temperatureDependent Class Reference

Temperature-dependent contact angle model. More...

Inheritance diagram for temperatureDependent:

Collaboration diagram for temperatureDependent:

Public Member Functions
	TypeName ("temperatureDependent")
	Runtime type information. More...
	temperatureDependent (const dictionary &dict)
	Construct from dictionary. More...
virtual autoPtr< contactAngleModel >	clone () const
	Construct and return a clone. More...
virtual	~temperatureDependent ()
	Destructor. More...
virtual tmp< scalarField >	cosTheta (const fvPatchVectorField &Up, const vectorField &nHat) const
	Cosine of the contact angle. More...
virtual void	write (Ostream &os) const
	Write data in dictionary format. More...
Public Member Functions inherited from contactAngleModel
	TypeName ("contactAngleModel")
	Runtime type information. More...
	declareRunTimeSelectionTable (autoPtr, contactAngleModel, dictionary,(const dictionary &dict),(dict))
	contactAngleModel ()
virtual	~contactAngleModel ()
	Destructor. More...

Additional Inherited Members
Static Public Member Functions inherited from contactAngleModel
static autoPtr< contactAngleModel >	New (const dictionary &dict)
Static Protected Member Functions inherited from contactAngleModel
static const dictionary &	contactAngleDict (const dictionary &dict)

Detailed Description

Temperature-dependent contact angle model.

The contact angle is evaluated from the specified Foam::Function1 for the temperature field looked-up from the mesh database the name of which may optionally be provided.

Usage

Property	Description	Required	Default value
T	Temperature field name	no	T
contactAngle	contact angle function	yes

Example of the contact angle specification:

        contactAngle
        {
            type                temperatureDependent;
            contactAngle        constant 0.07;
        }

See also

Foam::contactAngleModel Foam::Function1

Source files

• temperatureDependentContactAngle.H
• temperatureDependentContactAngle.C

Definition at line 91 of file temperatureDependentContactAngle.H.

Constructor & Destructor Documentation

temperatureDependent()

temperatureDependent

(

const dictionary &

dict

)

Construct from dictionary.

Definition at line 49 of file temperatureDependentContactAngle.C.

Referenced by temperatureDependent::clone().

Here is the caller graph for this function:

~temperatureDependent()

~temperatureDependent ( )

virtual

Destructor.

Definition at line 61 of file temperatureDependentContactAngle.C.

Member Function Documentation

TypeName()

TypeName

(

"temperatureDependent"

)

Runtime type information.

clone()

virtual autoPtr<contactAngleModel> clone ( ) const

inlinevirtual

Construct and return a clone.

Implements contactAngleModel.

Definition at line 116 of file temperatureDependentContactAngle.H.

References temperatureDependent::temperatureDependent().

Here is the call graph for this function:

cosTheta()

Foam::tmp< Foam::scalarField > cosTheta ( const fvPatchVectorField &  Up, const vectorField &  nHat  ) const

virtual

Cosine of the contact angle.

Implements contactAngleModel.

Definition at line 68 of file temperatureDependentContactAngle.C.

References Foam::cos(), fvPatch::lookupPatchField(), and fvPatchField< Type >::patch().

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Write data in dictionary format.

Implements contactAngleModel.

Definition at line 85 of file temperatureDependentContactAngle.C.

References Foam::writeEntry().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/twoPhaseModels/interfaceProperties/contactAngleModels/temperatureDependent/temperatureDependentContactAngle.H
• src/twoPhaseModels/interfaceProperties/contactAngleModels/temperatureDependent/temperatureDependentContactAngle.C
