This boundary condition provides a grey-diffuse condition for radiation intensity, I, for use with the finite-volume discrete-ordinates model (fvDOM), in which the radiation temperature is retrieved from the temperature field boundary condition. More...

Inheritance diagram for greyDiffusiveRadiationMixedFvPatchScalarField:

[legend]

Collaboration diagram for greyDiffusiveRadiationMixedFvPatchScalarField:

[legend]

Public Member Functions
	TypeName ("greyDiffusiveRadiation")
	Runtime type information. More...

	greyDiffusiveRadiationMixedFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
	Construct from patch, internal field and dictionary. More...

	greyDiffusiveRadiationMixedFvPatchScalarField (const greyDiffusiveRadiationMixedFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fieldMapper &)
	Construct by mapping given a. More...

	greyDiffusiveRadiationMixedFvPatchScalarField (const greyDiffusiveRadiationMixedFvPatchScalarField &)=delete
	Disallow copy without setting internal field reference. More...

	greyDiffusiveRadiationMixedFvPatchScalarField (const greyDiffusiveRadiationMixedFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
	Copy constructor setting internal field reference. More...

virtual tmp< fvPatchScalarField >	clone (const DimensionedField< scalar, volMesh > &iF) const
	Construct and return a clone setting internal field reference. More...

const word &	TName () const
	Return the temperature field name. More...

word &	TName ()
	Return reference to the temperature field name to allow. More...

virtual void	map (const fvPatchScalarField &, const fieldMapper &)
	Map the given fvPatchField onto this fvPatchField. More...

virtual void	reset (const fvPatchScalarField &)
	Reset the fvPatchField to the given fvPatchField. More...

virtual void	updateCoeffs ()
	Update the coefficients associated with the patch field. More...

virtual void	write (Ostream &) const
	Write. More...

Public Member Functions inherited from radiationCoupledBase
	TypeName ("radiationCoupledBase")
	Runtime type information. More...

	radiationCoupledBase (const fvPatch &patch, const word &calculationMethod, const scalarField &emissivity)
	Construct from patch, emissivity mode and emissivity. More...

	radiationCoupledBase (const fvPatch &patch, const word &calculationMethod, const scalarField &emissivity, const fieldMapper &mapper)
	Construct from patch, emissivity mode and emissivity and mapper. More...

	radiationCoupledBase (const fvPatch &patch, const dictionary &dict)
	Construct from patch and dictionary. More...

virtual	~radiationCoupledBase ()
	Destructor. More...

word	emissivityMethod () const
	Method to obtain emissivity. More...

tmp< scalarField >	emissivity () const
	Calculate corresponding emissivity field. More...

void	write (Ostream &) const
	Write. More...

Additional Inherited Members
Public Types inherited from radiationCoupledBase
enum	emissivityMethodType { SOLIDRADIATION , LOOKUP }
	Emissivity methods. More...

Static Public Attributes inherited from radiationCoupledBase
static const NamedEnum< emissivityMethodType, 2 >	emissivityMethodTypeNames_
	Names of emissivity methods. More...

Protected Attributes inherited from radiationCoupledBase
const emissivityMethodType	method_
	How to get emissivity. More...

scalarField	emissivity_
	Emissivity. Cached locally when looked up. More...

Detailed Description

This boundary condition provides a grey-diffuse condition for radiation intensity, I, for use with the finite-volume discrete-ordinates model (fvDOM), in which the radiation temperature is retrieved from the temperature field boundary condition.

Usage

Property	Description	Required	Default value
`T`	temperature field name	no	T
`emissivityMode`	emissivity mode: solidRadiation or lookup	yes

Example of the boundary condition specification:

    <patchName>
    {
        type            greyDiffusiveRadiation;
        T               T;
        emissivityMode  solidRadiation;
        value           uniform 0;
    }

See also: Foam::radiationCoupledBase Foam::radiationModel Foam::radiationModels::fvDOM Foam::mixedFvPatchField

Source files

Definition at line 91 of file greyDiffusiveRadiationMixedFvPatchScalarField.H.

Constructor & Destructor Documentation

◆ greyDiffusiveRadiationMixedFvPatchScalarField() [1/4]

greyDiffusiveRadiationMixedFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const dictionary &	dict
	)

Construct from patch, internal field and dictionary.

Definition at line 39 of file greyDiffusiveRadiationMixedFvPatchScalarField.C.

References dict, DimensionedField< Type, GeoMesh, PrimitiveField >::dimensions(), Foam::dimLength, fvPatchField< Type >::operator, fvPatchField< Type >::operator=(), p, and Foam::unitFraction.

Referenced by greyDiffusiveRadiationMixedFvPatchScalarField::clone().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ greyDiffusiveRadiationMixedFvPatchScalarField() [2/4]

greyDiffusiveRadiationMixedFvPatchScalarField	(	const greyDiffusiveRadiationMixedFvPatchScalarField &	ptf,
		const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const fieldMapper &	mapper
	)

Construct by mapping given a.

greyDiffusiveRadiationMixedFvPatchScalarField onto a new patch

Definition at line 81 of file greyDiffusiveRadiationMixedFvPatchScalarField.C.

◆ greyDiffusiveRadiationMixedFvPatchScalarField() [3/4]

greyDiffusiveRadiationMixedFvPatchScalarField ( const greyDiffusiveRadiationMixedFvPatchScalarField & )

delete

Disallow copy without setting internal field reference.

◆ greyDiffusiveRadiationMixedFvPatchScalarField() [4/4]

greyDiffusiveRadiationMixedFvPatchScalarField	(	const greyDiffusiveRadiationMixedFvPatchScalarField &	ptf,
		const DimensionedField< scalar, volMesh > &	iF
	)
