Abstract base class for cavitation models. More...

Inheritance diagram for cavitationModel:

[legend]

Collaboration diagram for cavitationModel:

Public Member Functions
	TypeName ("cavitationModel")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, cavitationModel, dictionary,(const dictionary &dict, const incompressibleTwoPhases &phases),(dict, phases))

	cavitationModel (const dictionary &dict, const incompressibleTwoPhases &phases)
	Construct for phases. More...

virtual	~cavitationModel ()
	Destructor. More...

const dimensionedScalar &	pSat () const
	Return the saturation vapour pressure. More...

virtual Pair< tmp< volScalarField::Internal > >	mDotcvAlpha () const =0
	Return the mass condensation and vaporisation rates as a. More...

virtual Pair< tmp< volScalarField::Internal > >	mDotcvP () const =0
	Return the mass condensation and vaporisation rates as coefficients. More...

Pair< tmp< volScalarField::Internal > >	mDot12Alpha () const
	Return the mass transfer rates of the two phases as coefficients to. More...

Pair< tmp< volScalarField::Internal > >	mDot12P () const
	Return the mass transfer rates of the two phases as coefficients to. More...

virtual void	correct ()=0
	Correct the cavitation model. More...

virtual bool	read (const dictionary &dict)=0
	Read the dictionary and update. More...

Static Public Member Functions
static autoPtr< cavitationModel >	New (const dictionary &dict, const incompressibleTwoPhases &phases)

Protected Member Functions
const volScalarField::Internal &	alphal () const
	Return the liquid density. More...

const volScalarField::Internal &	alphav () const
	Return the vapour density. More...

const dimensionedScalar &	rhol () const
	Return the liquid density. More...

const dimensionedScalar &	rhov () const
	Return the vapour density. More...

Protected Attributes
const incompressibleTwoPhases &	phases_
	Mixture properties. More...

const bool	liquidIndex_
	Index of the liquid. More...

dimensionedScalar	pSat_
	Saturation vapour pressure. More...

Detailed Description

Abstract base class for cavitation models.

Source files

Definition at line 50 of file cavitationModel.H.

Constructor & Destructor Documentation

◆ cavitationModel()

cavitationModel	(	const dictionary &	dict,
		const incompressibleTwoPhases &	phases
	)

Construct for phases.

Definition at line 40 of file cavitationModel.C.

◆ ~cavitationModel()

virtual ~cavitationModel ( )

inlinevirtual

Destructor.

Definition at line 133 of file cavitationModel.H.

Member Function Documentation

◆ alphal()

const volScalarField::Internal& alphal ( ) const

inlineprotected

Return the liquid density.

Definition at line 69 of file cavitationModel.H.

References twoPhases::alpha(), cavitationModel::liquidIndex_, and cavitationModel::phases_.

Here is the call graph for this function:

◆ alphav()

const volScalarField::Internal& alphav ( ) const

inlineprotected

Return the vapour density.

Definition at line 75 of file cavitationModel.H.

References twoPhases::alpha(), cavitationModel::liquidIndex_, and cavitationModel::phases_.

Here is the call graph for this function:

◆ rhol()

const dimensionedScalar& rhol ( ) const

inlineprotected

Return the liquid density.

Definition at line 81 of file cavitationModel.H.

References cavitationModel::liquidIndex_, cavitationModel::phases_, and incompressibleTwoPhases::rho().

Here is the call graph for this function:

◆ rhov()

const dimensionedScalar& rhov ( ) const

inlineprotected

Return the vapour density.

Definition at line 87 of file cavitationModel.H.

References cavitationModel::liquidIndex_, cavitationModel::phases_, and incompressibleTwoPhases::rho().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "cavitationModel" )

Runtime type information.

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		cavitationModel	,
		dictionary	,
		(const dictionary &dict, const incompressibleTwoPhases &phases)	,
		(dict, phases)
	)

◆ New()

Foam::autoPtr< Foam::cavitationModel > New	(	const dictionary &	dict,
		const incompressibleTwoPhases &	phases
	)

static

Definition at line 30 of file cavitationModelNew.C.

References dict, Foam::endl(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, Foam::Info, and Foam::nl.

Here is the call graph for this function:

◆ pSat()

const dimensionedScalar& pSat ( ) const

inline

Return the saturation vapour pressure.

Definition at line 140 of file cavitationModel.H.

References cavitationModel::pSat_.

◆ mDotcvAlpha()

virtual Pair<tmp<volScalarField::Internal> > mDotcvAlpha ( ) const

pure virtual

Return the mass condensation and vaporisation rates as a.

coefficient to multiply alphav for the condensation rate and a coefficient to multiply alphal for the vaporisation rate

Implemented in SchnerrSauer, Merkle, and Kunz.

◆ mDotcvP()

virtual Pair<tmp<volScalarField::Internal> > mDotcvP ( ) const

pure virtual

Return the mass condensation and vaporisation rates as coefficients.

to multiply (p - pSat)

Implemented in SchnerrSauer, Merkle, and Kunz.

◆ mDot12Alpha()

Pair<tmp<volScalarField::Internal> > mDot12Alpha ( ) const

inline

Return the mass transfer rates of the two phases as coefficients to.

multiply the volume fraction of the other phase

Definition at line 156 of file cavitationModel.H.

◆ mDot12P()

Pair<tmp<volScalarField::Internal> > mDot12P ( ) const

inline

Return the mass transfer rates of the two phases as coefficients to.

multiply (p - pSat)

Definition at line 163 of file cavitationModel.H.

◆ correct()

virtual void correct ( )

pure virtual

Correct the cavitation model.

Implemented in SchnerrSauer, Merkle, and Kunz.

◆ read()

bool read ( const dictionary & dict )

pure virtual

Read the dictionary and update.

Implemented in SchnerrSauer, Merkle, and Kunz.

Definition at line 54 of file cavitationModel.C.

References dict, and dictionary::lookup().

Referenced by Kunz::read(), Merkle::read(), and SchnerrSauer::read().

Here is the call graph for this function:

Here is the caller graph for this function:

Member Data Documentation

◆ phases_

const incompressibleTwoPhases& phases_

protected

Mixture properties.

Definition at line 57 of file cavitationModel.H.

Referenced by cavitationModel::alphal(), cavitationModel::alphav(), cavitationModel::rhol(), and cavitationModel::rhov().

◆ liquidIndex_

const bool liquidIndex_

protected

Index of the liquid.

Definition at line 60 of file cavitationModel.H.

Referenced by cavitationModel::alphal(), cavitationModel::alphav(), cavitationModel::rhol(), and cavitationModel::rhov().

◆ pSat_

dimensionedScalar pSat_

protected

Saturation vapour pressure.

Definition at line 63 of file cavitationModel.H.

Referenced by cavitationModel::pSat().

The documentation for this class was generated from the following files:

src/twoPhaseModels/incompressibleCavitation/cavitationModel/cavitationModel.H
src/twoPhaseModels/incompressibleCavitation/cavitationModel/cavitationModel.C
src/twoPhaseModels/incompressibleCavitation/cavitationModel/cavitationModelNew.C
