Disk momentum source derived from Foam::fv::propellerDisk with support for motion of the body the propeller is attached to. More...

Inheritance diagram for rigidBodyPropellerDisk:

[legend]

Collaboration diagram for rigidBodyPropellerDisk:

[legend]

Public Member Functions
	TypeName ("rigidBodyPropellerDisk")
	Runtime type information. More...

	rigidBodyPropellerDisk (const word &name, const word &modelType, const fvMesh &mesh, const dictionary &dict)
	Construct from components. More...

	rigidBodyPropellerDisk (const rigidBodyPropellerDisk &)=delete
	Disallow default bitwise copy construction. More...

virtual	~rigidBodyPropellerDisk ()
	Destructor. More...

virtual vector	centre () const
	Return the current propeller centre. More...

label	bodyID () const

Public Member Functions inherited from propellerDisk
	TypeName ("propellerDisk")
	Runtime type information. More...

	propellerDisk (const word &name, const word &modelType, const fvMesh &mesh, const dictionary &dict)
	Construct from components. More...

	propellerDisk (const propellerDisk &)=delete
	Disallow default bitwise copy construction. More...

virtual	~propellerDisk ()
	Destructor. More...

vector	force () const
	Return the current force of the fluid on the propeller. More...

vector	moment () const
	Return the current moment of the fluid on the propeller. More...

virtual wordList	addSupFields () const
	Return the list of fields for which the fvModel adds source term. More...

virtual void	addSup (const volVectorField &U, fvMatrix< vector > &eqn) const
	Source term to momentum equation. More...

virtual void	addSup (const volScalarField &rho, const volVectorField &U, fvMatrix< vector > &eqn) const
	Source term to compressible momentum equation. More...

virtual void	addSup (const volScalarField &alpha, const volScalarField &rho, const volVectorField &U, fvMatrix< vector > &eqn) const
	Explicit and implicit sources for phase equations. More...

virtual bool	movePoints ()
	Update for mesh motion. More...

virtual void	topoChange (const polyTopoChangeMap &)
	Update topology using the given map. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

virtual void	distribute (const polyDistributionMap &)
	Redistribute or update using the given distribution map. More...

virtual bool	read (const dictionary &dict)
	Read dictionary. More...

void	operator= (const propellerDisk &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from fvModel
	TypeName ("fvModel")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, fvModel, dictionary,(const word &name, const word &modelType, const fvMesh &mesh, const dictionary &dict),(name, modelType, mesh, dict))

	fvModel (const word &name, const word &modelType, const fvMesh &mesh, const dictionary &dict)
	Construct from components. More...

autoPtr< fvModel >	clone () const
	Return clone. More...

virtual	~fvModel ()
	Destructor. More...

const word &	name () const
	Return const access to the source name. More...

const word &	keyword () const
	Return name as the keyword. More...

const fvMesh &	mesh () const
	Return const access to the mesh database. More...

const dictionary &	coeffs (const dictionary &) const
	Return the coefficients sub-dictionary. More...

virtual bool	addsSupToField (const word &fieldName) const
	Return true if the fvModel adds a source term to the given. More...

virtual scalar	maxDeltaT () const
	Return the maximum time-step for stable operation. More...

virtual void	addSup (fvMatrix< scalar > &eqn) const
	Add a source term to a field-less proxy equation. More...

template<class Type >
tmp< fvMatrix< Type > >	sourceProxy (const VolField< Type > &eqnField) const
	Add a source term to an equation. More...

template<class Type >
tmp< fvMatrix< Type > >	source (const VolField< Type > &field) const
	Return source for an equation. More...

template<class Type >
tmp< fvMatrix< Type > >	sourceProxy (const VolField< Type > &field, const VolField< Type > &eqnField) const
	Return source for an equation. More...

template<class Type >
tmp< fvMatrix< Type > >	source (const volScalarField &rho, const VolField< Type > &field) const
	Return source for a compressible equation. More...

template<class Type >
tmp< fvMatrix< Type > >	sourceProxy (const volScalarField &rho, const VolField< Type > &field, const VolField< Type > &eqnField) const
	Return source for a compressible equation. More...

template<class Type >
tmp< fvMatrix< Type > >	source (const volScalarField &alpha, const volScalarField &rho, const VolField< Type > &field) const
	Return source for a phase equation. More...

template<class Type >
tmp< fvMatrix< Type > >	sourceProxy (const volScalarField &alpha, const volScalarField &rho, const VolField< Type > &field, const VolField< Type > &eqnField) const
	Return source for a phase equation. More...

template<class Type >
tmp< fvMatrix< Type > >	source (const volScalarField &alpha, const geometricOneField &rho, const VolField< Type > &field) const
	Return source for a phase equation. More...

template<class Type >
tmp< fvMatrix< Type > >	source (const geometricOneField &alpha, const volScalarField &rho, const VolField< Type > &field) const
	Return source for a phase equation. More...

template<class Type >
tmp< fvMatrix< Type > >	source (const geometricOneField &alpha, const geometricOneField &rho, const VolField< Type > &field) const
	Return source for a phase equation. More...

