Mesh manipulator that uses the intersection provided by the cyclic non-conformal poly patches to create non-conformal finite volume interfaces. More...

Inheritance diagram for fvMeshStitcher:

[legend]

Public Member Functions
	TypeName ("fvMeshStitcher")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, fvMeshStitcher, fvMesh,(fvMesh &mesh),(mesh))

	fvMeshStitcher (fvMesh &)
	Construct from fvMesh. More...

	fvMeshStitcher (const fvMeshStitcher &)=delete
	Disallow default bitwise copy construction. More...

virtual	~fvMeshStitcher ()
	Destructor. More...

fvMesh &	mesh ()
	Return the fvMesh. More...

bool	stitches () const
	Does this stitcher do anything? More...

bool	disconnect (const bool changing, const bool geometric)
	Disconnect the mesh by removing faces from the nonConformalCyclics. More...

bool	connect (const bool changing, const bool geometric, const bool load)
	Connect the mesh by adding faces into the nonConformalCyclics. More...

void	reconnect (const bool geometric) const
	Re-compute the connection. Topology is preserved. Permits a change. More...

virtual void	topoChange (const polyTopoChangeMap &)
	Update corresponding to the given map. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

virtual void	distribute (const polyDistributionMap &)
	Update corresponding to the given distribution map. More...

virtual bool	write (const bool write=true) const
	Write the stitcher state. More...

void	operator= (const fvMeshStitcher &)=delete
	Disallow default bitwise assignment. More...

Static Public Member Functions
static autoPtr< fvMeshStitcher >	New (fvMesh &, bool changing)
	Select, construct and return the fvMeshStitcher. More...

Protected Types
template<class Type >
using	SurfaceFieldBoundary = GeometricBoundaryField< Type, surfaceMesh >
	Alias for surface boundary fields to reduce verbosity of method. More...

using	part = patchToPatches::intersection::part
	Alias the patchToPatch intersection part struct. More...

using	couple = patchToPatches::intersection::couple
	Alias the patchToPatch intersection couple struct. More...

Protected Member Functions
boolList	patchCoupleds () const
	Determine which patches are coupled; i.e., for which. More...

bool	geometric () const
	Is the connection "geometric", or has the topology just been. More...

tmp< DimensionedField< scalar, volMesh > >	openness () const
	Return the non-dimensional cell openness for debugging/checking. More...

tmp< DimensionedField< scalar, volMesh > >	volumeConservationError (const label n) const
	Return the non-dimensional old-time volume conservation error. More...

tmp< DimensionedField< scalar, volMesh > >	projectedVolumeFraction () const
	Return the projected volume fraction for debugging/checking. More...

Detailed Description

Mesh manipulator that uses the intersection provided by the cyclic non-conformal poly patches to create non-conformal finite volume interfaces.

Source files

Definition at line 55 of file fvMeshStitcher.H.

Member Typedef Documentation

◆ SurfaceFieldBoundary

using SurfaceFieldBoundary = GeometricBoundaryField<Type, surfaceMesh>

protected

Alias for surface boundary fields to reduce verbosity of method.

definitions below

Definition at line 64 of file fvMeshStitcher.H.

◆ part

using part = patchToPatches::intersection::part

protected

Alias the patchToPatch intersection part struct.

Definition at line 67 of file fvMeshStitcher.H.

◆ couple

using couple = patchToPatches::intersection::couple

protected

Alias the patchToPatch intersection couple struct.

Definition at line 70 of file fvMeshStitcher.H.

Constructor & Destructor Documentation

◆ fvMeshStitcher() [1/2]

fvMeshStitcher ( fvMesh & mesh )

explicit

Construct from fvMesh.

Definition at line 2242 of file fvMeshStitcher.C.

◆ fvMeshStitcher() [2/2]

fvMeshStitcher ( const fvMeshStitcher & )

delete

Disallow default bitwise copy construction.

◆ ~fvMeshStitcher()

~fvMeshStitcher ( )

virtual

Destructor.

Definition at line 2253 of file fvMeshStitcher.C.

Member Function Documentation

◆ patchCoupleds()

Foam::boolList patchCoupleds ( ) const

protected

Determine which patches are coupled; i.e., for which.

non-conformal patches are the remote or neighbouring meshes available

Definition at line 2107 of file fvMeshStitcher.C.

References forAll, mappedFvPatchBaseBase::haveNbr(), nonConformalMappedWallFvPatch::nbrPatch(), UPstream::parRun(), nonConformalFvPatch::patch(), patchi, processorCyclicFvPatch::referPatchIndex(), Foam::patchToPatchTools::singleProcess(), and fvPatch::size().

Here is the call graph for this function:

◆ geometric()

bool geometric ( ) const

protected

Is the connection "geometric", or has the topology just been.

loaded and stabilisation geometry applied?

Definition at line 2159 of file fvMeshStitcher.C.

