Low Reynolds-number k-kl-omega turbulence model for incompressible flows. More...

Inheritance diagram for kkLOmega:

Collaboration diagram for kkLOmega:

[legend]

Public Member Functions
	TypeName ("kkLOmega")
	Runtime type information. More...

	kkLOmega (const geometricOneField &alpha, const geometricOneField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity, const word &type=typeName)
	Construct from components. More...

virtual	~kkLOmega ()
	Destructor. More...

virtual bool	read ()
	Read RASProperties dictionary. More...

tmp< volScalarField >	DkEff (const volScalarField &alphaT) const
	Return the effective diffusivity for k. More...

tmp< volScalarField >	DomegaEff (const volScalarField &alphaT) const
	Return the effective diffusivity for omega. More...

virtual tmp< volScalarField >	kl () const
	Return the laminar kinetic energy. More...

virtual tmp< volScalarField >	kt () const
	Return the turbulence kinetic energy. More...

virtual tmp< volScalarField >	omega () const
	Return the turbulence specific dissipation rate. More...

virtual tmp< volScalarField >	k () const
	Return the total fluctuation kinetic energy. More...

virtual tmp< volScalarField >	epsilon () const
	Return the total fluctuation kinetic energy dissipation rate. More...

virtual void	validate ()
	Validate the turbulence fields after construction. More...

virtual void	correct ()
	Solve the turbulence equations and correct the turbulence viscosity. More...

Public Member Functions inherited from eddyViscosity< incompressible::RASModel >
	eddyViscosity (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)
	Construct from components. More...

virtual	~eddyViscosity ()
	Destructor. More...

virtual tmp< volScalarField >	nut () const
	Return the turbulence viscosity. More...

virtual tmp< scalarField >	nut (const label patchi) const
	Return the turbulence viscosity on patch. More...

virtual tmp< volSymmTensorField >	R () const
	Return the Reynolds stress tensor [m^2/s^2]. More...

Public Member Functions inherited from linearViscousStress< BasicMomentumTransportModel >
	linearViscousStress (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)
	Construct from components. More...

virtual	~linearViscousStress ()
	Destructor. More...

virtual tmp< surfaceVectorField >	devTau () const
	Return the effective surface stress. More...

virtual tmp< fvVectorMatrix >	divDevTau (volVectorField &U) const
	Return the source term for the momentum equation. More...

virtual tmp< fvVectorMatrix >	divDevTau (const volScalarField &rho, volVectorField &U) const
	Return the source term for the momentum equation. More...

template<class RhoFieldType >
Foam::tmp< Foam::fvVectorMatrix >	DivDevTau (const RhoFieldType &rho, volVectorField &U) const

Protected Member Functions
virtual void	correctNut ()

Protected Member Functions inherited from linearViscousStress< BasicMomentumTransportModel >
template<class RhoFieldType >
tmp< fvVectorMatrix >	DivDevTau (const RhoFieldType &rho, volVectorField &U) const
	Return the source term for the momentum equation. More...

Protected Attributes
dimensionedScalar	A0_

dimensionedScalar	As_

dimensionedScalar	Av_

dimensionedScalar	Abp_

dimensionedScalar	Anat_

dimensionedScalar	Ats_

dimensionedScalar	CbpCrit_

dimensionedScalar	Cnc_

dimensionedScalar	CnatCrit_

dimensionedScalar	Cint_

dimensionedScalar	CtsCrit_

dimensionedScalar	CrNat_

dimensionedScalar	C11_

dimensionedScalar	C12_

dimensionedScalar	CR_

dimensionedScalar	CalphaTheta_

dimensionedScalar	Css_

dimensionedScalar	CtauL_

dimensionedScalar	Cw1_

dimensionedScalar	Cw2_

dimensionedScalar	Cw3_

dimensionedScalar	CwR_

dimensionedScalar	Clambda_

dimensionedScalar	CmuStd_

dimensionedScalar	Prtheta_

dimensionedScalar	Sigmak_

dimensionedScalar	Sigmaw_

dimensionedScalar	omegaMin_
	Lower limit for omega. More...

volScalarField	kt_

volScalarField	kl_

volScalarField	omega_

volScalarField	epsilon_

Protected Attributes inherited from eddyViscosity< incompressible::RASModel >
volScalarField	nut_

Additional Inherited Members
Public Types inherited from eddyViscosity< incompressible::RASModel >
typedef BasicMomentumTransportModel::alphaField	alphaField

typedef BasicMomentumTransportModel::rhoField	rhoField

Public Types inherited from linearViscousStress< BasicMomentumTransportModel >
typedef BasicMomentumTransportModel::alphaField	alphaField

typedef BasicMomentumTransportModel::rhoField	rhoField

Detailed Description

Low Reynolds-number k-kl-omega turbulence model for incompressible flows.

