Mixed boundary condition for the phase temperature of a phase in an Euler-Euler multiphase simulation, to be used for heat-transfer with another region in a CHT case. Optional thin wall material layer resistances can be specified through thicknessLayers and kappaLayers entries. More...

Inheritance diagram for multiphaseExternalTemperatureFvPatchScalarField:

[legend]

Collaboration diagram for multiphaseExternalTemperatureFvPatchScalarField:

[legend]

Public Member Functions
	TypeName ("multiphaseExternalTemperature")
	Runtime type information. More...

	multiphaseExternalTemperatureFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
	Construct from patch, internal field and dictionary. More...

	multiphaseExternalTemperatureFvPatchScalarField (const multiphaseExternalTemperatureFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fieldMapper &)
	Construct by mapping given. More...

	multiphaseExternalTemperatureFvPatchScalarField (const multiphaseExternalTemperatureFvPatchScalarField &)=delete
	Disallow copy without setting internal field reference. More...

	multiphaseExternalTemperatureFvPatchScalarField (const multiphaseExternalTemperatureFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
	Copy constructor setting internal field reference. More...

virtual tmp< fvPatchScalarField >	clone (const DimensionedField< scalar, volMesh > &iF) const
	Construct and return a clone setting internal field reference. More...

Public Member Functions inherited from externalTemperatureFvPatchScalarField
	TypeName ("externalTemperature")
	Runtime type information. More...

	externalTemperatureFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
	Construct from patch, internal field and dictionary. More...

	externalTemperatureFvPatchScalarField (const externalTemperatureFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fieldMapper &)
	Construct by mapping given. More...

	externalTemperatureFvPatchScalarField (const externalTemperatureFvPatchScalarField &)=delete
	Disallow copy without setting internal field reference. More...

	externalTemperatureFvPatchScalarField (const externalTemperatureFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
	Copy constructor setting internal field reference. More...

virtual bool	fixesValue () const
	Disallow manipulation of the boundary values. More...

virtual void	map (const fvPatchScalarField &, const fieldMapper &)
	Map the given fvPatchField onto this fvPatchField. More...

virtual void	reset (const fvPatchScalarField &)
	Reset the fvPatchField to the given fvPatchField. More...

virtual void	updateCoeffs ()
	Update the coefficients associated with the patch field. More...

void	write (Ostream &) const
	Write. More...

Protected Member Functions
virtual void	getKappa (scalarField &kappa, tmp< scalarField > &sumKappaTcByDelta, tmp< scalarField > &sumKappaByDelta, tmp< scalarField > &T, tmp< scalarField > &sumq) const
	Get the patch kappa, sum kappa*Tc/delta, kappa/delta and. More...

Protected Member Functions inherited from externalTemperatureFvPatchScalarField
void	plusEqOp (tmp< scalarField > &tf, const scalar d) const
	Plus-equals op for a tmp field. Will initialise the tmp if empty. More...

void	plusEqOp (tmp< scalarField > &tf, const tmp< scalarField > &tdf) const
	Plus-equals op for a tmp field. Will initialise the tmp if empty. More...

Detailed Description

Mixed boundary condition for the phase temperature of a phase in an Euler-Euler multiphase simulation, to be used for heat-transfer with another region in a CHT case. Optional thin wall material layer resistances can be specified through thicknessLayers and kappaLayers entries.

See also: Foam::externalTemperatureFvPatchScalarField

Source files

Definition at line 54 of file multiphaseExternalTemperatureFvPatchScalarField.H.

Constructor & Destructor Documentation

◆ multiphaseExternalTemperatureFvPatchScalarField() [1/4]

multiphaseExternalTemperatureFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const dictionary &	dict
	)

Construct from patch, internal field and dictionary.

Definition at line 88 of file multiphaseExternalTemperatureFvPatchScalarField.C.

Referenced by multiphaseExternalTemperatureFvPatchScalarField::clone().

Here is the caller graph for this function:

◆ multiphaseExternalTemperatureFvPatchScalarField() [2/4]

multiphaseExternalTemperatureFvPatchScalarField	(	const multiphaseExternalTemperatureFvPatchScalarField &	psf,
		const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const fieldMapper &	mapper
	)

Construct by mapping given.

multiphaseExternalTemperatureFvPatchScalarField onto a new patch

Definition at line 100 of file multiphaseExternalTemperatureFvPatchScalarField.C.

◆ multiphaseExternalTemperatureFvPatchScalarField() [3/4]

multiphaseExternalTemperatureFvPatchScalarField ( const multiphaseExternalTemperatureFvPatchScalarField & )

delete

Disallow copy without setting internal field reference.

◆ multiphaseExternalTemperatureFvPatchScalarField() [4/4]

multiphaseExternalTemperatureFvPatchScalarField	(	const multiphaseExternalTemperatureFvPatchScalarField &	psf,
		const DimensionedField< scalar, volMesh > &	iF
	)

Copy constructor setting internal field reference.

Definition at line 113 of file multiphaseExternalTemperatureFvPatchScalarField.C.

Member Function Documentation

◆ getKappa()

void getKappa	(	scalarField &	kappa,
		tmp< scalarField > &	sumKappaTcByDelta,
		tmp< scalarField > &	sumKappaByDelta,
		tmp< scalarField > &	T,
		tmp< scalarField > &	sumq
	)		const

protectedvirtual

Get the patch kappa, sum kappa*Tc/delta, kappa/delta and.

reference temperature for all phases except the phase being solved and also the current phase-average wall T and phase heat-flux obtained by partitioning the sum heat-flux provided

Reimplemented from externalTemperatureFvPatchScalarField.

Definition at line 32 of file multiphaseExternalTemperatureFvPatchScalarField.C.

References alpha(), GeometricField< Type, GeoMesh, PrimitiveField >::boundaryField(), forAll, Foam::constant::electromagnetic::kappa, phaseModel::kappaEff(), patchi, phaseSystem::phases(), phaseSystem::propertiesName, basicThermo::T(), Foam::T(), and phaseModel::thermo().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "multiphaseExternalTemperature" )

Runtime type information.

◆ clone()

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, volMesh > & iF ) const

inlinevirtual

Construct and return a clone setting internal field reference.
