Model for diffusive mass transfer coefficients between two phases. More...

Inheritance diagram for diffusiveMassTransferModel:

Collaboration diagram for diffusiveMassTransferModel:

Public Member Functions
	TypeName ("diffusiveMassTransferModel")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, diffusiveMassTransferModel, dictionary,(const dictionary &dict, const phaseInterface &interface),(dict, interface))

	diffusiveMassTransferModel (const dictionary &dict, const phaseInterface &interface)
	Construct from a dictionary and an interface. More...

virtual	~diffusiveMassTransferModel ()
	Destructor. More...

virtual tmp< volScalarField >	K () const =0
	The implicit mass transfer coefficient. More...

Static Public Member Functions
static autoPtr< diffusiveMassTransferModel >	New (const dictionary &dict, const phaseInterface &interface)

Static Public Attributes
static const dimensionSet	dimK
	Coefficient dimensions. More...

Detailed Description

Model for diffusive mass transfer coefficients between two phases.

Source files

Definition at line 54 of file diffusiveMassTransferModel.H.

Constructor & Destructor Documentation

◆ diffusiveMassTransferModel()

diffusiveMassTransferModel	(	const dictionary &	dict,
		const phaseInterface &	interface
	)

Construct from a dictionary and an interface.

Definition at line 61 of file diffusiveMassTransferModel.C.

◆ ~diffusiveMassTransferModel()

~diffusiveMassTransferModel ( )

virtual

Destructor.

Definition at line 71 of file diffusiveMassTransferModel.C.

Member Function Documentation

◆ TypeName()

TypeName ( "diffusiveMassTransferModel" )

Runtime type information.

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		diffusiveMassTransferModel	,
		dictionary	,
		(const dictionary &dict, const phaseInterface &interface)	,
		(dict, interface)
	)

◆ New()

Foam::autoPtr< Foam::diffusiveMassTransferModel > New	(	const dictionary &	dict,
		const phaseInterface &	interface
	)

static

Definition at line 32 of file diffusiveMassTransferModelNew.C.

References dict, Foam::endl(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, Foam::Info, dictionary::lookup(), and phaseInterface::name().

Here is the call graph for this function:

◆ K()

virtual tmp<volScalarField> K ( ) const

pure virtual

The implicit mass transfer coefficient.

Note: this has had the species mass diffusivity factored out

Implemented in sphericalDiffusiveMassTransfer, and Frossling.

Referenced by blendedDiffusiveMassTransferModel::K().

Here is the caller graph for this function:

Member Data Documentation

◆ dimK

const Foam::dimensionSet dimK

static

Coefficient dimensions.

Definition at line 80 of file diffusiveMassTransferModel.H.

Referenced by blendedDiffusiveMassTransferModel::K(), and blendedSidedDiffusiveMassTransferModel::KinThe().

The documentation for this class was generated from the following files:

applications/modules/multiphaseEuler/phaseSystem/interfacialModels/diffusiveMassTransferModels/diffusiveMassTransferModel/diffusiveMassTransferModel.H
applications/modules/multiphaseEuler/phaseSystem/interfacialModels/diffusiveMassTransferModels/diffusiveMassTransferModel/diffusiveMassTransferModel.C
applications/modules/multiphaseEuler/phaseSystem/interfacialModels/diffusiveMassTransferModels/diffusiveMassTransferModel/diffusiveMassTransferModelNew.C
