Reynolds-stress turbulence model base class. More...

Inheritance diagram for ReynoldsStress< BasicMomentumTransportModel >:

[legend]

Collaboration diagram for ReynoldsStress< BasicMomentumTransportModel >:

[legend]

Public Types
typedef BasicMomentumTransportModel::alphaField	alphaField

typedef BasicMomentumTransportModel::rhoField	rhoField

Public Member Functions
	ReynoldsStress (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)
	Construct from components. More...

virtual	~ReynoldsStress ()
	Destructor. More...

virtual bool	read ()=0
	Re-read model coefficients if they have changed. More...

virtual tmp< volScalarField >	nut () const
	Return the turbulence viscosity. More...

virtual tmp< scalarField >	nut (const label patchi) const
	Return the turbulence viscosity on patch. More...

virtual tmp< volScalarField >	k () const
	Return the turbulence kinetic energy. More...

virtual tmp< volSymmTensorField >	R () const
	Return the Reynolds stress tensor [m^2/s^2]. More...

virtual tmp< surfaceVectorField >	devTau () const
	Return the effective surface stress. More...

virtual tmp< fvVectorMatrix >	divDevTau (volVectorField &U) const
	Return the source term for the momentum equation. More...

virtual tmp< fvVectorMatrix >	divDevTau (const volScalarField &rho, volVectorField &U) const
	Return the source term for the momentum equation. More...

virtual void	validate ()
	Validate the turbulence fields after construction. More...

virtual void	correct ()=0
	Solve the turbulence equations and correct the turbulence viscosity. More...

template<class RhoFieldType >
Foam::tmp< Foam::fvVectorMatrix >	DivDevTau (const RhoFieldType &rho, volVectorField &U) const

Protected Member Functions
void	boundNormalStress (volSymmTensorField &R) const

void	correctWallShearStress (volSymmTensorField &R) const

virtual void	correctNut ()=0
	Update the eddy-viscosity. More...

virtual tmp< fvSymmTensorMatrix >	RSource () const
	Source term for the R equation. More...

tmp< surfaceVectorField >	Refff (const volVectorField &U) const
	Return the effective Reynolds stress flux. More...

Protected Attributes
dimensionedScalar	couplingFactor_

volSymmTensorField	R_

volScalarField	nut_

Detailed Description

template<class BasicMomentumTransportModel>
class Foam::ReynoldsStress< BasicMomentumTransportModel >

Reynolds-stress turbulence model base class.

Source files

Definition at line 47 of file ReynoldsStress.H.

Member Typedef Documentation

◆ alphaField

typedef BasicMomentumTransportModel::alphaField alphaField

Definition at line 93 of file ReynoldsStress.H.

◆ rhoField

typedef BasicMomentumTransportModel::rhoField rhoField

Definition at line 94 of file ReynoldsStress.H.

Constructor & Destructor Documentation

◆ ReynoldsStress()

ReynoldsStress	(	const word &	modelName,
		const alphaField &	alpha,
		const rhoField &	rho,
		const volVectorField &	U,
		const surfaceScalarField &	alphaRhoPhi,
		const surfaceScalarField &	phi,
		const viscosity &	viscosity
	)

Construct from components.

Definition at line 121 of file ReynoldsStress.C.

◆ ~ReynoldsStress()

virtual ~ReynoldsStress ( )

inlinevirtual

Destructor.

Definition at line 113 of file ReynoldsStress.H.

Member Function Documentation

◆ boundNormalStress()

void boundNormalStress ( volSymmTensorField & R ) const

protected

Definition at line 33 of file ReynoldsStress.C.

References R().

Here is the call graph for this function:

◆ correctWallShearStress()

void correctWallShearStress ( volSymmTensorField & R ) const

protected

Definition at line 58 of file ReynoldsStress.C.

References forAll, patches, patchi, and R().

Here is the call graph for this function:

◆ correctNut()

virtual void correctNut ( )

protectedpure virtual

Update the eddy-viscosity.

Implemented in SSG< BasicMomentumTransportModel >, LRR< BasicMomentumTransportModel >, and DeardorffDiffStress< BasicMomentumTransportModel >.

◆ RSource()

Foam::tmp< Foam::fvSymmTensorMatrix > RSource

protectedvirtual

Source term for the R equation.

Definition at line 105 of file ReynoldsStress.C.

References Foam::dimTime, and Foam::dimVolume.

◆ Refff()

Foam::tmp< Foam::surfaceVectorField > Refff ( const volVectorField & U ) const

protected

Return the effective Reynolds stress flux.

