An abstract class for methods of chemical mechanism reduction. More...

Inheritance diagram for chemistryReductionMethod< ThermoType >:

[legend]

Collaboration diagram for chemistryReductionMethod< ThermoType >:

Public Member Functions
	TypeName ("chemistryReductionMethod")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, chemistryReductionMethod, dictionary,(const dictionary &dict, chemistryModel< ThermoType > &chemistry),(dict, chemistry))

	chemistryReductionMethod (chemistryModel< ThermoType > &chemistry)
	Construct from components. More...

	chemistryReductionMethod (const dictionary &dict, chemistryModel< ThermoType > &chemistry)
	Construct from components. More...

virtual	~chemistryReductionMethod ()
	Destructor. More...

virtual bool	active () const
	Return mechanism reduction active. More...

label	nSpecie ()
	Return the number of species. More...

label	nActiveSpecies () const
	Return the number of active species. More...

scalar	tolerance () const
	Return the tolerance. More...

const List< bool > &	activeSpecies () const
	Return the active species. More...

bool	reactionDisabled (const label i) const
	Return whether or not a reaction is disabled. More...

virtual void	reduceMechanism (const scalar p, const scalar T, const scalarField &c, List< label > &ctos, DynamicList< label > &stoc, const label li)=0
	Reduce the mechanism. More...

virtual void	update ()
	... More...

Static Public Member Functions
static autoPtr< chemistryReductionMethod< ThermoType > >	New (const dictionary &dict, chemistryModel< ThermoType > &chemistry)

Protected Member Functions
const dictionary &	coeffDict (const dictionary &dict) const
	Protected Member Functions. More...

void	initReduceMechanism ()
	Initialise reduction of the mechanism. More...

void	endReduceMechanism (List< label > &ctos, DynamicList< label > &stoc)
	End reduction of the mechanism. More...

Protected Attributes
chemistryModel< ThermoType > &	chemistry_
	Reference to the chemistry model. More...

const label	nSpecie_
	Total number of species. More...

label	nActiveSpecies_
	Number of active species. More...

Field< bool >	reactionsDisabled_
	List of disabled reactions (disabled = true) More...

List< bool >	activeSpecies_
	List of active species (active = true) More...

Detailed Description

template<class ThermoType>
class Foam::chemistryReductionMethod< ThermoType >

An abstract class for methods of chemical mechanism reduction.

Source files

Definition at line 59 of file chemistryReductionMethod.H.

Constructor & Destructor Documentation

◆ chemistryReductionMethod() [1/2]

chemistryReductionMethod ( Foam::chemistryModel< ThermoType > & chemistry )

Construct from components.

Definition at line 32 of file chemistryReductionMethod.C.

◆ chemistryReductionMethod() [2/2]

chemistryReductionMethod	(	const dictionary &	dict,
		Foam::chemistryModel< ThermoType > &	chemistry
	)

Construct from components.

Definition at line 51 of file chemistryReductionMethod.C.

References chemistry.

◆ ~chemistryReductionMethod()

~chemistryReductionMethod

virtual

Destructor.

Definition at line 85 of file chemistryReductionMethod.C.

Member Function Documentation

◆ coeffDict()

const dictionary& coeffDict ( const dictionary & dict ) const

inlineprotected

Protected Member Functions.

Definition at line 83 of file chemistryReductionMethod.H.

References dict.

Referenced by DAC< ThermoType >::DAC(), DRG< ThermoType >::DRG(), DRGEP< ThermoType >::DRGEP(), EFA< ThermoType >::EFA(), and PFA< ThermoType >::PFA().

Here is the caller graph for this function:

◆ initReduceMechanism()

void initReduceMechanism

protected

Initialise reduction of the mechanism.

Definition at line 92 of file chemistryReductionMethod.C.

Referenced by DRGEP< ThermoType >::DRGEP(), DAC< ThermoType >::reduceMechanism(), DRG< ThermoType >::reduceMechanism(), EFA< ThermoType >::reduceMechanism(), and PFA< ThermoType >::reduceMechanism().

Here is the caller graph for this function:

◆ endReduceMechanism()

void endReduceMechanism	(	List< label > &	ctos,
		DynamicList< label > &	stoc
	)

protected

End reduction of the mechanism.

Definition at line 102 of file chemistryReductionMethod.C.

