meshToMesh0 Class Reference

Serial mesh to mesh interpolation class. More...

Public Types
enum	order { MAP , INTERPOLATE , CELL_POINT_INTERPOLATE , CELL_VOLUME_WEIGHT }
	Enumeration specifying required accuracy. More...

Public Member Functions
	ClassName ("meshToMesh0")
	meshToMesh0 (const fvMesh &fromMesh, const fvMesh &toMesh, const HashTable< word > &patchMap, const wordList &cuttingPatchNames)
	Construct from the two meshes, the patch name map for the patches. More...
	meshToMesh0 (const fvMesh &fromMesh, const fvMesh &toMesh)
	Construct from the two meshes assuming there is an exact mapping. More...
	~meshToMesh0 ()
	Destructor. More...
const fvMesh &	fromMesh () const
const fvMesh &	toMesh () const
const labelList &	cellAddressing () const
	From toMesh cells to fromMesh cells. More...
scalar	V () const
	Overlap volume. More...
template<class Type >
void	mapField (Field< Type > &, const Field< Type > &, const labelList &adr) const
	Map field. More...
template<class Type >
void	interpolateField (Field< Type > &, const VolField< Type > &, const labelList &adr, const scalarListList &weights) const
	Interpolate field using inverse-distance weights. More...
template<class Type >
void	interpolateField (Field< Type > &, const VolField< Type > &, const labelListList &adr, const scalarListList &weights) const
	Interpolate field using inverse-volume weights. More...
template<class Type >
void	interpolateField (Field< Type > &, const VolField< Type > &, const labelList &adr, const vectorField &centres) const
	Interpolate field using cell-point interpolation. More...
template<class Type >
void	interpolateInternalField (Field< Type > &, const VolField< Type > &, order=INTERPOLATE) const
	Interpolate internal volume field. More...
template<class Type >
void	interpolateInternalField (Field< Type > &, const tmp< VolField< Type >> &, order=INTERPOLATE) const
template<class Type >
void	interpolate (VolField< Type > &, const VolField< Type > &, order=INTERPOLATE) const
	Interpolate volume field. More...
template<class Type >
void	interpolate (VolField< Type > &, const tmp< VolField< Type >> &, order=INTERPOLATE) const
template<class Type >
tmp< VolField< Type > >	interpolate (const VolField< Type > &, order=INTERPOLATE) const
	Interpolate volume field. More...
template<class Type >
tmp< VolField< Type > >	interpolate (const tmp< VolField< Type >> &, order=INTERPOLATE) const

Detailed Description

Serial mesh to mesh interpolation class.

Source files

• meshToMesh0.H
• meshToMesh0.C
• calculateMeshToMesh0Addressing.C
• calculateMeshToMesh0Weights.C
• meshToMesh0Templates.C

Definition at line 59 of file meshToMesh0.H.

Member Enumeration Documentation

order

enum order

Enumeration specifying required accuracy.

Enumerator
MAP
INTERPOLATE
CELL_POINT_INTERPOLATE
CELL_VOLUME_WEIGHT

Definition at line 142 of file meshToMesh0.H.

Constructor & Destructor Documentation

meshToMesh0() [1/2]

meshToMesh0	(	const fvMesh &	fromMesh,
		const fvMesh &	toMesh,
		const HashTable< word > &	patchMap,
		const wordList &	cuttingPatchNames
	)

Construct from the two meshes, the patch name map for the patches.

to be interpolated and the names of the toMesh-patches which cut the fromMesh

meshToMesh0() [2/2]

meshToMesh0	(	const fvMesh &	fromMesh,
		const fvMesh &	toMesh
	)

Construct from the two meshes assuming there is an exact mapping.

between the patches

~meshToMesh0()

~meshToMesh0

(

)

Destructor.

Member Function Documentation

ClassName()

ClassName

(

"meshToMesh0"

)

fromMesh()

const fvMesh& fromMesh ( ) const

inline

Definition at line 181 of file meshToMesh0.H.

Referenced by Foam::MapConsistentVolFields(), and Foam::MapVolFields().

Here is the caller graph for this function:

toMesh()

const fvMesh& toMesh ( ) const

inline

Definition at line 186 of file meshToMesh0.H.

Referenced by Foam::MapConsistentVolFields(), Foam::MapLagrangianFields(), and Foam::MapVolFields().

Here is the caller graph for this function:

cellAddressing()

const labelList& cellAddressing ( ) const

inline

From toMesh cells to fromMesh cells.

Definition at line 192 of file meshToMesh0.H.

V()

scalar V ( ) const

inline

Overlap volume.

Definition at line 198 of file meshToMesh0.H.

mapField()

void mapField	(	Field< Type > &	,
		const Field< Type > &	,
		const labelList &	adr
	)		const

Map field.

interpolateField() [1/3]

void interpolateField	(	Field< Type > &	,
		const VolField< Type > &	,
		const labelList &	adr,
		const scalarListList &	weights
	)		const

Interpolate field using inverse-distance weights.

interpolateField() [2/3]

void interpolateField	(	Field< Type > &	,
		const VolField< Type > &	,
		const labelListList &	adr,
		const scalarListList &	weights
	)		const

Interpolate field using inverse-volume weights.

interpolateField() [3/3]

void interpolateField	(	Field< Type > &	,
		const VolField< Type > &	,
		const labelList &	adr,
		const vectorField &	centres
	)		const

Interpolate field using cell-point interpolation.

interpolateInternalField() [1/2]

void interpolateInternalField	(	Field< Type > &	,
		const VolField< Type > &	,
		order	= INTERPOLATE
	)		const

Interpolate internal volume field.

interpolateInternalField() [2/2]

void interpolateInternalField	(	Field< Type > &	,
		const tmp< VolField< Type >> &	,
		order	= INTERPOLATE
	)		const

interpolate() [1/4]

void interpolate	(	VolField< Type > &	,
		const VolField< Type > &	,
		order	= INTERPOLATE
	)		const

Interpolate volume field.

Referenced by Foam::MapConsistentVolFields(), and Foam::MapVolFields().

Here is the caller graph for this function:

interpolate() [2/4]

void interpolate	(	VolField< Type > &	,
		const tmp< VolField< Type >> &	,
		order	= INTERPOLATE
	)		const

interpolate() [3/4]

tmp<VolField<Type> > interpolate	(	const VolField< Type > &	,
		order	= INTERPOLATE
	)		const

Interpolate volume field.

interpolate() [4/4]

tmp<VolField<Type> > interpolate	(	const tmp< VolField< Type >> &	,
		order	= INTERPOLATE
	)		const

---

The documentation for this class was generated from the following file:

• applications/utilities/preProcessing/mapFields/meshToMesh0.H
