multiDomainDecomposition Class Reference

... More...

Inheritance diagram for multiDomainDecomposition:

Collaboration diagram for multiDomainDecomposition:

Public Member Functions
	TypeName ("multiDomainDecomposition")
	Runtime type information. More...
	multiDomainDecomposition (const processorRunTimes &procRunTimes, const fileName &meshPath, const wordList &regionNames)
	Construct from processor run times and region names. More...
virtual	~multiDomainDecomposition ()
	Destructor. More...
label	nProcs () const
	Return the number of processors in the decomposition. More...
bool	readDecompose (const bool doSets)
	Read in the complete mesh. Read the processor meshes if they are. More...
bool	readReconstruct (const bool doSets)
	Read in the processor meshes. Read the complete mesh if it is. More...
fvMesh::readUpdateState	readUpdateDecompose ()
	Read-update for decomposition. More...
fvMesh::readUpdateState	readUpdateReconstruct ()
	Read-update for reconstruction. More...
void	writeComplete (const bool doSets) const
	Write the decomposed meshes and associated data. More...
void	writeProcs (const bool doSets) const
	Write the decomposed meshes and associated data. More...
Public Member Functions inherited from MultiRegionListBase< Container, Region >
	MultiRegionListBase (Container< Region > &regions, bool reuse)
	Construct from a list of regions. More...
	MultiRegionListBase (Container< Region > &&regions)
	Construct from a list of regions. More...
Public Member Functions inherited from MultiRegionRefs< Region >
	MultiRegionRefs (UPtrList< Region > &regions)
	Construct from a list of region pointers. More...
	~MultiRegionRefs ()
	Destructor. More...
label	size () const
	Return the size. More...
RegionRef< const Region >	operator[] (const label regioni) const
	Const-access a region. More...
RegionRef< Region >	operator[] (const label regioni)
	Access a region. More...
RegionRef< const Region >	operator[] (const word &regionName) const
	Const-access a region. More...
RegionRef< Region >	operator[] (const word &regionName)
	Access a region. More...

Detailed Description

...

Source files

• multiDomainDecomposition.H
• multiDomainDecomposition.C

Definition at line 49 of file multiDomainDecomposition.H.

Constructor & Destructor Documentation

multiDomainDecomposition()

multiDomainDecomposition	(	const processorRunTimes &	procRunTimes,
		const fileName &	meshPath,
		const wordList &	regionNames
	)

Construct from processor run times and region names.

Definition at line 68 of file multiDomainDecomposition.C.

~multiDomainDecomposition()

~multiDomainDecomposition ( )

virtual

Destructor.

Definition at line 82 of file multiDomainDecomposition.C.

Member Function Documentation

TypeName()

TypeName

(

"multiDomainDecomposition"

)

Runtime type information.

nProcs()

label nProcs ( ) const

inline

Return the number of processors in the decomposition.

Definition at line 94 of file multiDomainDecomposition.H.

References processorRunTimes::nProcs().

Here is the call graph for this function:

readDecompose()

bool readDecompose

(

const bool

doSets

)

Read in the complete mesh. Read the processor meshes if they are.

available and up to date relative to the complete mesh, or decompose if not. Return whether or not decomposition happened.

Definition at line 88 of file multiDomainDecomposition.C.

References Foam::endl(), forAll, and Foam::Info.

Here is the call graph for this function:

readReconstruct()

bool readReconstruct

(

const bool

doSets

)

Read in the processor meshes. Read the complete mesh if it is.

available and up to date relative to the processor meshes, or reconstruct if not. Return whether or not reconstruction happened.

Definition at line 124 of file multiDomainDecomposition.C.

References Foam::endl(), forAll, and Foam::Info.

Here is the call graph for this function:

readUpdateDecompose()

Foam::fvMesh::readUpdateState readUpdateDecompose

(

)

Read-update for decomposition.

Definition at line 161 of file multiDomainDecomposition.C.

References Foam::endl(), forAll, Foam::Info, fvMesh::TOPO_CHANGE, and fvMesh::UNCHANGED.

Here is the call graph for this function:

readUpdateReconstruct()

Foam::fvMesh::readUpdateState readUpdateReconstruct

(

)

Read-update for reconstruction.

Definition at line 193 of file multiDomainDecomposition.C.

References Foam::endl(), forAll, Foam::Info, fvMesh::TOPO_CHANGE, and fvMesh::UNCHANGED.

Here is the call graph for this function:

writeComplete()

void writeComplete

(

const bool

doSets

)

const

Write the decomposed meshes and associated data.

Definition at line 224 of file multiDomainDecomposition.C.

References forAll.

writeProcs()

void writeProcs

(

const bool

doSets

)

const

Write the decomposed meshes and associated data.

Definition at line 233 of file multiDomainDecomposition.C.

References forAll.

---

The documentation for this class was generated from the following files:

• src/parallel/parallel/multiDomainDecomposition/multiDomainDecomposition.H
• src/parallel/parallel/multiDomainDecomposition/multiDomainDecomposition.C