This turbulence model is described in:

    Walters, D. K., & Cokljat, D. (2008).
    A three-equation eddy-viscosity model for Reynolds-averaged
    Navier–Stokes simulations of transitional flow.
    Journal of Fluids Engineering, 130(12), 121401.

corrected according to:

    Furst, J. (2013).
    Numerical simulation of transitional flows with laminar kinetic energy.
    Engineering Mechanics, 20(5), 379-388.

and includes the improvements proposed in:

    Lopez, M., and Keith Walters, D. (2016).
    A Recommended Correction to the kT−kL−ω Transition-Sensitive
    Eddy-Viscosity Model.
    Journal of Fluids Engineering, 139(2), 024501.

The default model coefficients are

    kkLOmegaCoeffs
    {
        A0             4.04
        As             2.12
        Av             6.75
        Abp            0.6
        Anat           200
        Ats            200
        CbpCrit        1.2
        Cnc            0.1
        CnatCrit       1250
        Cint           0.75
        CtsCrit        1000
        CrNat          0.02
        C11            3.4e-6
        C12            1.0e-10
        CR             0.12
        CalphaTheta    0.035
        Css            1.5
        CtauL          4360
        Cw1            0.44
        Cw2            0.92
        Cw3            0.3
        CwR            1.5
        Clambda        2.495
        CmuStd         0.09
        Prtheta        0.85
        Sigmak         1
        Sigmaw         1.17
    }

Source files

Definition at line 113 of file kkLOmega.H.

Constructor & Destructor Documentation

◆ kkLOmega()

kkLOmega	(	const geometricOneField &	alpha,
		const geometricOneField &	rho,
		const volVectorField &	U,
		const surfaceScalarField &	alphaRhoPhi,
		const surfaceScalarField &	phi,
		const viscosity &	viscosity,
		const word &	type = `typeName`
	)

Construct from components.

Referenced by makeMomentumTransportModelTypes().

Here is the caller graph for this function:

◆ ~kkLOmega()

virtual ~kkLOmega ( )

inlinevirtual

Destructor.

Definition at line 233 of file kkLOmega.H.

Member Function Documentation

◆ correctNut()

virtual void correctNut ( )

protectedvirtual

Implements eddyViscosity< incompressible::RASModel >.

Referenced by makeMomentumTransportModelTypes().

Here is the caller graph for this function:

◆ TypeName()

TypeName ( "kkLOmega" )

Runtime type information.

◆ read()

virtual bool read ( )

virtual

Read RASProperties dictionary.

Implements eddyViscosity< incompressible::RASModel >.

Referenced by makeMomentumTransportModelTypes().

Here is the caller graph for this function:

◆ DkEff()

tmp<volScalarField> DkEff ( const volScalarField & alphaT ) const

inline

Return the effective diffusivity for k.

Definition at line 243 of file kkLOmega.H.

References GeometricField< Type, GeoMesh, PrimitiveField >::New(), and kkLOmega::Sigmak_.

Referenced by makeMomentumTransportModelTypes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ DomegaEff()

tmp<volScalarField> DomegaEff ( const volScalarField & alphaT ) const

inline

Return the effective diffusivity for omega.

Definition at line 253 of file kkLOmega.H.

References GeometricField< Type, GeoMesh, PrimitiveField >::New(), and kkLOmega::Sigmaw_.

Referenced by makeMomentumTransportModelTypes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ kl()

virtual tmp<volScalarField> kl ( ) const

inlinevirtual

Return the laminar kinetic energy.

Definition at line 263 of file kkLOmega.H.

References kkLOmega::kl_.

◆ kt()

virtual tmp<volScalarField> kt ( ) const

inlinevirtual

Return the turbulence kinetic energy.

Definition at line 269 of file kkLOmega.H.

References kkLOmega::kt_.

◆ omega()

virtual tmp<volScalarField> omega ( ) const

inlinevirtual

Return the turbulence specific dissipation rate.

Definition at line 275 of file kkLOmega.H.

References kkLOmega::omega_.

◆ k()

virtual tmp<volScalarField> k ( ) const

inlinevirtual

Return the total fluctuation kinetic energy.

Implements eddyViscosity< incompressible::RASModel >.

Definition at line 281 of file kkLOmega.H.

References kkLOmega::kl_, kkLOmega::kt_, and GeometricField< Type, GeoMesh, PrimitiveField >::New().

Referenced by makeMomentumTransportModelTypes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ epsilon()

virtual tmp<volScalarField> epsilon ( ) const

inlinevirtual

Return the total fluctuation kinetic energy dissipation rate.

Definition at line 291 of file kkLOmega.H.

References kkLOmega::epsilon_.

◆ validate()

virtual void validate ( )

virtual

Validate the turbulence fields after construction.

Update turbulence viscosity and other derived fields as requires

Reimplemented from eddyViscosity< incompressible::RASModel >.

Referenced by makeMomentumTransportModelTypes().

