gradientUnburntEnthalpyFvPatchScalarField Class Reference

gradient boundary condition for unburnt More...

Inheritance diagram for gradientUnburntEnthalpyFvPatchScalarField:

Collaboration diagram for gradientUnburntEnthalpyFvPatchScalarField:

Public Member Functions
	TypeName ("gradientUnburntEnthalpy")
	Runtime type information. More...
	gradientUnburntEnthalpyFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &)
	Construct from patch and internal field. More...
	gradientUnburntEnthalpyFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
	Construct from patch, internal field and dictionary. More...
	gradientUnburntEnthalpyFvPatchScalarField (const gradientUnburntEnthalpyFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fieldMapper &)
	Construct by mapping given gradientUnburntEnthalpyFvPatchScalarField. More...
	gradientUnburntEnthalpyFvPatchScalarField (const gradientUnburntEnthalpyFvPatchScalarField &)=delete
	Disallow copy without setting internal field reference. More...
	gradientUnburntEnthalpyFvPatchScalarField (const gradientUnburntEnthalpyFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
	Copy constructor setting internal field reference. More...
virtual tmp< fvPatchScalarField >	clone (const DimensionedField< scalar, volMesh > &iF) const
	Construct and return a clone setting internal field reference. More...
void	map (const gradientUnburntEnthalpyFvPatchScalarField &, const fieldMapper &)
	Map the given fvPatchField onto this fvPatchField. More...
virtual void	map (const fvPatchScalarField &, const fieldMapper &)
	Map the given fvPatchField onto this fvPatchField. More...
virtual void	updateCoeffs ()
	Update the coefficients associated with the patch field. More...

Detailed Description

gradient boundary condition for unburnt

Source files

• gradientUnburntEnthalpyFvPatchScalarField.H
• gradientUnburntEnthalpyFvPatchScalarField.C

Definition at line 48 of file gradientUnburntEnthalpyFvPatchScalarField.H.

Constructor & Destructor Documentation

gradientUnburntEnthalpyFvPatchScalarField() [1/5]

gradientUnburntEnthalpyFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF
	)

Construct from patch and internal field.

Definition at line 33 of file gradientUnburntEnthalpyFvPatchScalarField.C.

Referenced by gradientUnburntEnthalpyFvPatchScalarField::clone().

Here is the caller graph for this function:

gradientUnburntEnthalpyFvPatchScalarField() [2/5]

gradientUnburntEnthalpyFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const dictionary &	dict
	)

Construct from patch, internal field and dictionary.

Definition at line 46 of file gradientUnburntEnthalpyFvPatchScalarField.C.

gradientUnburntEnthalpyFvPatchScalarField() [3/5]

gradientUnburntEnthalpyFvPatchScalarField	(	const gradientUnburntEnthalpyFvPatchScalarField &	ptf,
		const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const fieldMapper &	mapper
	)

Construct by mapping given gradientUnburntEnthalpyFvPatchScalarField.

onto a new patch

Definition at line 58 of file gradientUnburntEnthalpyFvPatchScalarField.C.

References gradientUnburntEnthalpyFvPatchScalarField::map().

Here is the call graph for this function:

gradientUnburntEnthalpyFvPatchScalarField() [4/5]

gradientUnburntEnthalpyFvPatchScalarField ( const gradientUnburntEnthalpyFvPatchScalarField &  )

delete

Disallow copy without setting internal field reference.

gradientUnburntEnthalpyFvPatchScalarField() [5/5]

gradientUnburntEnthalpyFvPatchScalarField	(	const gradientUnburntEnthalpyFvPatchScalarField &	tppsf,
		const DimensionedField< scalar, volMesh > &	iF
	)

Copy constructor setting internal field reference.

Definition at line 73 of file gradientUnburntEnthalpyFvPatchScalarField.C.

Member Function Documentation

TypeName()

TypeName

(

"gradientUnburntEnthalpy"

)

Runtime type information.

clone()

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, volMesh > &  iF ) const

inlinevirtual

Construct and return a clone setting internal field reference.

Definition at line 100 of file gradientUnburntEnthalpyFvPatchScalarField.H.

References gradientUnburntEnthalpyFvPatchScalarField::gradientUnburntEnthalpyFvPatchScalarField().

Here is the call graph for this function:

map() [1/2]

void map	(	const gradientUnburntEnthalpyFvPatchScalarField &	ptf,
		const fieldMapper &	mapper
	)

Map the given fvPatchField onto this fvPatchField.

Definition at line 86 of file gradientUnburntEnthalpyFvPatchScalarField.C.

Referenced by gradientUnburntEnthalpyFvPatchScalarField::gradientUnburntEnthalpyFvPatchScalarField().

Here is the caller graph for this function:

map() [2/2]

void map ( const fvPatchScalarField &  ptf, const fieldMapper &  mapper  )

virtual

Map the given fvPatchField onto this fvPatchField.

Definition at line 99 of file gradientUnburntEnthalpyFvPatchScalarField.C.

updateCoeffs()

void updateCoeffs ( )

virtual

Update the coefficients associated with the patch field.

Definition at line 109 of file gradientUnburntEnthalpyFvPatchScalarField.C.

References basicThermo::Cp(), fvPatchField< Type >::evaluate(), patchi, fvPatchField< Type >::snGrad(), and thermo.

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/thermophysicalModels/multicomponentThermo/derivedFvPatchFields/gradientUnburntEnthalpy/gradientUnburntEnthalpyFvPatchScalarField.H
• src/thermophysicalModels/multicomponentThermo/derivedFvPatchFields/gradientUnburntEnthalpy/gradientUnburntEnthalpyFvPatchScalarField.C
