Basic second-order div using face interpolated values and Gauss' theorem. More...

Inheritance diagram for gaussDivScheme< Type >:

Collaboration diagram for gaussDivScheme< Type >:

Public Member Functions
	TypeName ("Gauss")
	Runtime type information. More...

	gaussDivScheme (const fvMesh &mesh)
	Construct null. More...

	gaussDivScheme (const fvMesh &mesh, Istream &is)
	Construct from Istream. More...

	gaussDivScheme (const gaussDivScheme &)=delete
	Disallow default bitwise copy construction. More...

tmp< VolField< typename innerProduct< vector, Type >::type > >	fvcDiv (const VolField< Type > &)

void	operator= (const gaussDivScheme &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from divScheme< Type >
virtual const word &	type () const =0
	Runtime type information. More...

	declareRunTimeSelectionTable (tmp, divScheme, Istream,(const fvMesh &mesh, Istream &schemeData),(mesh, schemeData))

	divScheme (const fvMesh &mesh)
	Construct from mesh. More...

	divScheme (const fvMesh &mesh, Istream &is)
	Construct from mesh and Istream. More...

	divScheme (const divScheme &)=delete
	Disallow default bitwise copy construction. More...

virtual	~divScheme ()
	Destructor. More...

const fvMesh &	mesh () const
	Return mesh reference. More...

void	operator= (const divScheme &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from refCount
int	count () const
	Return the current reference count. More...

bool	unique () const
	Return true if the reference count is zero. More...

void	operator++ ()
	Increment the reference count. More...

void	operator++ (int)
	Increment the reference count. More...

void	operator-- ()
	Decrement the reference count. More...

void	operator-- (int)
	Decrement the reference count. More...

void	operator= (const refCount &)=delete
	Disallow bitwise assignment. More...

Additional Inherited Members
Static Public Member Functions inherited from divScheme< Type >
static tmp< divScheme< Type > >	New (const fvMesh &mesh, Istream &schemeData)
	Return a pointer to a new divScheme created on freestore. More...

Protected Member Functions inherited from refCount
	refCount ()
	Construct null initialising count to 0. More...

	refCount (const refCount &)=delete
	Disallow copy. More...

Protected Attributes inherited from divScheme< Type >
const fvMesh &	mesh_

tmp< surfaceInterpolationScheme< Type > >	tinterpScheme_

Detailed Description

template<class Type>
class Foam::fv::gaussDivScheme< Type >

Basic second-order div using face interpolated values and Gauss' theorem.

Source files

Definition at line 54 of file gaussDivScheme.H.

Constructor & Destructor Documentation

◆ gaussDivScheme() [1/3]

gaussDivScheme ( const fvMesh & mesh )

inline

Construct null.

Definition at line 68 of file gaussDivScheme.H.

◆ gaussDivScheme() [2/3]

gaussDivScheme	(	const fvMesh &	mesh,
		Istream &	is
	)

inline

Construct from Istream.

Definition at line 74 of file gaussDivScheme.H.

◆ gaussDivScheme() [3/3]

gaussDivScheme ( const gaussDivScheme< Type > & )

delete

Disallow default bitwise copy construction.

Member Function Documentation

◆ TypeName()

TypeName ( "Gauss" )

Runtime type information.

◆ fvcDiv()

tmp< VolField< typename innerProduct< vector, Type >::type > > fvcDiv ( const VolField< Type > & vf )

virtual

Implements divScheme< Type >.

Definition at line 44 of file gaussDivScheme.C.

References Foam::fvc::dotInterpolate(), IOobject::name(), tmp< T >::ref(), and Foam::fvc::surfaceIntegrateExtrapolate().

Here is the call graph for this function:

◆ operator=()

void operator= ( const gaussDivScheme< Type > & )

delete

Disallow default bitwise assignment.

The documentation for this class was generated from the following files:

src/finiteVolume/finiteVolume/divSchemes/gaussDivScheme/gaussDivScheme.H
src/finiteVolume/finiteVolume/divSchemes/gaussDivScheme/gaussDivScheme.C