template<class Type >
tmp< fvMatrix< Type > >	d2dt2 (const VolField< Type > &field) const
	Return source for an equation with a second time derivative. More...

virtual void	preUpdateMesh ()
	Prepare for mesh update. More...

virtual void	correct ()
	Correct the fvModel. More...

virtual bool	write (const bool write=true) const
	Write fvModel data. More...

template<class AlphaRhoFieldType , class ... AlphaRhoFieldTypes>
Foam::dimensionSet	sourceDims (const dimensionSet &ds, const AlphaRhoFieldType &alphaRhoField, const AlphaRhoFieldTypes &... alphaRhoFields)

template<class AlphaRhoFieldType , class ... AlphaRhoFieldTypes>
const Foam::word &	fieldName (const AlphaRhoFieldType &alphaRhoField, const AlphaRhoFieldTypes &... alphaRhoFields)

template<class AlphaRhoFieldType >
const Foam::word &	fieldName (const AlphaRhoFieldType &alphaRhoField)

template<class Type , class ... AlphaRhoFieldTypes>
Foam::tmp< Foam::fvMatrix< Type > >	sourceTerm (const VolField< Type > &eqnField, const dimensionSet &ds, const AlphaRhoFieldTypes &... alphaRhoFields) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	sourceProxy (const VolField< Type > &eqnField) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	source (const VolField< Type > &field) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	sourceProxy (const VolField< Type > &field, const VolField< Type > &eqnField) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	source (const volScalarField &rho, const VolField< Type > &field) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	sourceProxy (const volScalarField &rho, const VolField< Type > &field, const VolField< Type > &eqnField) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	source (const volScalarField &alpha, const volScalarField &rho, const VolField< Type > &field) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	sourceProxy (const volScalarField &alpha, const volScalarField &rho, const VolField< Type > &field, const VolField< Type > &eqnField) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	source (const geometricOneField &alpha, const geometricOneField &rho, const VolField< Type > &field) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	source (const volScalarField &alpha, const geometricOneField &rho, const VolField< Type > &field) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	source (const geometricOneField &alpha, const volScalarField &rho, const VolField< Type > &field) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	d2dt2 (const VolField< Type > &field) const

Protected Member Functions
virtual void	readCoeffs (const dictionary &dict)
	Read the model coefficients. More...

virtual vector	normal () const
	Return the current propeller normal. More...

Protected Member Functions inherited from propellerDisk
virtual scalar	n () const
	Return the rotation speed. More...

virtual void	correctn (const scalar T) const
	No rotation speed correction. More...

scalar	diskThickness (const vector &centre) const
	Computes the thickness of the disk in streamwise direction. More...

scalar	J (const vectorField &U, const vector &nHat) const
	Return the normalised flow-rate through the disk. More...

Protected Member Functions inherited from fvModel
template<class Type >
void	addSupType (const VolField< Type > &field, fvMatrix< Type > &eqn) const
	Add a source term to an equation. More...

template<class Type >
void	addSupType (const volScalarField &rho, const VolField< Type > &field, fvMatrix< Type > &eqn) const
	Add a source term to a compressible equation. More...

template<class Type >
void	addSupType (const volScalarField &alpha, const volScalarField &rho, const VolField< Type > &field, fvMatrix< Type > &eqn) const
	Add a source term to a phase equation. More...

template<class Type , class ... AlphaRhoFieldTypes>
tmp< fvMatrix< Type > >	sourceTerm (const VolField< Type > &eqnField, const dimensionSet &ds, const AlphaRhoFieldTypes &... alphaRhoFields) const
	Return a source for an equation. More...

Additional Inherited Members
Static Public Member Functions inherited from fvModel
static const dictionary &	coeffs (const word &modelType, const dictionary &)
	Return the coefficients sub-dictionary for a given model type. More...

template<class AlphaRhoFieldType , class ... AlphaRhoFieldTypes>
static dimensionSet	sourceDims (const dimensionSet &ds, const AlphaRhoFieldType &alphaRhoField, const AlphaRhoFieldTypes &... alphaRhoFields)
	Return the dimensions of the matrix of a source term. More...

static const dimensionSet &	sourceDims (const dimensionSet &ds)
	Return the dimensions of the matrix of a source term (base. More...

template<class AlphaRhoFieldType , class ... AlphaRhoFieldTypes>
static const word &	fieldName (const AlphaRhoFieldType &alphaRhoField, const AlphaRhoFieldTypes &... alphaRhoFields)
	Return the name of the field associated with a source term. More...

template<class AlphaRhoFieldType >
static const word &	fieldName (const AlphaRhoFieldType &alphaRhoField)
	Return the name of the field associated with a source term (base. More...

static const word &	fieldName ()
	Return the name of the field associated with a source term. Special. More...

static autoPtr< fvModel >	New (const word &name, const fvMesh &mesh, const dictionary &dict)
	Return a reference to the selected fvModel. More...

Static Public Attributes inherited from fvModel
static const wordHashSet	keywords
	The keywords read by this class. More...

Protected Attributes inherited from propellerDisk
fvCellZone	zone_
	The cellZone the fvConstraint applies to. More...

word	phaseName_
	The name of the phase to which this fvModel applies. More...

word	UName_
	Name of the velocity field. More...

vector	centre_
	Propeller disk centre. More...

vector	normal_
	Propeller disk normal direction. More...

scalar	n_
	Rotation speed [1/s]. More...

scalar	rotationDir_
	Rotation direction (obtained from the sign of n_) More...

scalar	dProp_
	Propeller diameter. More...

scalar	dHub_
	Hub diameter. More...

autoPtr< Function1< vector2D > >	propellerFunction_
	Propeller function. More...

autoPtr< volVectorField::Internal >	forcePtr_

vector	force_
	Current force of the fluid on the propeller. More...

vector	moment_
	Current moment of the fluid on the propeller. More...

Switch	log_
	Optional switch to enable logging of integral properties. More...

autoPtr< functionObjects::logFile >	logFile_
	Optional log file. More...

Detailed Description

Disk momentum source derived from Foam::fv::propellerDisk with support for motion of the body the propeller is attached to.

Usage

Example usage:

diskSource
{
    type            rigidBodyPropellerDisk;

    libs            ("librigidBodyPropellerDisk.so");

    cellZone        propeller;

    body            hull;

    centre          (0 0 0);    // Centre of the propeller
    normal          (1 0 0);    // Normal direction of the propeller

    n               26.03;      // Rotation speed [1/s]

    dPropeller      0.203;      // Propeller diameter
    dHub            0.039179;   // Hub diameter

    propellerCurve
    {
        type table;

        //   J     Kt     Kq
        values
        (
            (0.10 (0.3267 0.03748))
            (0.15 (0.3112 0.03629))
            (0.20 (0.2949 0.03500))
            (0.25 (0.2777 0.03361))
            (0.30 (0.2598 0.03210))
            (0.35 (0.2410 0.03047))
            (0.40 (0.2214 0.02871))
            (0.45 (0.2010 0.02682))
            (0.50 (0.1798 0.02479))
            (0.55 (0.1577 0.02261))
            (0.60 (0.1349 0.02027))
            (0.65 (0.1112 0.01777))
            (0.70 (0.0867 0.01509))
            (0.75 (0.0614 0.01224))
            (0.80 (0.0353 0.00921))
        );
    }
}

See also: Foam::fv::propellerDisk

Source files

Definition at line 104 of file rigidBodyPropellerDisk.H.

Constructor & Destructor Documentation

◆ rigidBodyPropellerDisk() [1/2]

rigidBodyPropellerDisk	(	const word &	name,
		const word &	modelType,
		const fvMesh &	mesh,
		const dictionary &	dict
	)

Construct from components.

Definition at line 80 of file rigidBodyPropellerDisk.C.

References fvModel::coeffs(), dict, and rigidBodyPropellerDisk::readCoeffs().

Here is the call graph for this function:

◆ rigidBodyPropellerDisk() [2/2]

rigidBodyPropellerDisk ( const rigidBodyPropellerDisk & )

delete

Disallow default bitwise copy construction.

◆ ~rigidBodyPropellerDisk()

virtual ~rigidBodyPropellerDisk ( )

inlinevirtual

Destructor.

Definition at line 152 of file rigidBodyPropellerDisk.H.

Member Function Documentation

◆ readCoeffs()

void readCoeffs ( const dictionary & dict )

protectedvirtual

Read the model coefficients.

Reimplemented from propellerDisk.

Definition at line 50 of file rigidBodyPropellerDisk.C.

References rigidBodyModel::bodyIndex(), dict, Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, and propellerDisk::readCoeffs().

Referenced by rigidBodyPropellerDisk::rigidBodyPropellerDisk().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ normal()

Foam::vector normal ( ) const

protectedvirtual

Return the current propeller normal.

Reimplemented from propellerDisk.

Definition at line 72 of file rigidBodyPropellerDisk.C.

◆ TypeName()

TypeName ( "rigidBodyPropellerDisk" )

Runtime type information.

◆ centre()

Foam::vector centre ( ) const

virtual

Return the current propeller centre.

Reimplemented from propellerDisk.

Definition at line 66 of file rigidBodyPropellerDisk.C.

Referenced by propellerDiskForce::restrain().

Here is the caller graph for this function:

◆ bodyID()

label bodyID ( ) const

inline

Definition at line 161 of file rigidBodyPropellerDisk.H.

Referenced by propellerDiskForce::restrain().

Here is the caller graph for this function:

The documentation for this class was generated from the following files:

src/fvModels/rigidBodyPropellerDisk/rigidBodyPropellerDisk.H
src/fvModels/rigidBodyPropellerDisk/rigidBodyPropellerDisk.C

Public Member Functions

Protected Member Functions

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ rigidBodyPropellerDisk() [1/2]

◆ rigidBodyPropellerDisk() [2/2]

◆ ~rigidBodyPropellerDisk()

Member Function Documentation

◆ readCoeffs()

◆ normal()

◆ TypeName()

◆ centre()

◆ bodyID()
