Projects the vertex onto the selected surfaces of the geometry provided as a searchableSurfaces object. More...

Inheritance diagram for projectVertex:

Collaboration diagram for projectVertex:

Public Member Functions
	TypeName ("project")
	Runtime type information. More...

	projectVertex (const dictionary &, const label index, const searchableSurfaceList &geometry, Istream &)
	Construct from Istream setting pointsList. More...

	projectVertex (const projectVertex &)=delete
	Disallow default bitwise copy construction. More...

virtual	~projectVertex ()
	Destructor. More...

virtual	operator point () const
	Project the given points onto the surface. More...

void	operator= (const projectVertex &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from pointVertex
	TypeName ("point")
	Runtime type information. More...

	pointVertex (const dictionary &, const label index, const searchableSurfaceList &geometry, Istream &)
	Construct from Istream setting pointsList. More...

virtual	~pointVertex ()
	Destructor. More...

Public Member Functions inherited from blockVertex
	TypeName ("blockVertex")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, blockVertex, Istream,(const dictionary &dict, const label index, const searchableSurfaceList &geometry, Istream &is),(dict, index, geometry, is))

	blockVertex ()
	Construct null. More...

virtual autoPtr< blockVertex >	clone () const
	Clone function. More...

virtual	~blockVertex ()
	Destructor. More...

Additional Inherited Members
Static Public Member Functions inherited from blockVertex
static autoPtr< blockVertex >	New (const dictionary &dict, const label index, const searchableSurfaceList &geometry, Istream &)
	New function which constructs and returns pointer to a blockVertex. More...

static label	read (Istream &, const dictionary &)
	Read vertex index with optional name lookup. More...

static void	write (Ostream &, const label, const dictionary &)
	Write vertex index with optional name backsubstitution. More...

Protected Attributes inherited from pointVertex
point	vertex_
	The vertex location. More...

Detailed Description

Projects the vertex onto the selected surfaces of the geometry provided as a searchableSurfaces object.

Source files

Definition at line 51 of file projectVertex.H.

Constructor & Destructor Documentation

◆ projectVertex() [1/2]

projectVertex	(	const dictionary &	dict,
		const label	index,
		const searchableSurfaceList &	geometry,
		Istream &	is
	)

Construct from Istream setting pointsList.

Definition at line 45 of file projectVertex.C.

References Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, searchableSurfaceList::findSurfaceID(), forAll, List< T >::setSize(), and List< T >::size().

Here is the call graph for this function:

◆ projectVertex() [2/2]

projectVertex ( const projectVertex & )

delete

Disallow default bitwise copy construction.

◆ ~projectVertex()

virtual ~projectVertex ( )

inlinevirtual

Destructor.

Definition at line 85 of file projectVertex.H.

Member Function Documentation

◆ TypeName()

TypeName ( "project" )

Runtime type information.

◆ operator point()

operator point ( ) const

virtual

Project the given points onto the surface.

Reimplemented from pointVertex.

Definition at line 74 of file projectVertex.C.

References searchableSurfacesQueries::bounds(), searchableSurfacesQueries::findNearest(), Foam::magSqr(), boundBox::max(), Foam::max(), boundBox::min(), Foam::min(), List< T >::size(), and boundBox::span().

Here is the call graph for this function:

◆ operator=()

void operator= ( const projectVertex & )
