Abstract base class for laplacian schemes. More...

Inheritance diagram for laplacianScheme< Type, GType >:

Collaboration diagram for laplacianScheme< Type, GType >:

[legend]

Public Member Functions
virtual const word &	type () const =0
	Runtime type information. More...

	declareRunTimeSelectionTable (tmp, laplacianScheme, Istream,(const fvMesh &mesh, Istream &schemeData),(mesh, schemeData))

	laplacianScheme (const fvMesh &mesh)
	Construct from mesh. More...

	laplacianScheme (const fvMesh &mesh, Istream &is)
	Construct from mesh and Istream. More...

	laplacianScheme (const fvMesh &mesh, const tmp< surfaceInterpolationScheme< GType >> &igs, const tmp< snGradScheme< Type >> &sngs)
	Construct from mesh, interpolation and snGradScheme schemes. More...

	laplacianScheme (const laplacianScheme &)=delete
	Disallow default bitwise copy construction. More...

virtual	~laplacianScheme ()
	Destructor. More...

const fvMesh &	mesh () const
	Return mesh reference. More...

virtual tmp< fvMatrix< Type > >	fvmLaplacian (const SurfaceField< GType > &, const VolField< Type > &)=0

virtual tmp< fvMatrix< Type > >	fvmLaplacian (const VolField< GType > &, const VolField< Type > &)

virtual tmp< VolField< Type > >	fvcLaplacian (const VolField< Type > &)=0

virtual tmp< VolField< Type > >	fvcLaplacian (const SurfaceField< GType > &, const VolField< Type > &)=0

virtual tmp< VolField< Type > >	fvcLaplacian (const VolField< GType > &, const VolField< Type > &)

void	operator= (const laplacianScheme &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from refCount
int	count () const
	Return the current reference count. More...

bool	unique () const
	Return true if the reference count is zero. More...

void	operator++ ()
	Increment the reference count. More...

void	operator++ (int)
	Increment the reference count. More...

void	operator-- ()
	Decrement the reference count. More...

void	operator-- (int)
	Decrement the reference count. More...

void	operator= (const refCount &)=delete
	Disallow bitwise assignment. More...

Static Public Member Functions
static tmp< laplacianScheme< Type, GType > >	New (const fvMesh &mesh, Istream &schemeData)
	Return a pointer to a new laplacianScheme created on freestore. More...

Protected Attributes
const fvMesh &	mesh_

tmp< surfaceInterpolationScheme< GType > >	tinterpGammaScheme_

tmp< snGradScheme< Type > >	tsnGradScheme_

Additional Inherited Members
Protected Member Functions inherited from refCount
	refCount ()
	Construct null initialising count to 0. More...

	refCount (const refCount &)=delete
	Disallow copy. More...

Detailed Description

template<class Type, class GType>
class Foam::fv::laplacianScheme< Type, GType >

Abstract base class for laplacian schemes.

Source files

Definition at line 65 of file laplacianScheme.H.

Constructor & Destructor Documentation

◆ laplacianScheme() [1/4]

laplacianScheme ( const fvMesh & mesh )

inline

Construct from mesh.

Definition at line 102 of file laplacianScheme.H.

◆ laplacianScheme() [2/4]

laplacianScheme	(	const fvMesh &	mesh,
		Istream &	is
	)

inline

Construct from mesh and Istream.

Definition at line 110 of file laplacianScheme.H.

References laplacianScheme< Type, GType >::mesh(), snGradScheme< Type >::New(), surfaceInterpolationScheme< Type >::New(), laplacianScheme< Type, GType >::tinterpGammaScheme_, and laplacianScheme< Type, GType >::tsnGradScheme_.

Here is the call graph for this function:

◆ laplacianScheme() [3/4]

laplacianScheme	(	const fvMesh &	mesh,
		const tmp< surfaceInterpolationScheme< GType >> &	igs,
		const tmp< snGradScheme< Type >> &	sngs
	)

inline

Construct from mesh, interpolation and snGradScheme schemes.

