hPowerThermo< EquationOfState > Class Template Reference

Enthalpy based thermodynamics package using a power function of temperature for the constant heat capacity at constant volume which is particularly suitable for solids at low temperatures: More...

Inheritance diagram for hPowerThermo< EquationOfState >:
Inheritance graph
[legend]
Collaboration diagram for hPowerThermo< EquationOfState >:
Collaboration graph
[legend]

Public Member Functions

 hPowerThermo (const EquationOfState &st, const scalar c0, const scalar n0, const scalar Tref, const scalar hf)
 Construct from components. More...

 hPowerThermo (const word &name, const dictionary &dict)
 Construct from name and dictionary. More...

 hPowerThermo (const word &, const hPowerThermo &)
 Construct as a named copy. More...

autoPtr< hPowerThermo > clone () const
 Construct and return a clone. More...

scalar limit (const scalar T) const
 Limit the temperature to be in the range Tlow_ to Thigh_. More...

scalar Cp (const scalar p, const scalar T) const
 Heat capacity at constant pressure [J/kg/K]. More...

scalar ha (const scalar p, const scalar T) const
 Absolute enthalpy [J/kg]. More...

scalar hs (const scalar p, const scalar T) const
 Sensible enthalpy [J/kg]. More...

scalar hf () const
 Enthalpy of formation [J/kg]. More...

scalar s (const scalar p, const scalar T) const
 Entropy [J/kg/K]. More...

scalar gStd (const scalar T) const
 Gibbs free energy of the mixture in the standard state [J/kg]. More...

scalar dCpdT (const scalar p, const scalar T) const
 Temperature derivative of heat capacity at constant pressure. More...

void operator+= (const hPowerThermo &)


Static Public Member Functions

static word typeName ()
 Return the instantiated type name. More...


Friends

hPowerThermo operator+ (const hPowerThermo &, const hPowerThermo &)

hPowerThermo operator* (const scalar, const hPowerThermo &)

hPowerThermo operator== (const hPowerThermo &, const hPowerThermo &)

Ostream & operator (Ostream &, const hPowerThermo &)


Detailed Description

template<class EquationOfState>
class Foam::hPowerThermo< EquationOfState >

Enthalpy based thermodynamics package using a power function of temperature for the constant heat capacity at constant volume which is particularly suitable for solids at low temperatures:

    Cp = c0*pow(T/Tref, n0)
Usage
Property Description
c0 Reference heat capacity at constant pressure [J/kg/K]
n0 Exponent of the power function
Tref Reference temperature [K]
hf Heat of formation [J/kg]

Example specification of hPowerThermo:

    thermodynamics
    {
        c0          230;
        Tref        470;
        n0          3;
        hf          0;
    }
Source files

Definition at line 126 of file hPowerThermo.H.

Constructor & Destructor Documentation

◆ hPowerThermo() [1/3]

hPowerThermo ( const EquationOfState &  st,
const scalar  c0,
const scalar  n0,
const scalar  Tref,
const scalar  hf
)
inline

Construct from components.

Definition at line 50 of file hPowerThermoI.H.

◆ hPowerThermo() [2/3]

hPowerThermo ( const word &  name,
const dictionary &  dict
)

Construct from name and dictionary.

Definition at line 32 of file hPowerThermo.C.

◆ hPowerThermo() [3/3]

hPowerThermo ( const word &  name,
const hPowerThermo< EquationOfState > &  jt
)
inline

Construct as a named copy.

Definition at line 68 of file hPowerThermoI.H.

Member Function Documentation

◆ clone()

Foam::autoPtr< Foam::hPowerThermo< EquationOfState > > clone
inline

Construct and return a clone.

Definition at line 84 of file hPowerThermoI.H.

◆ typeName()

static word typeName ( )
inlinestatic

Return the instantiated type name.

Definition at line 175 of file hPowerThermo.H.

◆ limit()

Foam::scalar limit ( const scalar  T) const
inline

Limit the temperature to be in the range Tlow_ to Thigh_.

Definition at line 96 of file hPowerThermoI.H.

References Foam::T().

Here is the call graph for this function:

◆ Cp()

Foam::scalar Cp ( const scalar  p,
const scalar  T
) const
inline

Heat capacity at constant pressure [J/kg/K].

Definition at line 106 of file hPowerThermoI.H.

References Cp(), p, Foam::pow(), and Foam::T().

Here is the call graph for this function:

◆ ha()

Foam::scalar ha ( const scalar  p,
const scalar  T
) const
inline

Absolute enthalpy [J/kg].

Definition at line 130 of file hPowerThermoI.H.

References hs(), p, and Foam::T().

Here is the call graph for this function:

◆ hs()

Foam::scalar hs ( const scalar  p,
const scalar  T
) const
inline

Sensible enthalpy [J/kg].

Definition at line 117 of file hPowerThermoI.H.

References Foam::constant::universal::h, p, Foam::pow(), Foam::T(), and Foam::constant::standard::Tstd.

Here is the call graph for this function:

◆ hf()

Foam::scalar hf
inline

Enthalpy of formation [J/kg].

Definition at line 141 of file hPowerThermoI.H.

◆ s()

Foam::scalar s ( const scalar  p,
const scalar  T
) const
inline

Entropy [J/kg/K].

Definition at line 148 of file hPowerThermoI.H.

References p, Foam::pow(), Foam::T(), and Foam::constant::standard::Tstd.

Here is the call graph for this function:

◆ gStd()

Foam::scalar gStd ( const scalar  T) const
inline

Gibbs free energy of the mixture in the standard state [J/kg].

Definition at line 161 of file hPowerThermoI.H.

References Foam::pow(), Foam::T(), and Foam::constant::standard::Tstd.

Here is the call graph for this function:

◆ dCpdT()

Foam::scalar dCpdT ( const scalar  p,
const scalar  T
) const
inline

Temperature derivative of heat capacity at constant pressure.

Definition at line 174 of file hPowerThermoI.H.

References NotImplemented.

◆ operator+=()

void operator+= ( const hPowerThermo< EquationOfState > &  )
inline

Definition at line 189 of file hPowerThermoI.H.

References Foam::mag(), Foam::operator+=(), and Y.

Here is the call graph for this function:

Friends And Related Function Documentation

◆ operator+

hPowerThermo operator+ ( const hPowerThermo< EquationOfState > &  ,
const hPowerThermo< EquationOfState > &
)
friend

◆ operator*

hPowerThermo operator* ( const  scalar,
const hPowerThermo< EquationOfState > &
)
friend

◆ operator==

hPowerThermo operator== ( const hPowerThermo< EquationOfState > &  ,
const hPowerThermo< EquationOfState > &
)
friend

◆ operator

Ostream& operator ( Ostream &  ,
const hPowerThermo< EquationOfState > &
)
friend
The documentation for this class was generated from the following files:
