fvMeshTopoChanger which maps the fields to a new mesh or sequence of meshes More...

Inheritance diagram for meshToMesh:

Collaboration diagram for meshToMesh:

Public Member Functions
	TypeName ("meshToMesh")
	Runtime type information. More...

	meshToMesh (fvMesh &, const dictionary &dict)
	Construct from fvMesh and dictionary. More...

	meshToMesh (const meshToMesh &)=delete
	Disallow default bitwise copy construction. More...

virtual	~meshToMesh ()
	Destructor. More...

scalar	timeToNextMesh () const

bool	mapped () const
	Return true if the mesh has been mapped this time-step,. More...

virtual bool	update ()
	Update the mesh for both mesh motion and topology change. More...

virtual void	topoChange (const polyTopoChangeMap &)
	Update corresponding to the given map. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

virtual void	distribute (const polyDistributionMap &)
	Update corresponding to the given distribution map. More...

void	operator= (const meshToMesh &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from fvMeshTopoChanger
	TypeName ("fvMeshTopoChanger")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, fvMeshTopoChanger, fvMesh,(fvMesh &mesh, const dictionary &dict),(mesh, dict))

	fvMeshTopoChanger (fvMesh &)
	Construct from fvMesh. More...

	fvMeshTopoChanger (const fvMeshTopoChanger &)=delete
	Disallow default bitwise copy construction. More...

virtual	~fvMeshTopoChanger ()
	Destructor. More...

fvMesh &	mesh ()
	Return the fvMesh. More...

const fvMesh &	mesh () const
	Return the fvMesh. More...

virtual bool	dynamic () const
	Is mesh dynamic, i.e. might it change? More...

virtual bool	write (const bool write=true) const
	Write the mover state. More...

void	operator= (const fvMeshTopoChanger &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Static Public Member Functions inherited from fvMeshTopoChanger
static autoPtr< fvMeshTopoChanger >	New (fvMesh &, const dictionary &dict)
	Select, construct and return the fvMeshTopoChanger. More...

static autoPtr< fvMeshTopoChanger >	New (fvMesh &)
	Select, construct and return the fvMeshTopoChanger. More...

Detailed Description

fvMeshTopoChanger which maps the fields to a new mesh or sequence of meshes

which can optionally be mapped to repeatedly for example in multi-cycle engine cases or cycled through for symmetric forward and reverse motion.

Usage

Property	Description	Required	Default value
`libs`	Libraries to load	no
`times`	List of times for the meshes	yes
`repeat`	Repetition period	no
`cycle`	Cycle period	no
`begin`	Begin time for the meshes	no	Time::beginTime()
`timeDelta`	Time tolerance used for time -> index	yes

Examples of the mesh-to-mesh mapping for the multi-cycle tutorials/incompressibleFluid/movingCone case:

    topoChanger
    {
        type    meshToMesh;

        libs    ("libmeshToMeshTopoChanger.so");

        times   (0.0015 0.003);

        cycle   #calc "1.0/300.0";
        begin   0;

        timeDelta 1e-6;
    }
