IATE (Interfacial Area Transport Equation) bubble diameter model run-time selectable sources. More...

Inheritance diagram for IATEsource:

[legend]

Collaboration diagram for IATEsource:

Classes
class	iNew
	Class used for the read-construction of. More...

Public Member Functions
	TypeName ("IATEsource")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, IATEsource, dictionary,(const IATE &iate, const dictionary &dict),(iate, dict))

	IATEsource (const IATE &iate)

autoPtr< IATEsource >	clone () const

virtual	~IATEsource ()
	Destructor. More...

const phaseModel &	phase () const

const phaseSystem &	fluid () const

const phaseModel &	otherPhase () const

scalar	phi () const

tmp< volScalarField >	sigma () const
	Return the bubble surface tension coefficient. More...

tmp< volScalarField >	Ur () const
	Return the bubble relative velocity. More...

tmp< volScalarField >	Ut () const
	Return the bubble turbulent velocity. More...

tmp< volScalarField >	Re () const
	Return the bubble Reynolds number. More...

tmp< volScalarField >	CD () const
	Return the bubble drag coefficient. More...

tmp< volScalarField >	Mo () const
	Return the bubble Morton number. More...

tmp< volScalarField >	Eo () const
	Return the bubble Eotvos number. More...

tmp< volScalarField >	We () const
	Return the bubble turbulent Weber number. More...

virtual tmp< fvScalarMatrix >	R (volScalarField &kappai) const =0

Static Public Member Functions
static autoPtr< IATEsource >	New (const word &type, const IATE &iate, const dictionary &dict)

Protected Attributes
const IATE &	iate_
	Reference to the IATE this source applies to. More...

Detailed Description

IATE (Interfacial Area Transport Equation) bubble diameter model run-time selectable sources.

Source files

Definition at line 53 of file IATEsource.H.

Constructor & Destructor Documentation

◆ IATEsource()

IATEsource ( const IATE & iate )

inline

Definition at line 109 of file IATEsource.H.

◆ ~IATEsource()

virtual ~IATEsource ( )

inlinevirtual

Destructor.

Definition at line 132 of file IATEsource.H.

Member Function Documentation

◆ TypeName()

TypeName ( "IATEsource" )

Runtime type information.

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		IATEsource	,
		dictionary	,
		(const IATE &iate, const dictionary &dict)	,
		(iate, dict)
	)

◆ clone()

autoPtr<IATEsource> clone ( ) const

inline

Definition at line 114 of file IATEsource.H.

References NotImplemented.

◆ New()

Foam::autoPtr< Foam::diameterModels::IATEsource > New	(	const word &	type,
		const IATE &	iate,
		const dictionary &	dict
	)

static

Definition at line 46 of file IATEsource.C.

References dict, Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::nl, and Foam::type().

Referenced by IATEsource::iNew::operator()().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ phase()

const phaseModel& phase ( ) const

inline

Definition at line 138 of file IATEsource.H.

References IATEsource::iate_, and diameterModel::phase().

Referenced by IATEsource::otherPhase(), and IATEsource::sigma().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ fluid()

const phaseSystem& fluid ( ) const

inline

Definition at line 143 of file IATEsource.H.

References phaseModel::fluid(), IATEsource::iate_, and diameterModel::phase().

Referenced by IATEsource::otherPhase(), and IATEsource::sigma().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ otherPhase()

const phaseModel& otherPhase ( ) const

inline

Definition at line 148 of file IATEsource.H.

References IATEsource::fluid(), phaseSystem::otherPhase(), and IATEsource::phase().

Referenced by IATEsource::sigma().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ phi()

scalar phi ( ) const

inline

Definition at line 153 of file IATEsource.H.

References Foam::constant::mathematical::pi().

Here is the call graph for this function:

◆ sigma()

tmp<volScalarField> sigma ( ) const

inline

Return the bubble surface tension coefficient.

Definition at line 159 of file IATEsource.H.

References IATEsource::fluid(), IATEsource::otherPhase(), IATEsource::phase(), and phaseSystem::sigma().

Here is the call graph for this function:

◆ Ur()

Foam::tmp< Foam::volScalarField > Ur ( ) const

Return the bubble relative velocity.

Definition at line 72 of file IATEsource.C.

References IOobject::db(), objectRegistry::lookupObject(), Foam::mag(), Foam::max(), Foam::pow(), Foam::pow025(), rho, Foam::constant::physicoChemical::sigma, Foam::sqr(), and Foam::sqrt().

Here is the call graph for this function:

◆ Ut()

Foam::tmp< Foam::volScalarField > Ut ( ) const

Return the bubble turbulent velocity.

Definition at line 89 of file IATEsource.C.

References k, and Foam::sqrt().

Here is the call graph for this function:

◆ Re()

Foam::tmp< Foam::volScalarField > Re ( ) const

Return the bubble Reynolds number.

Definition at line 95 of file IATEsource.C.

References Foam::e, and Foam::max().

Here is the call graph for this function:

◆ CD()

Foam::tmp< Foam::volScalarField > CD ( ) const

Return the bubble drag coefficient.

Definition at line 101 of file IATEsource.C.

References Foam::max(), Foam::min(), Foam::pow(), and Foam::Re().

Here is the call graph for this function:

◆ Mo()

Foam::tmp< Foam::volScalarField > Mo ( ) const

Return the bubble Morton number.

Definition at line 119 of file IATEsource.C.

References IOobject::db(), objectRegistry::lookupObject(), Foam::mag(), Foam::pow3(), Foam::pow4(), rho, Foam::constant::physicoChemical::sigma, and Foam::sqr().

Here is the call graph for this function:

◆ Eo()

Foam::tmp< Foam::volScalarField > Eo ( ) const

Return the bubble Eotvos number.

Definition at line 131 of file IATEsource.C.

References IOobject::db(), objectRegistry::lookupObject(), Foam::mag(), Foam::constant::physicoChemical::sigma, and Foam::sqr().

Here is the call graph for this function:

◆ We()

Foam::tmp< Foam::volScalarField > We ( ) const

Return the bubble turbulent Weber number.

Definition at line 143 of file IATEsource.C.

References Foam::constant::physicoChemical::sigma, and Foam::sqr().

Here is the call graph for this function:

◆ R()

virtual tmp<fvScalarMatrix> R ( volScalarField & kappai ) const

pure virtual

Implemented in wakeEntrainmentCoalescence, turbulentBreakUp, and randomCoalescence.

Member Data Documentation

◆ iate_

const IATE& iate_

protected

Reference to the IATE this source applies to.

Definition at line 61 of file IATEsource.H.

Referenced by IATEsource::fluid(), and IATEsource::phase().

The documentation for this class was generated from the following files:

applications/modules/multiphaseEuler/phaseSystem/diameterModels/IATE/IATEsources/IATEsource/IATEsource.H
applications/modules/multiphaseEuler/phaseSystem/diameterModels/IATE/IATEsources/IATEsource/IATEsource.C