Definition at line 128 of file laplacianScheme.H.

◆ laplacianScheme() [4/4]

laplacianScheme ( const laplacianScheme< Type, GType > & )

delete

Disallow default bitwise copy construction.

◆ ~laplacianScheme()

~laplacianScheme

virtual

Destructor.

Definition at line 89 of file laplacianScheme.C.

Member Function Documentation

◆ type()

virtual const word& type ( ) const

pure virtual

Runtime type information.

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	tmp	,
		laplacianScheme< Type, GType >	,
		Istream	,
		(const fvMesh &mesh, Istream &schemeData)	,
		(mesh, schemeData)
	)

◆ New()

tmp< laplacianScheme< Type, GType > > New	(	const fvMesh &	mesh,
		Istream &	schemeData
	)

static

Return a pointer to a new laplacianScheme created on freestore.

Definition at line 44 of file laplacianScheme.C.

References Foam::endl(), IOstream::eof(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, InfoInFunction, mesh, and Foam::nl.

Referenced by Foam::fvm::laplacian(), and Foam::fvc::laplacian().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ mesh()

const fvMesh& mesh ( ) const

inline

Return mesh reference.

Definition at line 161 of file laplacianScheme.H.

References laplacianScheme< Type, GType >::mesh_.

Referenced by laplacianScheme< Type, GType >::laplacianScheme().

Here is the caller graph for this function:

◆ fvmLaplacian() [1/2]

virtual tmp<fvMatrix<Type> > fvmLaplacian	(	const SurfaceField< GType > &	,
		const VolField< Type > &
	)

pure virtual

Implemented in gaussLaplacianScheme< Type, GType >.

◆ fvmLaplacian() [2/2]

tmp< fvMatrix< Type > > fvmLaplacian	(	const VolField< GType > &	gamma,
		const VolField< Type > &	vf
	)

virtual

Definition at line 97 of file laplacianScheme.C.

References Foam::fvc::interpolate().

Here is the call graph for this function:

◆ fvcLaplacian() [1/3]

virtual tmp<VolField<Type> > fvcLaplacian ( const VolField< Type > & )

pure virtual

Implemented in gaussLaplacianScheme< Type, GType >.

◆ fvcLaplacian() [2/3]

virtual tmp<VolField<Type> > fvcLaplacian	(	const SurfaceField< GType > &	,
		const VolField< Type > &
	)

pure virtual

Implemented in gaussLaplacianScheme< Type, GType >.

◆ fvcLaplacian() [3/3]

tmp< VolField< Type > > fvcLaplacian	(	const VolField< GType > &	gamma,
		const VolField< Type > &	vf
	)

virtual

Definition at line 109 of file laplacianScheme.C.

References Foam::fvc::interpolate().

Here is the call graph for this function:

◆ operator=()

void operator= ( const laplacianScheme< Type, GType > & )

delete

Disallow default bitwise assignment.

Member Data Documentation

◆ mesh_

const fvMesh& mesh_

protected

Definition at line 74 of file laplacianScheme.H.

Referenced by laplacianScheme< Type, GType >::mesh().

◆ tinterpGammaScheme_

tmp<surfaceInterpolationScheme<GType> > tinterpGammaScheme_

protected

Definition at line 76 of file laplacianScheme.H.

Referenced by laplacianScheme< Type, GType >::laplacianScheme().

◆ tsnGradScheme_

tmp<snGradScheme<Type> > tsnGradScheme_

protected

Definition at line 78 of file laplacianScheme.H.

Referenced by laplacianScheme< Type, GType >::laplacianScheme().

The documentation for this class was generated from the following files:

src/finiteVolume/finiteVolume/laplacianSchemes/laplacianScheme/laplacianScheme.H
src/finiteVolume/finiteVolume/laplacianSchemes/laplacianScheme/laplacianScheme.C
