Contact-angle boundary condition for multi-phase interface-capturing simulations. Sets of coefficients are given for the contact angle with each other phase. These coefficients can specify either a constant or a dynamic contact angle. More...

Inheritance diagram for alphaContactAngleFvPatchScalarField:

[legend]

Collaboration diagram for alphaContactAngleFvPatchScalarField:

[legend]

Classes
class	contactAngleProperties

Public Member Functions
	TypeName ("alphaContactAngle")
	Runtime type information. More...

	alphaContactAngleFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
	Construct from patch, internal field and dictionary. More...

	alphaContactAngleFvPatchScalarField (const alphaContactAngleFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fieldMapper &)
	Construct by mapping given alphaContactAngleFvPatchScalarField. More...

	alphaContactAngleFvPatchScalarField (const alphaContactAngleFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
	Construct as copy setting internal field reference. More...

virtual tmp< fvPatchScalarField >	clone (const DimensionedField< scalar, volMesh > &iF) const
	Construct and return a clone setting internal field reference. More...

const HashTable< contactAngleProperties > &	thetaProps () const
	Return the contact angle properties. More...

virtual void	write (Ostream &) const
	Write. More...

Detailed Description

Contact-angle boundary condition for multi-phase interface-capturing simulations. Sets of coefficients are given for the contact angle with each other phase. These coefficients can specify either a constant or a dynamic contact angle.

Usage

Property	Description	Required	Default value
`theta0`	Equilibrium contact angle	yes
`uTheta`	Velocity scale	no	none
`thetaA`	Limiting advancing contact angle	if uTheta	none
`thetaR`	Limiting receding contact angle	if uTheta	none

Example of the boundary condition specification:

    <patchName>
    {
        type            alphaContactAngle;

        contactAngleProperties
        {
            // Constant contact angle with air
            air
            {
                theta0          90;
            }

            // Dynamic contact angle with water
            oil
            {
                theta0          70;
                uTheta          1;
                thetaA          100;
                thetaR          50;
            }
        }

        value           uniform 0;
    }

Source files

Definition at line 113 of file alphaContactAngleFvPatchScalarField.H.

Constructor & Destructor Documentation

◆ alphaContactAngleFvPatchScalarField() [1/3]

alphaContactAngleFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const dictionary &	dict
	)

Construct from patch, internal field and dictionary.

Definition at line 45 of file alphaContactAngleFvPatchScalarField.C.

References dict, and forAllConstIter.

Referenced by alphaContactAngleFvPatchScalarField::clone().

Here is the caller graph for this function:

◆ alphaContactAngleFvPatchScalarField() [2/3]

alphaContactAngleFvPatchScalarField	(	const alphaContactAngleFvPatchScalarField &	gcpsf,
		const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const fieldMapper &	mapper
	)

Construct by mapping given alphaContactAngleFvPatchScalarField.

onto a new patch

Definition at line 32 of file alphaContactAngleFvPatchScalarField.C.

◆ alphaContactAngleFvPatchScalarField() [3/3]

alphaContactAngleFvPatchScalarField	(	const alphaContactAngleFvPatchScalarField &	gcpsf,
		const DimensionedField< scalar, volMesh > &	iF
	)

Construct as copy setting internal field reference.

Definition at line 66 of file alphaContactAngleFvPatchScalarField.C.

Member Function Documentation

◆ TypeName()

TypeName ( "alphaContactAngle" )

Runtime type information.

◆ clone()

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, volMesh > & iF ) const

inlinevirtual

Construct and return a clone setting internal field reference.

Definition at line 257 of file alphaContactAngleFvPatchScalarField.H.

References alphaContactAngleFvPatchScalarField::alphaContactAngleFvPatchScalarField().

Here is the call graph for this function:

◆ thetaProps()

const HashTable<contactAngleProperties>& thetaProps ( ) const

inline

Return the contact angle properties.

Definition at line 272 of file alphaContactAngleFvPatchScalarField.H.

Referenced by Foam::correctContactAngle().

Here is the caller graph for this function:

◆ write()

void write ( Ostream & os ) const

virtual

Write.

Definition at line 129 of file alphaContactAngleFvPatchScalarField.C.

References token::BEGIN_BLOCK, Foam::decrIndent(), token::END_BLOCK, Foam::endl(), forAllConstIter, Foam::incrIndent(), Foam::indent(), Foam::nl, Ostream::write(), fvPatchField< Type >::write(), Foam::writeEntry(), and Foam::writeKeyword().
