Simple central-difference snGrad scheme with non-orthogonal correction. More...
Public Member Functions | |
| TypeName ("corrected") | |
| Runtime type information. More... | |
| correctedSnGrad (const fvMesh &mesh) | |
| Construct from mesh. More... | |
| correctedSnGrad (const fvMesh &mesh, Istream &) | |
| Construct from mesh and data stream. More... | |
| virtual | ~correctedSnGrad () |
| Destructor. More... | |
| virtual tmp< surfaceScalarField > | deltaCoeffs (const VolField< Type > &) const |
| Return the interpolation weighting factors for the given field. More... | |
| virtual bool | corrected () const |
| Return true if this scheme uses an explicit correction. More... | |
| tmp< SurfaceField< Type > > | fullGradCorrection (const VolField< Type > &) const |
| Return the explicit correction to the correctedSnGrad. More... | |
| virtual tmp< SurfaceField< Type > > | correction (const VolField< Type > &) const |
| Return the explicit correction to the correctedSnGrad. More... | |
| tmp< surfaceScalarField > | correction (const volScalarField &vsf) const |
| tmp< surfaceVectorField > | correction (const volVectorField &vvf) const |
| Foam::tmp< Foam::surfaceVectorField > | correction (const volVectorField &vvf) const |
 Public Member Functions inherited from snGradScheme< Type > | |
| virtual const word & | type () const =0 |
| Runtime type information. More... | |
| declareRunTimeSelectionTable (tmp, snGradScheme, Mesh,(const fvMesh &mesh, Istream &schemeData),(mesh, schemeData)) | |
| snGradScheme (const fvMesh &mesh) | |
| Construct from mesh. More... | |
| snGradScheme (const snGradScheme &)=delete | |
| Disallow default bitwise copy construction. More... | |
| virtual | ~snGradScheme () |
| Destructor. More... | |
| const fvMesh & | mesh () const |
| Return mesh reference. More... | |
| virtual tmp< SurfaceField< Type > > | snGrad (const VolField< Type > &) const |
| Return the snGrad of the given cell field. More... | |
| tmp< SurfaceField< Type > > | snGrad (const tmp< VolField< Type >> &) const |
| Return the snGrad of the given tmp cell field. More... | |
| void | operator= (const snGradScheme &)=delete |
| Disallow default bitwise assignment. More... | |
| Public Member Functions inherited from refCount | |
| int | count () const |
| Return the current reference count. More... | |
| bool | unique () const |
| Return true if the reference count is zero. More... | |
| void | operator++ () |
| Increment the reference count. More... | |
| void | operator++ (int) |
| Increment the reference count. More... | |
| void | operator-- () |
| Decrement the reference count. More... | |
| void | operator-- (int) |
| Decrement the reference count. More... | |
| void | operator= (const refCount &)=delete |
| Disallow bitwise assignment. More... | |
Additional Inherited Members | |
| Static Public Member Functions inherited from snGradScheme< Type > | |
| static tmp< snGradScheme< Type > > | New (const fvMesh &mesh, Istream &schemeData) |
| Return new tmp interpolation scheme. More... | |
| static tmp< SurfaceField< Type > > | snGrad (const VolField< Type > &, const tmp< surfaceScalarField > &, const word &snGradName="snGrad") |
| Return the snGrad of the given cell field with the given deltaCoeffs. More... | |
| static tmp< SurfaceField< Type > > | sndGrad (const VolField< Type > &, const word &snGradName="sndGrad") |
| Return the sndGrad of the given cell field. More... | |
| Protected Member Functions inherited from refCount | |
| refCount () | |
| Construct null initialising count to 0. More... | |
| refCount (const refCount &)=delete | |
| Disallow copy. More... | |
Simple central-difference snGrad scheme with non-orthogonal correction.
Definition at line 54 of file correctedSnGrad.H.
|
inline |
Construct from mesh.
Definition at line 73 of file correctedSnGrad.H.
|
inline |
Construct from mesh and data stream.
Definition at line 80 of file correctedSnGrad.H.
|
virtual |
Destructor.
Definition at line 36 of file correctedSnGrad.C.
| TypeName | ( | "corrected" | ) |
Runtime type information.
|
inlinevirtual |
Return the interpolation weighting factors for the given field.
Implements snGradScheme< Type >.
Definition at line 93 of file correctedSnGrad.H.
References snGradScheme< Type >::mesh(), and surfaceInterpolation::nonOrthDeltaCoeffs().
|
inlinevirtual |
Return true if this scheme uses an explicit correction.
Reimplemented from snGradScheme< Type >.
Definition at line 102 of file correctedSnGrad.H.
| Foam::tmp< Foam::SurfaceField< Type > > fullGradCorrection | ( | const VolField< Type > & | vf | ) | const |
Return the explicit correction to the correctedSnGrad.
for the given field using the gradient of the field
Definition at line 44 of file correctedSnGrad.C.
References Foam::fvc::dotInterpolate(), Foam::fvc::grad(), fvSchemes::grad(), mesh, IOobject::name(), Foam::compressible::New(), surfaceInterpolation::nonOrthCorrectionVectors(), tmp< T >::ref(), and fvMesh::schemes().
|
virtual |
Return the explicit correction to the correctedSnGrad.
for the given field using the gradients of the field components
Reimplemented from snGradScheme< Type >.
Definition at line 70 of file correctedSnGrad.C.
References GeometricField< Type, GeoMesh, PrimitiveField >::component(), DimensionedField< Type, GeoMesh, PrimitiveField >::dimensions(), mesh, IOobject::name(), surfaceInterpolation::nonOrthDeltaCoeffs(), tmp< T >::ref(), and GeometricField< Type, GeoMesh, PrimitiveField >::replace().
| tmp< surfaceScalarField > correction | ( | const volScalarField & | vsf | ) | const |
| tmp< surfaceVectorField > correction | ( | const volVectorField & | vvf | ) | const |
| Foam::tmp< Foam::surfaceVectorField > correction | ( | const volVectorField & | vvf | ) | const |
Definition at line 46 of file correctedSnGrads.C.
