Fourier's temperature gradient heat flux model for single specie laminar flow. More...

Inheritance diagram for Fourier< BasicThermophysicalTransportModel >:

Collaboration diagram for Fourier< BasicThermophysicalTransportModel >:

Public Types
typedef BasicThermophysicalTransportModel::alphaField	alphaField

typedef BasicThermophysicalTransportModel::momentumTransportModel	momentumTransportModel

typedef BasicThermophysicalTransportModel::thermoModel	thermoModel

Public Types inherited from laminarThermophysicalTransportModel< BasicThermophysicalTransportModel >
typedef BasicThermophysicalTransportModel::alphaField	alphaField

typedef BasicThermophysicalTransportModel::momentumTransportModel	momentumTransportModel

typedef BasicThermophysicalTransportModel::thermoModel	thermoModel

Public Member Functions
	TypeName ("Fourier")
	Runtime type information. More...

	Fourier (const momentumTransportModel &momentumTransport, const thermoModel &thermo)
	Construct from components. More...

virtual	~Fourier ()
	Destructor. More...

virtual bool	read ()
	Read thermophysicalTransport dictionary. More...

virtual tmp< volScalarField >	DEff (const volScalarField &Yi) const
	Effective mass diffusion coefficient. More...

virtual tmp< scalarField >	DEff (const volScalarField &Yi, const label patchi) const
	Effective mass diffusion coefficient. More...

virtual tmp< surfaceScalarField >	q () const
	Return the heat flux [W/m^2]. More...

virtual tmp< scalarField >	q (const label patchi) const
	Return the patch heat flux [W/m^2]. More...

virtual tmp< fvScalarMatrix >	divq (volScalarField &he) const
	Return the source term for the energy equation. More...

virtual tmp< surfaceScalarField >	j (const volScalarField &Yi) const
	Return the specie flux for the given specie mass-fraction [kg/m^2/s]. More...

virtual tmp< scalarField >	j (const volScalarField &Yi, const label patchi) const
	Return the specie flux. More...

virtual tmp< fvScalarMatrix >	divj (volScalarField &Yi) const
	Return the source term for the given specie mass-fraction equation. More...

virtual void	predict ()
	Correct the Fourier viscosity. More...

Public Member Functions inherited from laminarThermophysicalTransportModel< BasicThermophysicalTransportModel >
	TypeName ("laminar")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, laminarThermophysicalTransportModel, dictionary,(const momentumTransportModel &momentumTransport, const thermoModel &thermo),(momentumTransport, thermo))

	laminarThermophysicalTransportModel (const word &type, const momentumTransportModel &momentumTransport, const thermoModel &thermo)
	Construct from components. More...

	laminarThermophysicalTransportModel (const laminarThermophysicalTransportModel &)=delete
	Disallow default bitwise copy construction. More...

virtual	~laminarThermophysicalTransportModel ()
	Destructor. More...

virtual tmp< volScalarField >	kappaEff () const
	Effective thermal turbulent conductivity. More...

virtual tmp< scalarField >	kappaEff (const label patchi) const
	Effective thermal turbulent conductivity. More...

virtual tmp< scalarField >	alphaEff (const label patchi) const
	Effective thermal turbulent diffusivity. More...

virtual void	correct ()
	Solve the thermophysical transport model equations. More...

void	operator= (const laminarThermophysicalTransportModel &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Static Public Member Functions inherited from laminarThermophysicalTransportModel< BasicThermophysicalTransportModel >
static autoPtr< laminarThermophysicalTransportModel >	New (const momentumTransportModel &momentumTransport, const thermoModel &thermo)
	Return a reference to the selected laminar model. More...

Protected Member Functions inherited from laminarThermophysicalTransportModel< BasicThermophysicalTransportModel >
const dictionary &	coeffDict () const
	Const access to the coefficients dictionary. More...

tmp< volScalarField >	alphaEff () const
	Effective thermal turbulent diffusivity of mixture [kg/m/s]. More...

Detailed Description

template<class BasicThermophysicalTransportModel>
class Foam::laminarThermophysicalTransportModels::Fourier< BasicThermophysicalTransportModel >

Fourier's temperature gradient heat flux model for single specie laminar flow.

The heat flux source is implemented as an implicit energy correction to the temperature gradient based flux source. At convergence the energy correction is 0.

Source files

Definition at line 56 of file Fourier.H.

