alphatWallFunctionFvPatchScalarField Class Reference

This boundary condition provides a turbulent thermal diffusivity condition when using wall functions. More...

Inheritance diagram for alphatWallFunctionFvPatchScalarField:
Inheritance graph
[legend]
Collaboration diagram for alphatWallFunctionFvPatchScalarField:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("compressible::alphatWallFunction")
 Runtime type information. More...

 alphatWallFunctionFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
 Construct from patch, internal field and dictionary. More...

 alphatWallFunctionFvPatchScalarField (const alphatWallFunctionFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fieldMapper &)
 Construct by mapping given. More...

 alphatWallFunctionFvPatchScalarField (const alphatWallFunctionFvPatchScalarField &)=delete
 Disallow copy without setting internal field reference. More...

 alphatWallFunctionFvPatchScalarField (const alphatWallFunctionFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
 Copy constructor setting internal field reference. More...

virtual tmp< fvPatchScalarField > clone (const DimensionedField< scalar, volMesh > &iF) const
 Construct and return a clone setting internal field reference. More...

virtual void map (const fvPatchScalarField &, const fieldMapper &)
 Map the given fvPatchField onto this fvPatchField. More...

virtual void updateCoeffs ()
 Update the coefficients associated with the patch field. More...

virtual void write (Ostream &) const
 Write. More...


Detailed Description

This boundary condition provides a turbulent thermal diffusivity condition when using wall functions.

- replicates OpenFOAM v1.5 (and earlier) behaviour

The turbulent thermal diffusivity calculated using:

\[ \alpha_t = \frac{\mu_t}{Pr_t} \]

where

$ \alpha_t$ = turbulence thermal diffusivity
$ \mu_t $ = turbulence viscosity
$ Pr_t $ = turblent Prandtl number
Usage
Property Description Required Default value
nut turbulence viscosity field name no nut
Prt turbulent Prandtl number no 0.85

Example of the boundary condition specification:

    <patchName>
    {
        type            alphatWallFunction;
        nut             nut;
        Prt             0.85;
        value           uniform 0; // optional value entry
    }
See also
Foam::fixedValueFvPatchField
Source files

Definition at line 114 of file alphatWallFunctionFvPatchScalarField.H.

Constructor & Destructor Documentation

◆ alphatWallFunctionFvPatchScalarField() [1/4]

alphatWallFunctionFvPatchScalarField ( const fvPatch &  p,
const DimensionedField< scalar, volMesh > &  iF,
const dictionary &  dict
)

Construct from patch, internal field and dictionary.

Definition at line 39 of file alphatWallFunctionFvPatchScalarField.C.

Referenced by alphatWallFunctionFvPatchScalarField::clone().

Here is the caller graph for this function:

◆ alphatWallFunctionFvPatchScalarField() [2/4]

alphatWallFunctionFvPatchScalarField ( const alphatWallFunctionFvPatchScalarField &  ptf,
const fvPatch &  p,
const DimensionedField< scalar, volMesh > &  iF,
const fieldMapper &  mapper
)

Construct by mapping given.

alphatWallFunctionFvPatchScalarField onto a new patch

Definition at line 51 of file alphatWallFunctionFvPatchScalarField.C.

◆ alphatWallFunctionFvPatchScalarField() [3/4]

alphatWallFunctionFvPatchScalarField ( const alphatWallFunctionFvPatchScalarField &  )
delete

Disallow copy without setting internal field reference.

◆ alphatWallFunctionFvPatchScalarField() [4/4]

alphatWallFunctionFvPatchScalarField ( const alphatWallFunctionFvPatchScalarField &  awfpsf,
const DimensionedField< scalar, volMesh > &  iF
)

Copy constructor setting internal field reference.

Definition at line 66 of file alphatWallFunctionFvPatchScalarField.C.

Member Function Documentation

◆ TypeName()

TypeName ( "compressible::alphatWallFunction"  )

Runtime type information.

◆ clone()

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, volMesh > &  iF) const
inlinevirtual

Construct and return a clone setting internal field reference.

Definition at line 165 of file alphatWallFunctionFvPatchScalarField.H.

References alphatWallFunctionFvPatchScalarField::alphatWallFunctionFvPatchScalarField().

Here is the call graph for this function:

◆ map()

void map ( const fvPatchScalarField &  ptf,
const fieldMapper &  mapper
)
virtual

Map the given fvPatchField onto this fvPatchField.

Definition at line 79 of file alphatWallFunctionFvPatchScalarField.C.

◆ updateCoeffs()

void updateCoeffs ( )
virtual

Update the coefficients associated with the patch field.

Definition at line 89 of file alphatWallFunctionFvPatchScalarField.C.

References fluidThermophysicalTransportModel::momentumTransport(), Foam::operator==(), and patchi.

Here is the call graph for this function:

◆ write()

void write ( Ostream &  os) const
virtual

Write.

Definition at line 117 of file alphatWallFunctionFvPatchScalarField.C.

References fvPatchField< Type >::write(), and Foam::writeEntry().

Here is the call graph for this function:
The documentation for this class was generated from the following files:
