceInterpolationScheme (const fvMesh &mesh, const fieldTable &fields, const surfaceScalarField &faceFlux, Istream &schemeData)
	Construct for interpolating given field. More...

	multivariateSurfaceInterpolationScheme (const multivariateSurfaceInterpolationScheme &)=delete
	Disallow default bitwise copy construction. More...

virtual	~multivariateSurfaceInterpolationScheme ()
	Destructor. More...

const fvMesh &	mesh () const
	Return mesh reference. More...

const fieldTable &	fields () const
	Return fields to be interpolated. More...

void	operator= (const multivariateSurfaceInterpolationScheme &)=delete
	Disallow default bitwise assignment. More...

virtual tmp< surfaceInterpolationScheme< Type > >	operator() (const VolField< Type > &field) const =0

Public Member Functions inherited from refCount
int	count () const
	Return the current reference count. More...

bool	unique () const
	Return true if the reference count is zero. More...

void	operator++ ()
	Increment the reference count. More...

void	operator++ (int)
	Increment the reference count. More...

void	operator-- ()
	Decrement the reference count. More...

void	operator-- (int)
	Decrement the reference count. More...

void	operator= (const refCount &)=delete
	Disallow bitwise assignment. More...

Static Public Member Functions
static tmp< multivariateSurfaceInterpolationScheme< Type > >	New (const fvMesh &mesh, const fieldTable &fields, const surfaceScalarField &faceFlux, Istream &schemeData)
	Return a pointer to a new gradScheme created on freestore. More...

Additional Inherited Members
Protected Member Functions inherited from refCount
	refCount ()
	Construct null initialising count to 0. More...

	refCount (const refCount &)=delete
	Disallow copy. More...

Detailed Description

template<class Type>
class Foam::multivariateSurfaceInterpolationScheme< Type >

Abstract base class for multi-variate surface interpolation schemes.

Source files

Definition at line 50 of file multivariateSurfaceInterpolationScheme.H.

Constructor & Destructor Documentation

◆ multivariateSurfaceInterpolationScheme() [1/2]

multivariateSurfaceInterpolationScheme	(	const fvMesh &	mesh,
		const fieldTable &	fields,
		const surfaceScalarField &	faceFlux,
		Istream &	schemeData
	)

Construct for interpolating given field.

◆ multivariateSurfaceInterpolationScheme() [2/2]

multivariateSurfaceInterpolationScheme ( const multivariateSurfaceInterpolationScheme< Type > & )

delete

Disallow default bitwise copy construction.

◆ ~multivariateSurfaceInterpolationScheme()

~multivariateSurfaceInterpolationScheme

virtual

Destructor.

Definition at line 92 of file multivariateSurfaceInterpolationScheme.C.

Member Function Documentation

◆ type()

virtual const word& type ( ) const

pure virtual

Runtime type information.

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	tmp	,
		multivariateSurfaceInterpolationScheme< Type >	,
		Istream	,
		(const fvMesh &mesh, const fieldTable &fields, const surfaceScalarField &faceFlux, Istream &is)	,
		(mesh, fields, faceFlux, is)
	)

◆ New()

Foam::tmp< Foam::multivariateSurfaceInterpolationScheme< Type > > New	(	const fvMesh &	mesh,
		const fieldTable &	fields,
		const surfaceScalarField &	faceFlux,
		Istream &	schemeData
	)

static

Return a pointer to a new gradScheme created on freestore.

Definition at line 55 of file multivariateSurfaceInterpolationScheme.C.

References Foam::endl(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, InfoInFunction, mesh, and Foam::nl.

Here is the call graph for this function:

◆ mesh()

const fvMesh& mesh ( ) const

inline

Return mesh reference.

Definition at line 145 of file multivariateSurfaceInterpolationScheme.H.

Referenced by multivariateScheme< Type, Scheme >::multivariateScheme(), and multivariateSelectionScheme< Type >::multivariateSelectionScheme().

Here is the caller graph for this function:

◆ fields()

const fieldTable& fields ( ) const

inline

Return fields to be interpolated.

Definition at line 151 of file multivariateSurfaceInterpolationScheme.H.

Referenced by multivariateScheme< Type, Scheme >::multivariateScheme(), and multivariateSelectionScheme< Type >::multivariateSelectionScheme().

Here is the caller graph for this function:

◆ operator=()

void operator= ( const multivariateSurfaceInterpolationScheme< Type > & )

delete

Disallow default bitwise assignment.

◆ operator()()

virtual tmp<surfaceInterpolationScheme<Type> > operator() ( const VolField< Type > & field ) const

pure virtual

Implemented in multivariateUpwind< Type >, multivariateSelectionScheme< Type >, multivariateScheme< Type, Scheme >, and multivariateIndependentScheme< Type >.

The documentation for this class was generated from the following files:

src/finiteVolume/interpolation/surfaceInterpolation/multivariateSchemes/multivariateSurfaceInterpolationScheme/multivariateSurfaceInterpolationScheme.H
src/finiteVolume/interpolation/surfaceInterpolation/multivariateSchemes/multivariateSurfaceInterpolationScheme/multivariateSurfaceInterpolationScheme.C