Definition at line 210 of file ReynoldsStress.C.

References Foam::dev2(), Foam::fvc::grad(), Foam::fvc::interpolate(), mesh, nut, Foam::fvc::snGrad(), GeometricField< Type, GeoMesh, PrimitiveField >::T(), and U.

Here is the call graph for this function:

◆ read()

bool read

pure virtual

Re-read model coefficients if they have changed.

Implemented in SSG< BasicMomentumTransportModel >, LRR< BasicMomentumTransportModel >, and DeardorffDiffStress< BasicMomentumTransportModel >.

Definition at line 184 of file ReynoldsStress.C.

References Foam::blockMeshTools::read().

Here is the call graph for this function:

◆ nut() [1/2]

virtual tmp<volScalarField> nut ( ) const

inlinevirtual

Return the turbulence viscosity.

Definition at line 123 of file ReynoldsStress.H.

References ReynoldsStress< BasicMomentumTransportModel >::nut_.

◆ nut() [2/2]

virtual tmp<scalarField> nut ( const label patchi ) const

inlinevirtual

Return the turbulence viscosity on patch.

Definition at line 129 of file ReynoldsStress.H.

References GeometricField< Type, GeoMesh, PrimitiveField >::boundaryField(), ReynoldsStress< BasicMomentumTransportModel >::nut_, and patchi.

Here is the call graph for this function:

◆ k()

Foam::tmp< Foam::volScalarField > k

virtual

Return the turbulence kinetic energy.

Reimplemented in SSG< BasicMomentumTransportModel >, and LRR< BasicMomentumTransportModel >.

Definition at line 200 of file ReynoldsStress.C.

References tmp< T >::ref(), and Foam::tr().

Here is the call graph for this function:

◆ R()

Foam::tmp< Foam::volSymmTensorField > R

virtual

Return the Reynolds stress tensor [m^2/s^2].

Definition at line 192 of file ReynoldsStress.C.

◆ devTau()

Foam::tmp< Foam::surfaceVectorField > devTau

virtual

Return the effective surface stress.

Definition at line 242 of file ReynoldsStress.C.

References Foam::fvc::interpolate(), mesh, and Foam::compressible::New().

Here is the call graph for this function:

◆ divDevTau() [1/2]

Foam::tmp< Foam::fvVectorMatrix > divDevTau ( volVectorField & U ) const

virtual

Return the source term for the momentum equation.

Definition at line 272 of file ReynoldsStress.C.

References U.

◆ divDevTau() [2/2]

Foam::tmp< Foam::fvVectorMatrix > divDevTau	(	const volScalarField &	rho,
		volVectorField &	U
	)		const

virtual

Return the source term for the momentum equation.

Definition at line 283 of file ReynoldsStress.C.

References rho, and U.

◆ validate()

void validate

virtual

Validate the turbulence fields after construction.

Update turbulence viscosity and other derived fields as requires

Definition at line 294 of file ReynoldsStress.C.

◆ correct()

void correct

pure virtual

Solve the turbulence equations and correct the turbulence viscosity.

Implemented in SSG< BasicMomentumTransportModel >, LRR< BasicMomentumTransportModel >, and DeardorffDiffStress< BasicMomentumTransportModel >.

Definition at line 301 of file ReynoldsStress.C.

References Foam::MULES::correct().

Here is the call graph for this function:

◆ DivDevTau()

Foam::tmp<Foam::fvVectorMatrix> DivDevTau	(	const RhoFieldType &	rho,
		volVectorField &	U
	)		const

Definition at line 256 of file ReynoldsStress.C.

References Foam::correction(), Foam::fvc::div(), Foam::fvc::interpolate(), Foam::fvc::laplacian(), nuEff, rho, and U.

Here is the call graph for this function:

Member Data Documentation

◆ couplingFactor_

dimensionedScalar couplingFactor_

protected

Definition at line 68 of file ReynoldsStress.H.

◆ R_

volSymmTensorField R_

protected

Definition at line 72 of file ReynoldsStress.H.

◆ nut_

volScalarField nut_

protected

Definition at line 73 of file ReynoldsStress.H.

Referenced by ReynoldsStress< BasicMomentumTransportModel >::nut().

The documentation for this class was generated from the following files:

src/MomentumTransportModels/momentumTransportModels/ReynoldsStress/ReynoldsStress.H
src/MomentumTransportModels/momentumTransportModels/ReynoldsStress/ReynoldsStress.C
