Zero-dimensional fixed pressure constraint. Should be used in conjunction with the zeroDimensionalFixedPressureModel. More...

Inheritance diagram for zeroDimensionalFixedPressureConstraint:

[legend]

Collaboration diagram for zeroDimensionalFixedPressureConstraint:

[legend]

Public Member Functions
	TypeName ("zeroDimensionalFixedPressure")
	Runtime type information. More...

	zeroDimensionalFixedPressureConstraint (const word &name, const word &modelType, const fvMesh &mesh, const dictionary &dict)
	Construct from dictionary. More...

virtual	~zeroDimensionalFixedPressureConstraint ()
	Destructor. More...

const word &	pName () const
	Pressure field name. More...

const word &	rhoName () const
	Density field name. More...

virtual wordList	constrainedFields () const
	Return the list of fields constrained by the fvConstraint. More...

tmp< volScalarField::Internal >	pEqnSource (const volScalarField &rho, fvMatrix< scalar > &pEqn) const
	Return the mass or volume source for the pressure equation. More...

tmp< volScalarField::Internal >	massSource (const volScalarField::Internal &rho) const
	Return the mass source. More...

tmp< volScalarField::Internal >	massSource (const volScalarField::Internal &alpha, const volScalarField::Internal &rho) const
	Return the mass source for a given phase. More...

virtual bool	constrain (fvMatrix< scalar > &pEqn, const word &fieldName) const
	Apply the constraint to the pressure equation. More...

virtual bool	movePoints ()
	Update for mesh motion. More...

virtual void	topoChange (const polyTopoChangeMap &)
	Update topology using the given map. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

virtual void	distribute (const polyDistributionMap &)
	Redistribute or update using the given distribution map. More...

virtual bool	read (const dictionary &dict)
	Read dictionary. More...

template<class AlphaFieldType >
Foam::tmp< Foam::volScalarField::Internal >	massSource (const AlphaFieldType &alpha, const volScalarField::Internal &rho) const

Public Member Functions inherited from fvConstraint
	TypeName ("fvConstraint")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, fvConstraint, dictionary,(const word &name, const word &constraintType, const fvMesh &mesh, const dictionary &dict),(name, constraintType, mesh, dict))

	fvConstraint (const word &name, const word &constraintType, const fvMesh &mesh, const dictionary &dict)
	Construct from components. More...

autoPtr< fvConstraint >	clone () const
	Return clone. More...

virtual	~fvConstraint ()
	Destructor. More...

const word &	name () const
	Return const access to the source name. More...

const fvMesh &	mesh () const
	Return const access to the mesh database. More...

const dictionary &	coeffs (const dictionary &) const
	Return the coefficients sub-dictionary. More...

virtual bool	constrainsField (const word &fieldName) const
	Return true if the given field is constrained. More...

	FOR_ALL_FIELD_TYPES (DEFINE_FV_CONSTRAINT_CONSTRAIN)
	Apply a constraint to an equation. More...

	FOR_ALL_FIELD_TYPES (DEFINE_FV_CONSTRAINT_CONSTRAIN_FIELD)
	Apply constraint to a field. More...

Additional Inherited Members
Static Public Member Functions inherited from fvConstraint
static autoPtr< fvConstraint >	New (const word &name, const fvMesh &mesh, const dictionary &dict)
	Return a reference to the selected fvConstraint. More...

Detailed Description

Zero-dimensional fixed pressure constraint. Should be used in conjunction with the zeroDimensionalFixedPressureModel.

This constraint and model facilitates specification of a constant or time-varying pressure. It adds mass source terms proportional to the error that remains when the pressure equation is evaluated at the desired pressure. Iteration may be necessary to converge the constraint in the case of non-linear equations of state.

Properties are added or removed with their current value. The model therefore represents a uniform expansion or contraction in infinite space.

Usage

Example usage:

{
    type            zeroDimensionalFixedPressure;

    // Name of the pressure field, default = p
    //p               p;

    // Name of the density field, default = rho
    //rho             rho;

    // Pressure value
    pressure        1e5;
}

Definition at line 78 of file zeroDimensionalFixedPressureConstraint.H.
