Standard k-epsilon turbulence model with additional source terms corresponding to PDR basic drag model (basic.H) More...

Inheritance diagram for PDRkEpsilon:

[legend]

Collaboration diagram for PDRkEpsilon:

[legend]

Public Member Functions
	TypeName ("PDRkEpsilon")
	Runtime type information. More...

	PDRkEpsilon (const geometricOneField &alpha, const volScalarField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &transport, const word &modelName=typeName)
	Construct from components. More...

virtual	~PDRkEpsilon ()
	Destructor. More...

void	correct ()
	Solve the turbulence equations and correct the turbulence viscosity. More...

bool	read ()
	Read momentumTransport dictionary. More...

Public Member Functions inherited from kEpsilon< compressible::momentumTransportModel >
	TypeName ("kEpsilon")
	Runtime type information. More...

	kEpsilon (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity, const word &type=typeName)
	Construct from components. More...

	kEpsilon (const kEpsilon &)=delete
	Disallow default bitwise copy construction. More...

virtual	~kEpsilon ()
	Destructor. More...

tmp< volScalarField >	DkEff () const
	Return the effective diffusivity for k. More...

tmp< volScalarField >	DepsilonEff () const
	Return the effective diffusivity for epsilon. More...

virtual tmp< volScalarField >	k () const
	Return the turbulence kinetic energy. More...

virtual tmp< volScalarField >	epsilon () const
	Return the turbulence kinetic energy dissipation rate. More...

virtual tmp< volScalarField >	omega () const
	Return the turbulence specific dissipation rate. More...

void	operator= (const kEpsilon &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from eddyViscosity< BasicMomentumTransportModel >
	eddyViscosity (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)
	Construct from components. More...

virtual	~eddyViscosity ()
	Destructor. More...

virtual tmp< volScalarField >	nut () const
	Return the turbulence viscosity. More...

virtual tmp< scalarField >	nut (const label patchi) const
	Return the turbulence viscosity on patch. More...

virtual tmp< volSymmTensorField >	R () const
	Return the Reynolds stress tensor [m^2/s^2]. More...

virtual void	validate ()
	Validate the turbulence fields after construction. More...

Public Member Functions inherited from linearViscousStress< BasicMomentumTransportModel >
	linearViscousStress (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)
	Construct from components. More...

virtual	~linearViscousStress ()
	Destructor. More...

virtual tmp< surfaceVectorField >	devTau () const
	Return the effective surface stress. More...

virtual tmp< fvVectorMatrix >	divDevTau (volVectorField &U) const
	Return the source term for the momentum equation. More...

virtual tmp< fvVectorMatrix >	divDevTau (const volScalarField &rho, volVectorField &U) const
	Return the source term for the momentum equation. More...

template<class RhoFieldType >
Foam::tmp< Foam::fvVectorMatrix >	DivDevTau (const RhoFieldType &rho, volVectorField &U) const

Additional Inherited Members
Public Types inherited from kEpsilon< compressible::momentumTransportModel >
typedef BasicMomentumTransportModel::alphaField	alphaField

typedef BasicMomentumTransportModel::rhoField	rhoField

Public Types inherited from eddyViscosity< BasicMomentumTransportModel >
typedef BasicMomentumTransportModel::alphaField	alphaField

typedef BasicMomentumTransportModel::rhoField	rhoField

Public Types inherited from linearViscousStress< BasicMomentumTransportModel >
typedef BasicMomentumTransportModel::alphaField	alphaField

typedef BasicMomentumTransportModel::rhoField	rhoField

Protected Member Functions inherited from kEpsilon< compressible::momentumTransportModel >
tmp< volScalarField >	boundEpsilon ()
	Bound epsilon and return Cmu*sqr(k) for nut. More...

virtual tmp< fvScalarMatrix >	kSource () const
	Source term for the k equation. More...

virtual tmp< fvScalarMatrix >	epsilonSource () const
	Source term for the epsilon equation. More...

Protected Member Functions inherited from linearViscousStress< BasicMomentumTransportModel >
template<class RhoFieldType >
tmp< fvVectorMatrix >	DivDevTau (const RhoFieldType &rho, volVectorField &U) const
	Return the source term for the momentum equation. More...

