Wrapper class providing run-time selection of thermophysicalProperties for the templated thermodynamics packages. More...

Inheritance diagram for liquidPropertiesSelector:

[legend]

Collaboration diagram for liquidPropertiesSelector:

[legend]

Public Member Functions
virtual	~liquidPropertiesSelector ()
	Destructor. More...

virtual scalar	sigma (const scalar p, const scalar T) const
	Surface tension [N/m]. More...

scalar	mu (const scalar p, const scalar T) const
	Viscosity [Pa s]. More...

Public Member Functions inherited from thermophysicalPropertiesSelector< liquidProperties >
	thermophysicalPropertiesSelector (const word &name)
	Construct from name. More...

	thermophysicalPropertiesSelector (const word &name, const dictionary &dict)
	Construct from name and dictionary. More...

	thermophysicalPropertiesSelector (const word &name, const thermophysicalPropertiesSelector &)
	Construct as named copy. More...

const word &	name () const
	Return the specie name. More...

const liquidProperties &	properties () const
	Return the physical properties model. More...

scalar	W () const
	Molecular weight [kg/kmol]. More...

scalar	limit (const scalar T) const
	Limit the temperature to be in the range Tlow_ to Thigh_. More...

scalar	rho (scalar p, scalar T) const
	Density [kg/m^3]. More...

scalar	psi (scalar p, scalar T) const
	Compressibility [s^2/m^2]. More...

scalar	CpMCv (scalar p, scalar T) const
	Return (Cp - Cv) [J/kg/K]. More...

scalar	Cp (const scalar p, const scalar T) const
	Heat capacity at constant pressure [J/kg/K]. More...

scalar	hs (const scalar p, const scalar T) const
	Sensible enthalpy [J/kg]. More...

scalar	hf () const
	Enthalpy of formation [J/kg]. More...

scalar	ha (const scalar p, const scalar T) const
	Absolute enthalpy [J/kg]. More...

scalar	Cv (const scalar p, const scalar T) const
	Heat capacity at constant volume [J/kg/K]. More...

scalar	es (const scalar p, const scalar T) const
	Sensible internal energy [J/kg]. More...

scalar	ea (const scalar p, const scalar T) const
	Absolute internal energy [J/kg]. More...

scalar	s (const scalar p, const scalar T) const

scalar	kappa (scalar p, scalar T) const
	Thermal conductivity [W/m/K]. More...

void	write (Ostream &os) const
	Write to Ostream. More...

Additional Inherited Members
Static Public Member Functions inherited from thermophysicalPropertiesSelector< liquidProperties >
static word	typeName ()
	Return the instantiated type name. More...

Static Public Attributes inherited from thermophysicalPropertiesSelector< liquidProperties >
static const bool	incompressible
	Is the equation of state is incompressible i.e. rho != f(p) More...

static const bool	isochoric
	Is the equation of state is isochoric i.e. rho = const. More...

Detailed Description

Wrapper class providing run-time selection of thermophysicalProperties for the templated thermodynamics packages.

Source files

Definition at line 51 of file liquidPropertiesSelector.H.

Constructor & Destructor Documentation

◆ ~liquidPropertiesSelector()

virtual ~liquidPropertiesSelector ( )

inlinevirtual

Destructor.

Definition at line 66 of file liquidPropertiesSelector.H.

Member Function Documentation

◆ sigma()

Foam::scalar sigma	(	const scalar	p,
		const scalar	T
	)		const

inlinevirtual

Surface tension [N/m].

Definition at line 30 of file liquidPropertiesSelectorI.H.

References p, thermophysicalPropertiesSelector< liquidProperties >::properties(), liquidProperties::sigma(), and Foam::T().

Here is the call graph for this function:

◆ mu()

Foam::scalar mu	(	const scalar	p,
		const scalar	T
	)		const

inline

Viscosity [Pa s].

Definition at line 40 of file liquidPropertiesSelectorI.H.

References p, and Foam::T().
