Public Member Functions | Static Public Member Functions | Protected Member Functions | List of all members
XiCorrModel Class Referenceabstract

Base class for ignition kernel flame wrinkling Xi correction. More...

Inheritance diagram for XiCorrModel:
Inheritance graph
[legend]

Public Member Functions

 TypeName ("XiCorrModel")
 Runtime type information. More...

 declareRunTimeSelectionTable (autoPtr, XiCorrModel, dictionary,(const fvMesh &mesh, const dictionary &dict),(mesh, dict))

 XiCorrModel (const fvMesh &mesh, const dictionary &dict)
 Construct from mesh and dictionary. More...

 XiCorrModel (const XiCorrModel &)=delete
 Disallow default bitwise copy construction. More...

virtual ~XiCorrModel ()
 Destructor. More...

virtual dimensionedScalar Ak (const dimensionedScalar &Vk) const =0
 Return the area of the ignition kernel. More...

virtual void XiCorr (volScalarField &Xi, const volScalarField &b, const volScalarField &mgb) const

virtual void topoChange (const polyTopoChangeMap &)
 Update topology using the given map. More...

virtual void mapMesh (const polyMeshMap &)
 Update from another mesh using the given map. More...

virtual void distribute (const polyDistributionMap &)
 Redistribute or update using the given distribution map. More...

virtual bool movePoints ()
 Update for mesh motion. More...

bool read (const dictionary &XiProperties)
 Update properties from the given XiProperties dictionary. More...

void operator= (const XiCorrModel &)=delete
 Disallow default bitwise assignment. More...


Static Public Member Functions

static autoPtr< XiCorrModel > New (const fvMesh &mesh, const dictionary &dict)
 Return a reference to the selected XiCorrModel model. More...


Protected Member Functions

virtual bool readCoeffs (const dictionary &dict)
 Update coefficients from given dictionary. More...


Detailed Description

Base class for ignition kernel flame wrinkling Xi correction.

Usage
Example usage:
XiCorr
{
    type            <type>;
    cellZone        all;
    bMin            0.05;
}

Where:

Property Description Required Default value
cellZone Correction cellZone yes
bMin Min b below which no correction no 0.01
Source files

Definition at line 84 of file XiCorrModel.H.

Constructor & Destructor Documentation

◆ XiCorrModel() [1/2]

XiCorrModel ( const fvMesh &  mesh,
const dictionary &  dict
)

Construct from mesh and dictionary.

Definition at line 49 of file XiCorrModel.C.

References dict, and XiCorrModel::readCoeffs().

Here is the call graph for this function:

◆ XiCorrModel() [2/2]

XiCorrModel ( const XiCorrModel &  )
delete

Disallow default bitwise copy construction.

◆ ~XiCorrModel()

~XiCorrModel ( )
virtual

Destructor.

Definition at line 64 of file XiCorrModel.C.

Member Function Documentation

◆ readCoeffs()

bool readCoeffs ( const dictionary &  dict)
protectedvirtual

Update coefficients from given dictionary.

Reimplemented in spherical, and cylindrical.

Definition at line 40 of file XiCorrModel.C.

References dict, and dimensioned< Type >::readIfPresent().

Referenced by cylindrical::readCoeffs(), spherical::readCoeffs(), and XiCorrModel::XiCorrModel().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ TypeName()

TypeName ( "XiCorrModel"  )

Runtime type information.

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable ( autoPtr  ,
XiCorrModel  ,
dictionary  ,
(const fvMesh &mesh, const dictionary &dict)  ,
(mesh, dict)
)

◆ New()

Foam::autoPtr< Foam::XiCorrModel > New ( const fvMesh &  mesh,
const dictionary &  dict
)
static

Return a reference to the selected XiCorrModel model.

Definition at line 30 of file XiCorrModelNew.C.

References dict, Foam::endl(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, Foam::Info, dictionary::lookup(), mesh, Foam::nl, dictionary::optionalSubDict(), and Foam::type().

Here is the call graph for this function:

◆ Ak()

virtual dimensionedScalar Ak ( const dimensionedScalar &  Vk) const
pure virtual

Return the area of the ignition kernel.

calculated from the given kernel volume

Implemented in spherical, planar, and cylindrical.

◆ XiCorr()

void XiCorr ( volScalarField &  Xi,
const volScalarField &  b,
const volScalarField &  mgb
) const
virtual

Definition at line 70 of file XiCorrModel.C.

References b, cells, Foam::dimVolume, Foam::endl(), Foam::gSum(), Foam::Info, Foam::max(), DimensionedField< Type, GeoMesh, PrimitiveField >::mesh(), Foam::min(), Foam::reduce(), and dimensioned< Type >::value().

Here is the call graph for this function:

◆ topoChange()

void topoChange ( const polyTopoChangeMap &  map)
virtual

Update topology using the given map.

Definition at line 115 of file XiCorrModel.C.

◆ mapMesh()

void mapMesh ( const polyMeshMap &  map)
virtual

Update from another mesh using the given map.

Definition at line 124 of file XiCorrModel.C.

◆ distribute()

void distribute ( const polyDistributionMap &  map)
virtual

Redistribute or update using the given distribution map.

Definition at line 130 of file XiCorrModel.C.

◆ movePoints()

bool movePoints ( )
virtual

Update for mesh motion.

Definition at line 139 of file XiCorrModel.C.

◆ read()

bool read ( const dictionary &  XiProperties)

Update properties from the given XiProperties dictionary.

Definition at line 146 of file XiCorrModel.C.

References dict, dictionary::optionalSubDict(), dictionary::subDict(), and Foam::type().

Here is the call graph for this function:

◆ operator=()

void operator= ( const XiCorrModel &  )
delete

Disallow default bitwise assignment.

The documentation for this class was generated from the following files:
