Read/write the lines from pro-STAR vrt/cel files. More...

Inheritance diagram for STARCDedgeFormat:

Collaboration diagram for STARCDedgeFormat:

Public Member Functions
	STARCDedgeFormat (const fileName &)
	Construct from file name. More...

	STARCDedgeFormat (const STARCDedgeFormat &)=delete
	Disallow default bitwise copy construction. More...

virtual	~STARCDedgeFormat ()
	Destructor. More...

virtual bool	read (const fileName &)
	Read from file. More...

virtual void	write (const fileName &name) const
	Write object. More...

void	operator= (const STARCDedgeFormat &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from edgeMesh
	TypeName ("edgeMesh")
	Runtime type information. More...

	edgeMesh ()
	Construct null. More...

	edgeMesh (const pointField &, const edgeList &)
	Construct from components. More...

	edgeMesh (pointField &&, edgeList &&)
	Construct by transferring components (points, edges). More...

	edgeMesh (const edgeMesh &)
	Copy constructor. More...

	edgeMesh (edgeMesh &&)
	Move constructor. More...

	edgeMesh (const fileName &)
	Construct from file name (uses extension to determine type) More...

	edgeMesh (const fileName &, const word &ext)
	Construct from file name (uses extension to determine type) More...

	edgeMesh (Istream &)
	Construct from Istream. More...

	declareRunTimeSelectionTable (autoPtr, edgeMesh, fileExtension,(const fileName &name),(name))

virtual	~edgeMesh ()
	Destructor. More...

	declareMemberFunctionSelectionTable (void, edgeMesh, write, fileExtension,(const fileName &name, const edgeMesh &mesh),(name, mesh))

void	transfer (edgeMesh &)
	Transfer the contents of the argument and annul the argument. More...

bool	read (const fileName &, const word &ext)
	Read from file. Chooses reader based on explicit extension. More...

const pointField &	points () const
	Return points. More...

const edgeList &	edges () const
	Return edges. More...

const labelListList &	pointEdges () const
	Return edges. More...

label	regions (labelList &edgeRegion) const
	Find connected regions. Set region number per edge. More...

virtual void	clear ()
	Clear all storage. More...

virtual void	reset (pointField &&points, edgeList &&edges)
	Reset primitive data (points, edges) More...

virtual void	scalePoints (const scalar)
	Scale points. A non-positive factor is ignored. More...

virtual void	mergeEdges ()
	Merge duplicate edges. More...

virtual void	writeStats (Ostream &) const

void	operator= (const edgeMesh &)

void	operator= (edgeMesh &&)

Public Member Functions inherited from STARCDCore
	STARCDCore ()
	Construct null. More...

Static Public Member Functions
static autoPtr< edgeMesh >	New (const fileName &name)
	Read file and return edgeMesh. More...

static void	write (const fileName &, const edgeMesh &)
	Write edge mesh. More...

Static Public Member Functions inherited from edgeMesh
static bool	canRead (const fileName &, const bool verbose=false)
	Can we read this file format? More...

static bool	canReadType (const word &ext, const bool verbose=false)
	Can we read this file format? More...

static bool	canWriteType (const word &ext, const bool verbose=false)
	Can we write this file format type? More...

static wordHashSet	readTypes ()

static wordHashSet	writeTypes ()

static autoPtr< edgeMesh >	New (const fileName &, const word &ext)
	Select constructed from filename (explicit extension) More...

static autoPtr< edgeMesh >	New (const fileName &)
	Select constructed from filename (implicit extension) More...

static void	write (const fileName &, const edgeMesh &)
	Write to file. More...

Static Public Member Functions inherited from edgeMeshFormatsCore
static bool	checkSupport (const wordHashSet &available, const word &ext, const bool verbose, const word &functionName)
	... More...

Static Public Member Functions inherited from STARCDCore
static bool	readPoints (IFstream &, pointField &, labelList &ids)
	Read points from a (.vrt) file. More...

static void	writePoints (Ostream &, const pointField &)
	Write header and points to (.vrt) file. More...

Static Protected Member Functions
static void	writeCase (Ostream &, const pointField &, const label nEdges)

Static Protected Member Functions inherited from edgeMeshFormatsCore
static string	getLineNoComment (IFstream &)
	Read non-comment line. More...

Static Protected Member Functions inherited from STARCDCore
static bool	readHeader (IFstream &, const word &fileSignature)
	Read header. More...

static void	writeHeader (Ostream &, const word &fileType)
	Write header for fileType (CELL\|VERTEX\|BOUNDARY) More...

Additional Inherited Members
Static Public Attributes inherited from edgeMeshFormatsCore
static word	nativeExt
	The file extension corresponding to 'native' edge format. More...

Protected Types inherited from STARCDCore
enum	cellType { starcdFluidType = 1 , starcdSolidType = 2 , starcdBaffleType = 3 , starcdShellType = 4 , starcdLineType = 5 , starcdPointType = 6 }

enum	shapeType { starcdPoint = 1 , starcdLine = 2 , starcdShell = 3 , starcdHex = 11 , starcdPrism = 12 , starcdTet = 13 , starcdPyr = 14 , starcdPoly = 255 }

Protected Member Functions inherited from edgeMesh
pointField &	storedPoints ()
	Non-const access to global points. More...

edgeList &	storedEdges ()
	Non-const access to the edges. More...
