hexRef8Data Class Reference

Various for reading/decomposing/reconstructing/distributing refinement data. More...

Public Member Functions
	hexRef8Data (const IOobject &io)
	Construct read. Has special provision for only some processors. More...
	hexRef8Data (const IOobject &io, const hexRef8Data &, const labelList &cellMap, const labelList &pointMap)
	Construct as subset. More...
	hexRef8Data (const IOobject &io, const UPtrList< const labelList > &cellMaps, const UPtrList< const labelList > &pointMaps, const UPtrList< const hexRef8Data > &)
	Construct from multiple hexRef8Data. More...
	hexRef8Data (const hexRef8Data &)=delete
	Disallow default bitwise copy construction. More...
	~hexRef8Data ()
	Destructor. More...
void	sync (const IOobject &io)
	Parallel synchronise. This enforces valid objects on all processors. More...
void	topoChange (const polyTopoChangeMap &)
	In-place update for topology changes. More...
void	distribute (const polyDistributionMap &)
	In-place distribute. More...
bool	write () const
	Write. More...
void	operator= (const hexRef8Data &)=delete
	Disallow default bitwise assignment. More...

Detailed Description

Various for reading/decomposing/reconstructing/distributing refinement data.

Source files

• hexRef8Data.H
• hexRef8Data.C

Definition at line 57 of file hexRef8Data.H.

Constructor & Destructor Documentation

hexRef8Data() [1/4]

hexRef8Data

(

const IOobject &

io

)

Construct read. Has special provision for only some processors.

having the files so can be used in redistribution.

Definition at line 40 of file hexRef8Data.C.

References Foam::endl(), typeIOobject< Type >::headerOk(), Foam::Info, IOobject::name(), IOobject::rename(), and Foam::returnReduce().

Here is the call graph for this function:

hexRef8Data() [2/4]

hexRef8Data	(	const IOobject &	io,
		const hexRef8Data &	data,
		const labelList &	cellMap,
		const labelList &	pointMap
	)

Construct as subset.

Definition at line 117 of file hexRef8Data.C.

References IOobject::rename().

Here is the call graph for this function:

hexRef8Data() [3/4]

hexRef8Data	(	const IOobject &	io,
		const UPtrList< const labelList > &	cellMaps,
		const UPtrList< const labelList > &	pointMaps,
		const UPtrList< const hexRef8Data > &	procDatas
	)

Construct from multiple hexRef8Data.

Definition at line 173 of file hexRef8Data.C.

References IOobject::db(), forAll, mesh, Foam::name(), primitiveMesh::nCells(), primitiveMesh::nPoints(), IOobject::rename(), UPtrList< T >::set(), and UPtrList< T >::size().

Here is the call graph for this function:

hexRef8Data() [4/4]

hexRef8Data ( const hexRef8Data &  )

delete

Disallow default bitwise copy construction.

~hexRef8Data()

~hexRef8Data

(

)

Destructor.

Definition at line 265 of file hexRef8Data.C.

Member Function Documentation

sync()

void sync

(

const IOobject &

io

)

Parallel synchronise. This enforces valid objects on all processors.

(even if they don't have a mesh). Used by redistributePar.

Definition at line 271 of file hexRef8Data.C.

References IOobject::db(), Foam::dimLength, mesh, primitiveMesh::nCells(), IOobject::NO_READ, primitiveMesh::nPoints(), IOobject::readOpt(), IOobject::rename(), Foam::returnReduce(), and Pstream::scatter().

Here is the call graph for this function:

topoChange()

void topoChange

(

const polyTopoChangeMap &

map

)

In-place update for topology changes.

Definition at line 329 of file hexRef8Data.C.

References polyTopoChangeMap::cellMap(), polyMesh::facesInstance(), polyTopoChangeMap::mesh(), and polyTopoChangeMap::pointMap().

Here is the call graph for this function:

distribute()

void distribute

(

const polyDistributionMap &

map

)

In-place distribute.

Definition at line 352 of file hexRef8Data.C.

References polyDistributionMap::cellMap(), distributionMap::distribute(), and polyDistributionMap::pointMap().

Here is the call graph for this function:

write()

bool write

(

)

const

Write.

Definition at line 372 of file hexRef8Data.C.

Referenced by domainDecomposition::writeComplete(), and domainDecomposition::writeProcs().

Here is the caller graph for this function:

operator=()

void operator= ( const hexRef8Data &  )

delete

Disallow default bitwise assignment.

---

The documentation for this class was generated from the following files:

• src/polyTopoChange/polyTopoChange/hexRef8/hexRef8Data.H
• src/polyTopoChange/polyTopoChange/hexRef8/hexRef8Data.C