Member Typedef Documentation

◆ alphaField

typedef BasicThermophysicalTransportModel::alphaField alphaField

Definition at line 67 of file Fourier.H.

◆ momentumTransportModel

typedef BasicThermophysicalTransportModel::momentumTransportModel momentumTransportModel

Definition at line 70 of file Fourier.H.

◆ thermoModel

typedef BasicThermophysicalTransportModel::thermoModel thermoModel

Definition at line 73 of file Fourier.H.

Constructor & Destructor Documentation

◆ Fourier()

Fourier	(	const momentumTransportModel &	momentumTransport,
		const thermoModel &	thermo
	)

Construct from components.

Definition at line 40 of file Fourier.C.

◆ ~Fourier()

virtual ~Fourier ( )

inlinevirtual

Destructor.

Definition at line 91 of file Fourier.H.

Member Function Documentation

◆ TypeName()

TypeName ( "Fourier< BasicThermophysicalTransportModel >" )

Runtime type information.

◆ read()

bool read

virtual

Read thermophysicalTransport dictionary.

Reimplemented from laminarThermophysicalTransportModel< BasicThermophysicalTransportModel >.

Definition at line 58 of file Fourier.C.

◆ DEff() [1/2]

tmp< volScalarField > DEff ( const volScalarField & Yi ) const

virtual

Effective mass diffusion coefficient.

for a given specie mass-fraction [kg/m/s]

Implements laminarThermophysicalTransportModel< BasicThermophysicalTransportModel >.

Definition at line 66 of file Fourier.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::nl, and Foam::type().

Here is the call graph for this function:

◆ DEff() [2/2]

tmp< scalarField > DEff	(	const volScalarField &	Yi,
		const label	patchi
	)		const

virtual

Effective mass diffusion coefficient.

for a given specie mass-fraction for patch [kg/m/s]

Implements laminarThermophysicalTransportModel< BasicThermophysicalTransportModel >.

Definition at line 83 of file Fourier.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::nl, and Foam::type().

Here is the call graph for this function:

◆ q() [1/2]

tmp< surfaceScalarField > q

virtual

Return the heat flux [W/m^2].

Definition at line 100 of file Fourier.C.

References alpha(), Foam::constant::atomic::group, IOobject::groupName(), Foam::fvc::interpolate(), GeometricField< Type, GeoMesh, PrimitiveField >::New(), Foam::fvc::snGrad(), and thermo.

Here is the call graph for this function:

◆ q() [2/2]

tmp< scalarField > q ( const label patchi ) const

virtual

Return the patch heat flux [W/m^2].

Definition at line 117 of file Fourier.C.

References alpha(), patchi, and thermo.

Here is the call graph for this function:

◆ divq()

tmp< fvScalarMatrix > divq ( volScalarField & he ) const

virtual

Return the source term for the energy equation.

Definition at line 133 of file Fourier.C.

References alpha(), he(), Foam::fvc::laplacian(), Foam::fvm::laplacianCorrection(), and thermo.

Here is the call graph for this function:

◆ j() [1/2]

tmp< surfaceScalarField > j ( const volScalarField & Yi ) const

virtual

Return the specie flux for the given specie mass-fraction [kg/m^2/s].

Definition at line 150 of file Fourier.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::nl, and Foam::type().

Here is the call graph for this function:

◆ j() [2/2]

tmp< scalarField > j	(	const volScalarField &	Yi,
		const label	patchi
	)		const

virtual

Return the specie flux.

for the given specie mass-fraction for patch [kg/m^2/s]

Definition at line 166 of file Fourier.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::nl, and Foam::type().

Here is the call graph for this function:

◆ divj()

tmp< fvScalarMatrix > divj ( volScalarField & Yi ) const

virtual

Return the source term for the given specie mass-fraction equation.

Definition at line 184 of file Fourier.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::nl, and Foam::type().

Here is the call graph for this function:

◆ predict()

void predict

virtual

Correct the Fourier viscosity.

Reimplemented from laminarThermophysicalTransportModel< BasicThermophysicalTransportModel >.

Definition at line 197 of file Fourier.C.

The documentation for this class was generated from the following files:

src/ThermophysicalTransportModels/fluid/laminar/Fourier/Fourier.H
src/ThermophysicalTransportModels/fluid/laminar/Fourier/Fourier.C
