Public Member Functions | List of all members
EulerD2dt2Scheme< Type > Class Template Reference

First-order Euler implicit d2dt2 using the current and two previous time-step values. More...

Inheritance diagram for EulerD2dt2Scheme< Type >:
Inheritance graph
[legend]
Collaboration diagram for EulerD2dt2Scheme< Type >:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("Euler")
 Runtime type information. More...

 EulerD2dt2Scheme (const fvMesh &mesh)
 Construct from mesh. More...

 EulerD2dt2Scheme (const fvMesh &mesh, Istream &is)
 Construct from mesh and Istream. More...

 EulerD2dt2Scheme (const EulerD2dt2Scheme &)=delete
 Disallow default bitwise copy construction. More...

const fvMesh & mesh () const
 Return mesh reference. More...

tmp< VolField< Type > > fvcD2dt2 (const VolField< Type > &)

tmp< VolField< Type > > fvcD2dt2 (const volScalarField &, const VolField< Type > &)

tmp< fvMatrix< Type > > fvmD2dt2 (const VolField< Type > &)

tmp< fvMatrix< Type > > fvmD2dt2 (const dimensionedScalar &, const VolField< Type > &)

tmp< fvMatrix< Type > > fvmD2dt2 (const volScalarField &, const VolField< Type > &)

void operator= (const EulerD2dt2Scheme &)=delete
 Disallow default bitwise assignment. More...

- Public Member Functions inherited from d2dt2Scheme< Type >
virtual const word & type () const =0
 Runtime type information. More...

 declareRunTimeSelectionTable (tmp, d2dt2Scheme, Istream,(const fvMesh &mesh, Istream &schemeData),(mesh, schemeData))

 d2dt2Scheme (const fvMesh &mesh)
 Construct from mesh. More...

 d2dt2Scheme (const fvMesh &mesh, Istream &)
 Construct from mesh and Istream. More...

 d2dt2Scheme (const d2dt2Scheme &)=delete
 Disallow default bitwise copy construction. More...

virtual ~d2dt2Scheme ()
 Destructor. More...

const fvMesh & mesh () const
 Return mesh reference. More...

void operator= (const d2dt2Scheme &)=delete
 Disallow default bitwise assignment. More...

- Public Member Functions inherited from refCount
int count () const
 Return the current reference count. More...

bool unique () const
 Return true if the reference count is zero. More...

void operator++ ()
 Increment the reference count. More...

void operator++ (int)
 Increment the reference count. More...

void operator-- ()
 Decrement the reference count. More...

void operator-- (int)
 Decrement the reference count. More...

void operator= (const refCount &)=delete
 Disallow bitwise assignment. More...


Additional Inherited Members

- Static Public Member Functions inherited from d2dt2Scheme< Type >
static tmp< d2dt2Scheme< Type > > New (const fvMesh &mesh, Istream &schemeData)
 Return a pointer to a new d2dt2Scheme created on freestore. More...

- Protected Member Functions inherited from refCount
 refCount ()
 Construct null initialising count to 0. More...

 refCount (const refCount &)=delete
 Disallow copy. More...

- Protected Attributes inherited from d2dt2Scheme< Type >
const fvMesh & mesh_


Detailed Description

template<class Type>
class Foam::fv::EulerD2dt2Scheme< Type >

First-order Euler implicit d2dt2 using the current and two previous time-step values.

Source files

Definition at line 55 of file EulerD2dt2Scheme.H.

Constructor & Destructor Documentation

◆ EulerD2dt2Scheme() [1/3]

EulerD2dt2Scheme ( const fvMesh &  mesh)
inline

Construct from mesh.

Definition at line 68 of file EulerD2dt2Scheme.H.

◆ EulerD2dt2Scheme() [2/3]

EulerD2dt2Scheme ( const fvMesh &  mesh,
Istream &  is
)
inline

Construct from mesh and Istream.

Definition at line 74 of file EulerD2dt2Scheme.H.

◆ EulerD2dt2Scheme() [3/3]

EulerD2dt2Scheme ( const EulerD2dt2Scheme< Type > &  )
delete

Disallow default bitwise copy construction.

