Fixed temperature equation constraint. More...

Inheritance diagram for fixedTemperature:

Collaboration diagram for fixedTemperature:

Public Types
enum class	temperatureMode { uniform , lookup }
	Temperature mode. More...

Public Member Functions
	TypeName ("fixedTemperature")
	Runtime type information. More...

	fixedTemperature (const word &name, const word &modelType, const fvMesh &mesh, const dictionary &dict)
	Construct from components. More...

	fixedTemperature (const fixedTemperature &)=delete
	Disallow default bitwise copy construction. More...

virtual	~fixedTemperature ()
	Destructor. More...

virtual wordList	constrainedFields () const
	Return the list of fields constrained by the fvConstraint. More...

virtual bool	constrain (fvMatrix< scalar > &eqn, const word &fieldName) const
	Constrain energy equation to fix the temperature. More...

virtual bool	movePoints ()
	Update for mesh motion. More...

virtual void	topoChange (const polyTopoChangeMap &)
	Update topology using the given map. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

virtual void	distribute (const polyDistributionMap &)
	Redistribute or update using the given distribution map. More...

virtual bool	read (const dictionary &dict)
	Read dictionary. More...

void	operator= (const fixedTemperature &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from fvConstraint
	TypeName ("fvConstraint")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, fvConstraint, dictionary,(const word &name, const word &constraintType, const fvMesh &mesh, const dictionary &dict),(name, constraintType, mesh, dict))

	fvConstraint (const word &name, const word &constraintType, const fvMesh &mesh, const dictionary &dict)
	Construct from components. More...

autoPtr< fvConstraint >	clone () const
	Return clone. More...

virtual	~fvConstraint ()
	Destructor. More...

const word &	name () const
	Return const access to the source name. More...

const fvMesh &	mesh () const
	Return const access to the mesh database. More...

const dictionary &	coeffs (const dictionary &) const
	Return the coefficients sub-dictionary. More...

virtual bool	constrainsField (const word &fieldName) const
	Return true if the given field is constrained. More...

	FOR_ALL_FIELD_TYPES (DEFINE_FV_CONSTRAINT_CONSTRAIN)
	Apply a constraint to an equation. More...

	FOR_ALL_FIELD_TYPES (DEFINE_FV_CONSTRAINT_CONSTRAIN_FIELD)
	Apply constraint to a field. More...

Static Public Attributes
static const NamedEnum< temperatureMode, 2 >	modeNames_
	String representation of mode enums. More...

Additional Inherited Members
Static Public Member Functions inherited from fvConstraint
static autoPtr< fvConstraint >	New (const word &name, const fvMesh &mesh, const dictionary &dict)
	Return a reference to the selected fvConstraint. More...

Detailed Description

Fixed temperature equation constraint.

Usage

fixedTemperature
{
    type            fixedTemperature;

    cellZone        all;

    phase           gas; // Optional phase name

    // Uniform temperature constraint
    mode            uniform;
    temperature     constant 500; // Uniform temperature

    // // Looked-up field temperature constraint
    // T            T; // Temperature field name
}

Note: The 'uniform' option allows the use of a time-varying uniform temperature by means of the Function1 type.

Source files

Definition at line 76 of file fixedTemperature.H.

Member Enumeration Documentation

◆ temperatureMode

enum temperatureMode

strong

Temperature mode.

Enumerator
uniform
lookup

Definition at line 83 of file fixedTemperature.H.

Constructor & Destructor Documentation

◆ fixedTemperature() [1/2]

fixedTemperature	(	const word &	name,
		const word &	modelType,
		const fvMesh &	mesh,
		const dictionary &	dict
	)

Construct from components.

Definition at line 111 of file fixedTemperature.C.

References fvConstraint::coeffs(), and dict.

Here is the call graph for this function:

◆ fixedTemperature() [2/2]

fixedTemperature ( const fixedTemperature & )

delete

Disallow default bitwise copy construction.

◆ ~fixedTemperature()

virtual ~fixedTemperature ( )

inlinevirtual

Destructor.

Definition at line 146 of file fixedTemperature.H.

Member Function Documentation

◆ TypeName()

TypeName ( "fixedTemperature" )

Runtime type information.

◆ constrainedFields()

Foam::wordList constrainedFields ( ) const

virtual

Return the list of fields constrained by the fvConstraint.

Reimplemented from fvConstraint.

Definition at line 132 of file fixedTemperature.C.

References IOobject::groupName(), objectRegistry::lookupObject(), mesh, and thermo.

Here is the call graph for this function:

◆ constrain()

bool constrain	(	fvMatrix< scalar > &	eqn,
		const word &	fieldName
	)		const

virtual

Constrain energy equation to fix the temperature.

Definition at line 144 of file fixedTemperature.C.

References cells, IOobject::groupName(), objectRegistry::lookupObject(), mesh, fvMatrix< Type >::setValues(), Foam::T(), thermo, fvMesh::time(), and dimensioned< Type >::value().

Here is the call graph for this function:

◆ movePoints()

bool movePoints ( )

virtual

Update for mesh motion.

Implements fvConstraint.

Definition at line 212 of file fixedTemperature.C.

◆ topoChange()

void topoChange ( const polyTopoChangeMap & map )

virtual

Update topology using the given map.

Implements fvConstraint.

Definition at line 219 of file fixedTemperature.C.

◆ mapMesh()

void mapMesh ( const polyMeshMap & map )

virtual

Update from another mesh using the given map.

Implements fvConstraint.

Definition at line 225 of file fixedTemperature.C.

◆ distribute()

void distribute ( const polyDistributionMap & map )

virtual

Redistribute or update using the given distribution map.

Implements fvConstraint.

Definition at line 231 of file fixedTemperature.C.

◆ read()

bool read ( const dictionary & dict )

virtual

Read dictionary.

Reimplemented from fvConstraint.

Definition at line 237 of file fixedTemperature.C.

References dict, and fvConstraint::read().

Here is the call graph for this function:

◆ operator=()

void operator= ( const fixedTemperature & )

delete

Disallow default bitwise assignment.

Member Data Documentation

◆ modeNames_

const Foam::NamedEnum< Foam::fv::fixedTemperature::temperatureMode, 2 > modeNames_

static

Initial value:

{
    "uniform",
    "lookup"
}

String representation of mode enums.

Definition at line 90 of file fixedTemperature.H.

The documentation for this class was generated from the following files:

src/fvConstraints/fixedTemperature/fixedTemperature.H
src/fvConstraints/fixedTemperature/fixedTemperature.C
