Blending method for the case in which the continuous phase is always the same. E.g., for an air-particles flow, the air phase is always continuous. More...

Inheritance diagram for continuous:

[legend]

Collaboration diagram for continuous:

[legend]

Public Member Functions
	TypeName ("continuous")
	Runtime type information. More...

	continuous (const dictionary &dict, const phaseInterface &interface)
	Construct from a dictionary and an interface. More...

	~continuous ()
	Destructor. More...

virtual bool	canBeContinuous (const label index) const
	Return whether or not a phase can be considered continuous. More...

virtual bool	canSegregate () const
	Return whether or not this interface can segregate. More...

Public Member Functions inherited from blendingMethod
	TypeName ("blendingMethod")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, blendingMethod, dictionary,(const dictionary &dict, const phaseInterface &interface),(dict, interface))

	blendingMethod (const dictionary &dict, const phaseInterface &interface)
	Construct from a dictionary and an interface. More...

virtual	~blendingMethod ()
	Destructor. More...

tmp< volScalarField >	f1DispersedIn2 (const UPtrList< const volScalarField > &alphas) const
	Return the coefficient for models in which phase 1 is dispersed in. More...

tmp< volScalarField >	f2DispersedIn1 (const UPtrList< const volScalarField > &alphas) const
	Return the coefficient for models in which phase 2 is dispersed in. More...

tmp< volScalarField >	fDisplaced (const UPtrList< const volScalarField > &alphas) const
	Return the coefficient for when the interface is displaced by a. More...

Protected Member Functions
virtual tmp< volScalarField >	fContinuous (const UPtrList< const volScalarField > &alphas, const label phaseSet, const label systemSet) const
	Evaluate the blending function. More...

Protected Member Functions inherited from blendingMethod
tmp< volScalarField >	constant (const UPtrList< const volScalarField > &alphas, const scalar k) const
	Return a constant field with the given value. More...

tmp< volScalarField >	alpha (const UPtrList< const volScalarField > &alphas, const label set, const bool protect) const
	Get the volume fraction of the given set. More...

tmp< volScalarField >	parameter (const UPtrList< const volScalarField > &alphas, const label set, const Pair< blendingParameter > &parameters) const
	Get a blending parameter averaged for the given set. More...

tmp< volScalarField >	x (const UPtrList< const volScalarField > &alphas, const label phaseSet, const label systemSet) const
	Return the coordinate of the blending function. More...

virtual tmp< volScalarField >	f (const UPtrList< const volScalarField > &alphas, const label phaseSet, const label systemSet) const
	Evaluate the blending function. Filters out phases that cannot. More...

Additional Inherited Members
Static Public Member Functions inherited from blendingMethod
static autoPtr< blendingMethod >	New (const word &modelTypeName, const dictionary &dict, const phaseInterface &interface)

Static Protected Member Functions inherited from blendingMethod
static blendingParameter	readParameter (const word &name, const dictionary &dict, const Pair< scalar > &bounds, const bool allowNone)
	Read a parameter and check it lies within specified bounds. More...

static Pair< blendingParameter >	readParameters (const word &name, const dictionary &dict, const phaseInterface &interface, const Pair< scalar > &bounds, const bool allowNone)
	Read a parameter for each phase in the interface. More...

Protected Attributes inherited from blendingMethod
const phaseInterface	interface_
	Interface. More...

Detailed Description

Blending method for the case in which the continuous phase is always the same. E.g., for an air-particles flow, the air phase is always continuous.

This method requires the continuous phase to be specified.

Source files

Definition at line 53 of file continuous.H.

Constructor & Destructor Documentation

◆ continuous()

continuous	(	const dictionary &	dict,
		const phaseInterface &	interface
	)

Construct from a dictionary and an interface.

Definition at line 65 of file continuous.C.

◆ ~continuous()

~continuous ( )

Destructor.

Definition at line 78 of file continuous.C.

Member Function Documentation

◆ fContinuous()

Foam::tmp< Foam::volScalarField > fContinuous	(	const UPtrList< const volScalarField > &	alphas,
		const label	phaseSet,
		const label	systemSet
	)		const

protectedvirtual

Evaluate the blending function.

Implements blendingMethod.

Definition at line 44 of file continuous.C.

References blendingMethod::constant(), phaseInterface::contains(), phaseInterface::index(), and blendingMethod::interface_.

Here is the call graph for this function:

◆ TypeName()

TypeName ( "continuous" )

Runtime type information.

◆ canBeContinuous()

bool canBeContinuous ( const label index ) const

virtual

Return whether or not a phase can be considered continuous.

Implements blendingMethod.

Definition at line 84 of file continuous.C.

◆ canSegregate()

bool canSegregate ( ) const

virtual

Return whether or not this interface can segregate.

Implements blendingMethod.

Definition at line 90 of file continuous.C.

The documentation for this class was generated from the following files:

applications/modules/multiphaseEuler/phaseSystem/interfacialModels/BlendedInterfacialModel/blendingMethods/continuous/continuous.H
applications/modules/multiphaseEuler/phaseSystem/interfacialModels/BlendedInterfacialModel/blendingMethods/continuous/continuous.C
