Cyclic patch for post-processing. More...

Inheritance diagram for cyclicPointPatch:

[legend]

Collaboration diagram for cyclicPointPatch:

Public Member Functions
	TypeName (cyclicPolyPatch::typeName_())
	Runtime type information. More...

	cyclicPointPatch (const polyPatch &patch, const pointBoundaryMesh &bm)
	Construct from components. More...

	cyclicPointPatch (const cyclicPointPatch &)=delete
	Disallow default bitwise copy construction. More...

virtual	~cyclicPointPatch ()
	Destructor. More...

const cyclicPolyPatch &	cyclicPatch () const
	Return the underlying cyclicPolyPatch. More...

const cyclicPointPatch &	nbrPatch () const
	Return neighbour point patch. More...

virtual const transformer &	transform () const
	Return transformation between the coupled patches. More...

virtual const edgeList &	transformPairs () const
	Return the set of pairs of points that require transformation. More...

void	operator= (const cyclicPointPatch &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from coupledFacePointPatch
	TypeName (coupledPolyPatch::typeName_())
	Runtime type information. More...

	coupledFacePointPatch (const polyPatch &patch, const pointBoundaryMesh &bm)
	Construct from components. More...

	coupledFacePointPatch (const coupledFacePointPatch &)=delete
	Disallow default bitwise copy construction. More...

virtual	~coupledFacePointPatch ()
	Destructor. More...

void	operator= (const coupledFacePointPatch &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from facePointPatch
	TypeName (polyPatch::typeName_())
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, facePointPatch, polyPatch,(const polyPatch &patch, const pointBoundaryMesh &bm),(patch, bm))

	facePointPatch (const polyPatch &, const pointBoundaryMesh &)
	Construct from polyPatch. More...

	facePointPatch (const facePointPatch &)=delete
	Disallow default bitwise copy construction. More...

virtual	~facePointPatch ()
	Destructor. More...

const polyPatch &	patch () const
	Return the polyPatch. More...

virtual const word &	name () const
	Return name. More...

virtual label	size () const
	Return size. More...

virtual label	index () const
	Return the index of this patch in the pointBoundaryMesh. More...

virtual bool	coupled () const
	Return true if this patch field is coupled. More...

virtual const labelList &	meshPoints () const
	Return mesh points. More...

virtual const pointField &	localPoints () const
	Return pointField of points in patch. More...

virtual const vectorField &	pointNormals () const
	Return point unit normals. More...

void	operator= (const facePointPatch &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from pointPatch
	TypeName ("basePatch")
	Runtime type information. More...

	pointPatch (const pointBoundaryMesh &bm)

	pointPatch (const pointPatch &)=delete
	Disallow default bitwise copy construction. More...

virtual	~pointPatch ()
	Destructor. More...

const pointBoundaryMesh &	boundaryMesh () const
	Return boundaryMesh reference. More...

virtual void	applyConstraint (const label pointi, pointConstraint &) const
	Accumulate the effect of constraint direction of this patch. More...

void	operator= (const pointPatch &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from coupledPointPatch
	TypeName (coupledPolyPatch::typeName_())
	Runtime type information. More...

	coupledPointPatch (const pointBoundaryMesh &bm)
	Construct from components. More...

	coupledPointPatch (const coupledPointPatch &)=delete
	Disallow default bitwise copy construction. More...

virtual	~coupledPointPatch ()
	Destructor. More...

void	operator= (const coupledPointPatch &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Static Public Member Functions inherited from facePointPatch
static autoPtr< facePointPatch >	New (const polyPatch &, const pointBoundaryMesh &)
	Return a pointer to a new patch created on freestore from polyPatch. More...

Protected Attributes inherited from facePointPatch
const polyPatch &	polyPatch_
	Reference to the underlying polyPatch. More...

Detailed Description

Cyclic patch for post-processing.

Source files

Definition at line 50 of file cyclicPointPatch.H.

Constructor & Destructor Documentation

◆ cyclicPointPatch() [1/2]

cyclicPointPatch	(	const polyPatch &	patch,
		const pointBoundaryMesh &	bm
	)

Construct from components.

Definition at line 81 of file cyclicPointPatch.C.

◆ cyclicPointPatch() [2/2]

cyclicPointPatch ( const cyclicPointPatch & )

delete

Disallow default bitwise copy construction.

◆ ~cyclicPointPatch()

~cyclicPointPatch ( )

virtual

Destructor.

Definition at line 94 of file cyclicPointPatch.C.

Member Function Documentation

◆ TypeName()

TypeName ( cyclicPolyPatch::typeName_() )

Runtime type information.

◆ cyclicPatch()

const cyclicPolyPatch& cyclicPatch ( ) const

inline

Return the underlying cyclicPolyPatch.

Definition at line 109 of file cyclicPointPatch.H.

◆ nbrPatch()

const cyclicPointPatch& nbrPatch ( ) const

inline

Return neighbour point patch.

Definition at line 115 of file cyclicPointPatch.H.

References pointPatch::boundaryMesh(), cyclicPolyPatch::nbrPatchIndex(), and patchi.

Here is the call graph for this function:

◆ transform()

virtual const transformer& transform ( ) const

inlinevirtual

Return transformation between the coupled patches.

Definition at line 123 of file cyclicPointPatch.H.

References cyclicPolyPatch::transform().

Referenced by cyclicPointPatchField< Type >::transform().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ transformPairs()

const Foam::edgeList & transformPairs ( ) const

virtual

Return the set of pairs of points that require transformation.

and/or mapping. First index is on this patch, second on the neighbour patch.

Definition at line 100 of file cyclicPointPatch.C.

◆ operator=()

void operator= ( const cyclicPointPatch & )