Protected Attributes inherited from kEpsilon< compressible::momentumTransportModel >
dimensionedScalar	Cmu_

dimensionedScalar	C1_

dimensionedScalar	C2_

dimensionedScalar	C3_

dimensionedScalar	sigmak_

dimensionedScalar	sigmaEps_

volScalarField	k_

volScalarField	epsilon_

Protected Attributes inherited from eddyViscosity< BasicMomentumTransportModel >
volScalarField	nut_

Detailed Description

Standard k-epsilon turbulence model with additional source terms corresponding to PDR basic drag model (basic.H)

The default model coefficients correspond to the following:

    PDRkEpsilonCoeffs
    {
        Cmu         0.09;
        C1          1.44;
        C2          1.92;
        C3          -0.33;  // only for compressible
        C4          0.1;
        sigmak      1.0;    // only for compressible
        sigmaEps    1.3;
        Prt         1.0;    // only for compressible
    }

The turbulence source term $G_{R}$ appears in the $\kappa-\epsilon$ equation for the generation of turbulence due to interaction with unresolved obstacles.

In the $\epsilon$ equation $C_{1} G_{R}$ is added as a source term.

In the $\kappa$ equation $G_{R}$ is added as a source term.

Source files

Definition at line 78 of file PDRkEpsilon.H.

Constructor & Destructor Documentation

◆ PDRkEpsilon()

PDRkEpsilon	(	const geometricOneField &	alpha,
		const volScalarField &	rho,
		const volVectorField &	U,
		const surfaceScalarField &	alphaRhoPhi,
		const surfaceScalarField &	phi,
		const viscosity &	transport,
		const word &	modelName = `typeName`
	)

Construct from components.

Definition at line 64 of file PDRkEpsilon.C.

◆ ~PDRkEpsilon()

~PDRkEpsilon ( )

virtual

Destructor.

Definition at line 92 of file PDRkEpsilon.C.

Member Function Documentation

◆ TypeName()

TypeName ( "PDRkEpsilon" )

Runtime type information.

◆ correct()

void correct ( )

virtual

Solve the turbulence equations and correct the turbulence viscosity.

Reimplemented from kEpsilon< compressible::momentumTransportModel >.

Definition at line 112 of file PDRkEpsilon.C.

References Foam::bound(), GeometricField< Type, GeoMesh, PrimitiveField >::boundaryFieldRef(), kEpsilon< compressible::momentumTransportModel >::C1_, kEpsilon< compressible::momentumTransportModel >::C2_, tmp< T >::clear(), kEpsilon< compressible::momentumTransportModel >::Cmu_, RASModel< BasicMomentumTransportModel >::correct(), GeometricField< Type, GeoMesh, PrimitiveField >::correctBoundaryConditions(), IOobject::db(), Foam::fvm::ddt(), kEpsilon< compressible::momentumTransportModel >::DepsilonEff(), Foam::dev(), Foam::dimLength, Foam::fvc::div(), Foam::fvm::div(), kEpsilon< compressible::momentumTransportModel >::DkEff(), kEpsilon< compressible::momentumTransportModel >::epsilon_, Foam::constant::universal::G, Foam::fvc::grad(), Foam::fvc::interpolate(), kEpsilon< compressible::momentumTransportModel >::k_, Foam::fvm::laplacian(), objectRegistry::lookupObject(), eddyViscosity< BasicMomentumTransportModel >::nut_, Foam::pow(), tmp< T >::ref(), Foam::solve(), Foam::fvm::Sp(), Foam::sqr(), Foam::sqrt(), Foam::fvm::SuSp(), Foam::twoSymm(), and GeometricBoundaryField< Type, GeoMesh, PrimitiveField >::updateCoeffs().

Here is the call graph for this function:

◆ read()

bool read ( )

virtual

Read momentumTransport dictionary.

Reimplemented from kEpsilon< compressible::momentumTransportModel >.

Definition at line 98 of file PDRkEpsilon.C.

References RASModel< BasicMomentumTransportModel >::read(), and dimensioned< Type >::readIfPresent().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

applications/legacy/combustion/PDRFoam/PDRModels/turbulence/PDRkEpsilon/PDRkEpsilon.H
applications/legacy/combustion/PDRFoam/PDRModels/turbulence/PDRkEpsilon/PDRkEpsilon.C