Member Function Documentation

◆ TypeName()

TypeName ( "Euler"  )

Runtime type information.

◆ mesh()

const fvMesh& mesh ( ) const
inline

Return mesh reference.

Definition at line 86 of file EulerD2dt2Scheme.H.

References d2dt2Scheme< Type >::mesh().

Here is the call graph for this function:

◆ fvcD2dt2() [1/2]

tmp< VolField< Type > > fvcD2dt2 ( const VolField< Type > &  vf)
virtual

Implements d2dt2Scheme< Type >.

Definition at line 44 of file EulerD2dt2Scheme.C.

References GeometricField< Type, GeoMesh, PrimitiveField >::boundaryField(), TimeState::deltaT0Value(), TimeState::deltaTValue(), mesh, polyMesh::moving(), IOobject::name(), GeometricField< Type, GeoMesh, PrimitiveField >::New(), OldTimeField< FieldType >::oldTime(), Foam::sqr(), fvMesh::time(), and dimensioned< Type >::value().

Here is the call graph for this function:

◆ fvcD2dt2() [2/2]

tmp< VolField< Type > > fvcD2dt2 ( const volScalarField &  rho,
const VolField< Type > &  vf
)
virtual

Implements d2dt2Scheme< Type >.

Definition at line 108 of file EulerD2dt2Scheme.C.

References GeometricField< Type, GeoMesh, PrimitiveField >::boundaryField(), TimeState::deltaT0Value(), TimeState::deltaTValue(), mesh, polyMesh::moving(), IOobject::name(), GeometricField< Type, GeoMesh, PrimitiveField >::New(), OldTimeField< FieldType >::oldTime(), rho, Foam::sqr(), fvMesh::time(), and dimensioned< Type >::value().

Here is the call graph for this function:

◆ fvmD2dt2() [1/3]

tmp< fvMatrix< Type > > fvmD2dt2 ( const VolField< Type > &  vf)
virtual

Implements d2dt2Scheme< Type >.

Definition at line 209 of file EulerD2dt2Scheme.C.

References TimeState::deltaT0Value(), TimeState::deltaTValue(), lduMatrix::diag(), DimensionedField< Type, GeoMesh, PrimitiveField >::dimensions(), Foam::dimTime, Foam::dimVolume, mesh, OldTimeField< FieldType >::oldTime(), tmp< T >::ref(), fvMatrix< Type >::source(), Foam::sqr(), fvMesh::time(), and fvMesh::V().

Here is the call graph for this function:

◆ fvmD2dt2() [2/3]

tmp< fvMatrix< Type > > fvmD2dt2 ( const dimensionedScalar &  rho,
const VolField< Type > &  vf
)
virtual

Implements d2dt2Scheme< Type >.

Definition at line 268 of file EulerD2dt2Scheme.C.

References TimeState::deltaT0Value(), TimeState::deltaTValue(), lduMatrix::diag(), DimensionedField< Type, GeoMesh, PrimitiveField >::dimensions(), Foam::dimTime, Foam::dimVolume, mesh, OldTimeField< FieldType >::oldTime(), tmp< T >::ref(), rho, fvMatrix< Type >::source(), Foam::sqr(), fvMesh::time(), and fvMesh::V().

Here is the call graph for this function:

◆ fvmD2dt2() [3/3]

tmp< fvMatrix< Type > > fvmD2dt2 ( const volScalarField &  rho,
const VolField< Type > &  vf
)
virtual

Implements d2dt2Scheme< Type >.

Definition at line 328 of file EulerD2dt2Scheme.C.

References TimeState::deltaT0Value(), TimeState::deltaTValue(), lduMatrix::diag(), DimensionedField< Type, GeoMesh, PrimitiveField >::dimensions(), Foam::dimTime, Foam::dimVolume, mesh, OldTimeField< FieldType >::oldTime(), tmp< T >::ref(), rho, fvMatrix< Type >::source(), Foam::sqr(), fvMesh::time(), and fvMesh::V().

Here is the call graph for this function:

◆ operator=()

void operator= ( const EulerD2dt2Scheme< Type > &  )
delete

Disallow default bitwise assignment.

The documentation for this class was generated from the following files:
