snGrad scheme with phase-fraction limited non-orthogonal correction. More...

Inheritance diagram for phaseStabilisedSnGrad< Type >:

Collaboration diagram for phaseStabilisedSnGrad< Type >:

Public Member Functions
	TypeName ("phaseStabilised")
	Runtime type information. More...

	phaseStabilisedSnGrad (const fvMesh &mesh, Istream &schemeData)
	Construct from mesh and data stream. More...

virtual	~phaseStabilisedSnGrad ()
	Destructor. More...

virtual tmp< surfaceScalarField >	deltaCoeffs (const VolField< Type > &vf) const
	Return the interpolation weighting factors for the given field. More...

virtual bool	corrected () const
	Return true if this scheme uses an explicit correction. More...

virtual tmp< SurfaceField< Type > >	correction (const VolField< Type > &) const
	Return the explicit correction to the phaseStabilisedSnGrad. More...

void	operator= (const phaseStabilisedSnGrad &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from snGradScheme< Type >
virtual const word &	type () const =0
	Runtime type information. More...

	declareRunTimeSelectionTable (tmp, snGradScheme, Mesh,(const fvMesh &mesh, Istream &schemeData),(mesh, schemeData))

	snGradScheme (const fvMesh &mesh)
	Construct from mesh. More...

	snGradScheme (const snGradScheme &)=delete
	Disallow default bitwise copy construction. More...

virtual	~snGradScheme ()
	Destructor. More...

const fvMesh &	mesh () const
	Return mesh reference. More...

virtual tmp< SurfaceField< Type > >	snGrad (const VolField< Type > &) const
	Return the snGrad of the given cell field. More...

tmp< SurfaceField< Type > >	snGrad (const tmp< VolField< Type >> &) const
	Return the snGrad of the given tmp cell field. More...

void	operator= (const snGradScheme &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from refCount
int	count () const
	Return the current reference count. More...

bool	unique () const
	Return true if the reference count is zero. More...

void	operator++ ()
	Increment the reference count. More...

void	operator++ (int)
	Increment the reference count. More...

void	operator-- ()
	Decrement the reference count. More...

void	operator-- (int)
	Decrement the reference count. More...

void	operator= (const refCount &)=delete
	Disallow bitwise assignment. More...

Additional Inherited Members
Static Public Member Functions inherited from snGradScheme< Type >
static tmp< snGradScheme< Type > >	New (const fvMesh &mesh, Istream &schemeData)
	Return new tmp interpolation scheme. More...

static tmp< SurfaceField< Type > >	snGrad (const VolField< Type > &, const tmp< surfaceScalarField > &, const word &snGradName="snGrad")
	Return the snGrad of the given cell field with the given deltaCoeffs. More...

static tmp< SurfaceField< Type > >	sndGrad (const VolField< Type > &, const word &snGradName="sndGrad")
	Return the sndGrad of the given cell field. More...

Protected Member Functions inherited from refCount
	refCount ()
	Construct null initialising count to 0. More...

	refCount (const refCount &)=delete
	Disallow copy. More...

Detailed Description

template<class Type>
class Foam::fv::phaseStabilisedSnGrad< Type >

snGrad scheme with phase-fraction limited non-orthogonal correction.

When the phase-fraction is less than 1e-3 the non-orthogonal correction is set to 0.

Source files

Definition at line 57 of file phaseStabilisedSnGrad.H.

Constructor & Destructor Documentation

◆ phaseStabilisedSnGrad()

phaseStabilisedSnGrad	(	const fvMesh &	mesh,
		Istream &	schemeData
	)

Construct from mesh and data stream.

Definition at line 44 of file phaseStabilisedSnGrad.C.

◆ ~phaseStabilisedSnGrad()

~phaseStabilisedSnGrad

virtual

Destructor.

Definition at line 61 of file phaseStabilisedSnGrad.C.

Member Function Documentation

◆ TypeName()

TypeName ( "phaseStabilised" )

Runtime type information.

◆ deltaCoeffs()

tmp< surfaceScalarField > deltaCoeffs ( const VolField< Type > & vf ) const

virtual

Return the interpolation weighting factors for the given field.

Implements snGradScheme< Type >.

Definition at line 68 of file phaseStabilisedSnGrad.C.

◆ corrected()

virtual bool corrected ( ) const

inlinevirtual

Return true if this scheme uses an explicit correction.

Reimplemented from snGradScheme< Type >.

Definition at line 91 of file phaseStabilisedSnGrad.H.

◆ correction()

tmp< SurfaceField< Type > > correction ( const VolField< Type > & vf ) const

virtual

Return the explicit correction to the phaseStabilisedSnGrad.

for the given field

Reimplemented from snGradScheme< Type >.

Definition at line 79 of file phaseStabilisedSnGrad.C.

References alpha(), Foam::average(), Foam::correction(), IOobject::db(), Foam::e, Foam::endl(), IOobject::group(), IOobject::groupName(), InfoInFunction, localMin< Type >::interpolate(), Foam::MULES::limiter(), Foam::max(), DimensionedField< Type, GeoMesh, PrimitiveField >::mesh(), Foam::min(), and Foam::pos().

Here is the call graph for this function:

◆ operator=()

void operator= ( const phaseStabilisedSnGrad< Type > & )

delete

Disallow default bitwise assignment.

The documentation for this class was generated from the following files:

src/finiteVolume/finiteVolume/snGradSchemes/phaseStabilisedSnGrad/phaseStabilisedSnGrad.H
src/finiteVolume/finiteVolume/snGradSchemes/phaseStabilisedSnGrad/phaseStabilisedSnGrad.C