Here is the caller graph for this function:

◆ correct()

virtual void correct ( )

virtual

Solve the turbulence equations and correct the turbulence viscosity.

Implements eddyViscosity< incompressible::RASModel >.

Referenced by makeMomentumTransportModelTypes().

Here is the caller graph for this function:

Member Data Documentation

◆ A0_

dimensionedScalar A0_

protected

Definition at line 166 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ As_

dimensionedScalar As_

protected

Definition at line 167 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ Av_

dimensionedScalar Av_

protected

Definition at line 168 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ Abp_

dimensionedScalar Abp_

protected

Definition at line 169 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ Anat_

dimensionedScalar Anat_

protected

Definition at line 170 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ Ats_

dimensionedScalar Ats_

protected

Definition at line 171 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ CbpCrit_

dimensionedScalar CbpCrit_

protected

Definition at line 172 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ Cnc_

dimensionedScalar Cnc_

protected

Definition at line 173 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ CnatCrit_

dimensionedScalar CnatCrit_

protected

Definition at line 174 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ Cint_

dimensionedScalar Cint_

protected

Definition at line 175 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ CtsCrit_

dimensionedScalar CtsCrit_

protected

Definition at line 176 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ CrNat_

dimensionedScalar CrNat_

protected

Definition at line 177 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ C11_

dimensionedScalar C11_

protected

Definition at line 178 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ C12_

dimensionedScalar C12_

protected

Definition at line 179 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ CR_

dimensionedScalar CR_

protected

Definition at line 180 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ CalphaTheta_

dimensionedScalar CalphaTheta_

protected

Definition at line 181 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ Css_

dimensionedScalar Css_

protected

Definition at line 182 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ CtauL_

dimensionedScalar CtauL_

protected

Definition at line 183 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ Cw1_

dimensionedScalar Cw1_

protected

Definition at line 184 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ Cw2_

dimensionedScalar Cw2_

protected

Definition at line 185 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ Cw3_

dimensionedScalar Cw3_

protected

Definition at line 186 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ CwR_

dimensionedScalar CwR_

protected

Definition at line 187 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ Clambda_

dimensionedScalar Clambda_

protected

Definition at line 188 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ CmuStd_

dimensionedScalar CmuStd_

protected

Definition at line 189 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ Prtheta_

dimensionedScalar Prtheta_

protected

Definition at line 190 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ Sigmak_

dimensionedScalar Sigmak_

protected

Definition at line 191 of file kkLOmega.H.

Referenced by kkLOmega::DkEff(), and makeMomentumTransportModelTypes().

◆ Sigmaw_

dimensionedScalar Sigmaw_

protected

Definition at line 192 of file kkLOmega.H.

Referenced by kkLOmega::DomegaEff(), and makeMomentumTransportModelTypes().

◆ omegaMin_

dimensionedScalar omegaMin_

protected

Lower limit for omega.

Definition at line 195 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes().

◆ kt_

volScalarField kt_

protected

Definition at line 200 of file kkLOmega.H.

Referenced by kkLOmega::k(), kkLOmega::kt(), and makeMomentumTransportModelTypes().

◆ kl_

volScalarField kl_

protected

Definition at line 201 of file kkLOmega.H.

Referenced by kkLOmega::k(), kkLOmega::kl(), and makeMomentumTransportModelTypes().

◆ omega_

volScalarField omega_

protected

Definition at line 202 of file kkLOmega.H.

Referenced by makeMomentumTransportModelTypes(), and kkLOmega::omega().

◆ epsilon_

volScalarField epsilon_

protected

Definition at line 203 of file kkLOmega.H.

Referenced by kkLOmega::epsilon(), and makeMomentumTransportModelTypes().

The documentation for this class was generated from the following file:

src/MomentumTransportModels/incompressible/RAS/kkLOmega/kkLOmega.H

Public Member Functions

Protected Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ kkLOmega()

◆ ~kkLOmega()

Member Function Documentation

◆ correctNut()

◆ TypeName()

◆ read()

◆ DkEff()

◆ DomegaEff()

◆ kl()

◆ kt()

◆ omega()

◆ k()

◆ epsilon()

◆ validate()

◆ correct()

Member Data Documentation

◆ A0_

◆ As_

◆ Av_

◆ Abp_

◆ Anat_

◆ Ats_

◆ CbpCrit_

◆ Cnc_

◆ CnatCrit_

◆ Cint_

◆ CtsCrit_

◆ CrNat_

◆ C11_

◆ C12_

◆ CR_

◆ CalphaTheta_

◆ Css_

◆ CtauL_

◆ Cw1_

◆ Cw2_

◆ Cw3_

◆ CwR_

◆ Clambda_

◆ CmuStd_

◆ Prtheta_

◆ Sigmak_

◆ Sigmaw_

◆ omegaMin_

◆ kt_

◆ kl_

◆ omega_

◆ epsilon_