References Foam::count(), forAll, nSpecie, Foam::R(), s(), and DynamicList< T, SizeInc, SizeMult, SizeDiv >::setSize().

Referenced by DAC< ThermoType >::reduceMechanism(), DRG< ThermoType >::reduceMechanism(), DRGEP< ThermoType >::reduceMechanism(), EFA< ThermoType >::reduceMechanism(), and PFA< ThermoType >::reduceMechanism().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ TypeName()

TypeName ( "chemistryReductionMethod< ThermoType >" )

Runtime type information.

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		chemistryReductionMethod< ThermoType >	,
		dictionary	,
		(const dictionary &dict, chemistryModel< ThermoType > &chemistry)	,
		(dict, chemistry)
	)

◆ New()

Foam::autoPtr< Foam::chemistryReductionMethod< ThermoType > > New	(	const dictionary &	dict,
		chemistryModel< ThermoType > &	chemistry
	)

static

Definition at line 34 of file chemistryReductionMethodNew.C.

References List< T >::append(), chemistry, dict, Foam::endl(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, forAll, Foam::Info, and dictionary::lookup().

Here is the call graph for this function:

◆ active()

virtual bool active ( ) const

inlinevirtual

Return mechanism reduction active.

Reimplemented in none< ThermoType >.

Definition at line 176 of file chemistryReductionMethod.H.

◆ nSpecie()

Foam::label nSpecie

inline

Return the number of species.

Definition at line 31 of file chemistryReductionMethodI.H.

Referenced by DAC< ThermoType >::DAC(), DRGEP< ThermoType >::DRGEP(), and EFA< ThermoType >::EFA().

Here is the caller graph for this function:

◆ nActiveSpecies()

Foam::label nActiveSpecies

inline

Return the number of active species.

Definition at line 39 of file chemistryReductionMethodI.H.

◆ tolerance()

Foam::scalar tolerance

inline

Return the tolerance.

Definition at line 55 of file chemistryReductionMethodI.H.

◆ activeSpecies()

const Foam::List< bool > & activeSpecies

inline

Return the active species.

Definition at line 47 of file chemistryReductionMethodI.H.

◆ reactionDisabled()

bool reactionDisabled ( const label i ) const

inline

Return whether or not a reaction is disabled.

Definition at line 62 of file chemistryReductionMethodI.H.

◆ reduceMechanism()

virtual void reduceMechanism	(	const scalar	p,
		const scalar	T,
		const scalarField &	c,
		List< label > &	ctos,
		DynamicList< label > &	stoc,
		const label	li
	)

pure virtual

Reduce the mechanism.

Implemented in PFA< ThermoType >, none< ThermoType >, EFA< ThermoType >, DRGEP< ThermoType >, DRG< ThermoType >, and DAC< ThermoType >.

◆ update()

void update

virtual

...

Reimplemented in none< ThermoType >.

Definition at line 173 of file chemistryReductionMethod.C.

References Foam::endl().

Here is the call graph for this function:

Member Data Documentation

◆ chemistry_

chemistryModel<ThermoType>& chemistry_

protected

Reference to the chemistry model.

Definition at line 66 of file chemistryReductionMethod.H.

Referenced by DAC< ThermoType >::DAC().

◆ nSpecie_

const label nSpecie_

protected

Total number of species.

Definition at line 69 of file chemistryReductionMethod.H.

◆ nActiveSpecies_

label nActiveSpecies_

protected

Number of active species.

Definition at line 72 of file chemistryReductionMethod.H.

◆ reactionsDisabled_

Field<bool> reactionsDisabled_

protected

List of disabled reactions (disabled = true)

Definition at line 75 of file chemistryReductionMethod.H.

◆ activeSpecies_

List<bool> activeSpecies_

protected

List of active species (active = true)

Definition at line 78 of file chemistryReductionMethod.H.

The documentation for this class was generated from the following files:

src/thermophysicalModels/chemistryModel/chemistryModel/reduction/chemistryReductionMethod/chemistryReductionMethod.H
src/thermophysicalModels/chemistryModel/chemistryModel/reduction/chemistryReductionMethod/chemistryReductionMethod.C
src/thermophysicalModels/chemistryModel/chemistryModel/reduction/chemistryReductionMethod/chemistryReductionMethodI.H
src/thermophysicalModels/chemistryModel/chemistryModel/reduction/chemistryReductionMethod/chemistryReductionMethodNew.C