References forAll, polyPatch::magFaceAreas(), Foam::max(), patchi, Foam::reduce(), Foam::returnReduce(), and polyPatch::start().

Here is the call graph for this function:

◆ openness()

Foam::tmp< Foam::DimensionedField< Foam::scalar, Foam::volMesh > > openness ( ) const

protected

Return the non-dimensional cell openness for debugging/checking.

Definition at line 2194 of file fvMeshStitcher.C.

References Foam::cbrt(), Foam::cmptMag(), Foam::mag(), Foam::max(), Foam::sqr(), Foam::fvc::surfaceIntegrate(), and Foam::fvc::surfaceSum().

Here is the call graph for this function:

◆ volumeConservationError()

Foam::tmp< Foam::DimensionedField< Foam::scalar, Foam::volMesh > > volumeConservationError ( const label n ) const

protected

Return the non-dimensional old-time volume conservation error.

for a specified old-time index for debugging/checking

Definition at line 2207 of file fvMeshStitcher.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, n, OldTimeField< FieldType >::oldTime(), and Foam::fvc::surfaceIntegrate().

Here is the call graph for this function:

◆ projectedVolumeFraction()

Foam::tmp< Foam::DimensionedField< Foam::scalar, Foam::volMesh > > projectedVolumeFraction ( ) const

protected

Return the projected volume fraction for debugging/checking.

Definition at line 2229 of file fvMeshStitcher.C.

References Foam::mag(), and Foam::fvc::surfaceIntegrate().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "fvMeshStitcher" )

Runtime type information.

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		fvMeshStitcher	,
		fvMesh	,
		(fvMesh &mesh)	,
		(mesh)
	)

◆ New()

Foam::autoPtr< Foam::fvMeshStitcher > New	(	fvMesh &	mesh,
		bool	changing
	)

static

Select, construct and return the fvMeshStitcher.

Definition at line 30 of file fvMeshStitcherNew.C.

References TimePaths::constant(), Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, forAllConstIter, typeIOobject< Type >::headerOk(), Foam::libs, fvMeshStitcher::mesh(), Foam::nl, IOobject::NO_WRITE, dlLibraryTable::open(), IOobject::READ_IF_PRESENT, and fvMesh::time().

Referenced by fvMesh::postConstruct().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ mesh()

fvMesh& mesh ( )

inline

Return the fvMesh.

Definition at line 446 of file fvMeshStitcher.H.

Referenced by fvMeshStitcher::New().

Here is the caller graph for this function:

◆ stitches()

bool stitches ( ) const

Does this stitcher do anything?

Definition at line 2259 of file fvMeshStitcher.C.

References forAll, and patchi.

Referenced by shockFluid::preSolve().

Here is the caller graph for this function:

◆ disconnect()

bool disconnect	(	const bool	changing,
		const bool	geometric
	)

Disconnect the mesh by removing faces from the nonConformalCyclics.

Definition at line 2280 of file fvMeshStitcher.C.

References forAll.

◆ connect()

bool connect	(	const bool	changing,
		const bool	geometric,
		const bool	load
	)

Connect the mesh by adding faces into the nonConformalCyclics.

Definition at line 2311 of file fvMeshStitcher.C.

References forAll.

◆ reconnect()

void reconnect ( const bool geometric ) const

Re-compute the connection. Topology is preserved. Permits a change.

in whether or not the connection is "geometric".

Definition at line 2362 of file fvMeshStitcher.C.

References GeometricField< Type, GeoMesh, PrimitiveField >::null().

Here is the call graph for this function:

◆ topoChange()

void topoChange ( const polyTopoChangeMap & )

virtual

Update corresponding to the given map.

Definition at line 2408 of file fvMeshStitcher.C.

◆ mapMesh()

void mapMesh ( const polyMeshMap & map )

virtual

Update from another mesh using the given map.

Definition at line 2412 of file fvMeshStitcher.C.

◆ distribute()

void distribute ( const polyDistributionMap & )

virtual

Update corresponding to the given distribution map.

Definition at line 2416 of file fvMeshStitcher.C.

◆ write()

virtual bool write ( const bool write = true ) const

inlinevirtual

Write the stitcher state.

Definition at line 483 of file fvMeshStitcher.H.

◆ operator=()

void operator= ( const fvMeshStitcher & )

delete

Disallow default bitwise assignment.

The documentation for this class was generated from the following files:

src/finiteVolume/fvMesh/fvMeshStitchers/fvMeshStitcher/fvMeshStitcher.H
src/finiteVolume/fvMesh/fvMeshStitchers/fvMeshStitcher/fvMeshStitcher.C
src/finiteVolume/fvMesh/fvMeshStitchers/fvMeshStitcher/fvMeshStitcherNew.C
src/finiteVolume/fvMesh/fvMeshStitchers/fvMeshStitcher/fvMeshStitcherTemplates.C
