Public Member Functions | Friends | List of all members
lduMesh Class Referenceabstract

Abstract base class for meshes which provide LDU addressing for the construction of lduMatrix and LDU-solvers. More...

Inheritance diagram for lduMesh:
Inheritance graph
[legend]

Public Member Functions

 TypeName ("lduMesh")
 Runtime type information. More...

virtual ~lduMesh ()
 Destructor. More...

virtual const objectRegistry & thisDb () const
 Return the object registry. More...

virtual const lduAddressing & lduAddr () const =0
 Return ldu addressing. More...

virtual lduInterfacePtrsList interfaces () const =0
 Return a list of pointers for each patch. More...

virtual label comm () const =0
 Return communicator used for parallel communication. More...

template<class T , class BinaryOp >
void reduce (T &Value, const BinaryOp &bop) const
 Helper: reduce with current communicator. More...

InfoProxy< lduMesh > info () const
 Return info proxy. More...


Friends

Ostream & operator<< (Ostream &, const InfoProxy< lduMesh > &)


Detailed Description

Abstract base class for meshes which provide LDU addressing for the construction of lduMatrix and LDU-solvers.

Definition at line 59 of file lduMesh.H.

Constructor & Destructor Documentation

◆ ~lduMesh()

virtual ~lduMesh ( )
inlinevirtual

Destructor.

Definition at line 71 of file lduMesh.H.

Member Function Documentation

◆ TypeName()

TypeName ( "lduMesh"  )

Runtime type information.

◆ thisDb()

const Foam::objectRegistry & thisDb ( ) const
virtual

Return the object registry.

Reimplemented in fvMesh.

Definition at line 40 of file lduMesh.C.

References NotImplemented.

◆ lduAddr()

virtual const lduAddressing& lduAddr ( ) const
pure virtual

Return ldu addressing.

Implemented in lduPrimitiveMesh, and fvMesh.

Referenced by GAMGAgglomeration::agglomerateLduAddressing(), GAMGAgglomeration::compactLevels(), dummyAgglomeration::dummyAgglomeration(), LduMatrix< Type, DType, LUType >::lduAddr(), lduMatrix::lduAddr(), lduPrimitiveMesh::lduPrimitiveMesh(), MGridGenGAMGAgglomeration::MGridGenGAMGAgglomeration(), and Foam::operator<<().

Here is the caller graph for this function:

◆ interfaces()

virtual lduInterfacePtrsList interfaces ( ) const
pure virtual

Return a list of pointers for each patch.

with only those pointing to interfaces being set

Implemented in lduPrimitiveMesh, and fvMesh.

Referenced by GAMGAgglomeration::compactLevels(), lduPrimitiveMesh::lduPrimitiveMesh(), MGridGenGAMGAgglomeration::MGridGenGAMGAgglomeration(), and Foam::operator<<().

Here is the caller graph for this function:

◆ comm()

virtual label comm ( ) const
pure virtual

Return communicator used for parallel communication.

Implemented in lduPrimitiveMesh, and fvMesh.

Referenced by eagerGAMGProcAgglomeration::agglomerate(), manualGAMGProcAgglomeration::agglomerate(), masterCoarsestGAMGProcAgglomeration::agglomerate(), procFacesGAMGProcAgglomeration::agglomerate(), GAMGProcAgglomeration::agglomerate(), GAMGAgglomeration::agglomerateLduAddressing(), lduPrimitiveMesh::lduPrimitiveMesh(), Foam::operator<<(), and lduMesh::reduce().

Here is the caller graph for this function:

◆ reduce()

void reduce ( T &  Value,
const BinaryOp &  bop
) const

Helper: reduce with current communicator.

Definition at line 31 of file lduMeshTemplates.C.

References lduMesh::comm(), UPstream::msgType(), and Foam::reduce().

Here is the call graph for this function:

◆ info()

InfoProxy<lduMesh> info ( ) const
inline

Return info proxy.

Used to print mesh information to a stream

Definition at line 105 of file lduMesh.H.

Referenced by GAMGProcAgglomeration::printStats().

Here is the caller graph for this function:

Friends And Related Function Documentation

◆ operator<<

Ostream& operator<< ( Ostream &  ,
const InfoProxy< lduMesh > &
)
friend
The documentation for this class was generated from the following files:
