ReactingPhaseModel< BasePhaseModel > Class Template Reference

Class which represents phases with volumetric reactions. Returns the reaction rate and heat. More...

Inheritance diagram for ReactingPhaseModel< BasePhaseModel >:

Collaboration diagram for ReactingPhaseModel< BasePhaseModel >:

Public Member Functions
	ReactingPhaseModel (const phaseSystem &fluid, const word &phaseName, const bool referencePhase, const label index)
virtual	~ReactingPhaseModel ()
	Destructor. More...
virtual void	correctReactions ()
	Correct the reaction rates. More...
virtual tmp< volScalarField::Internal >	R (const label speciei) const
	Return the consumption rate for a specie. More...
virtual tmp< fvScalarMatrix >	R (volScalarField &Yi) const
	Return consumption rate matrix for a specie. More...
virtual tmp< volScalarField >	Qdot () const
	Return heat release rate. More...

Protected Attributes
autoPtr< combustionModel >	reaction_
	Reaction model. More...

Detailed Description

template<class BasePhaseModel>
class Foam::ReactingPhaseModel< BasePhaseModel >

Class which represents phases with volumetric reactions. Returns the reaction rate and heat.

Source files

• ReactingPhaseModel.H
• ReactingPhaseModel.C

Definition at line 52 of file ReactingPhaseModel.H.

Constructor & Destructor Documentation

ReactingPhaseModel()

ReactingPhaseModel	(	const phaseSystem &	fluid,
		const word &	phaseName,
		const bool	referencePhase,
		const label	index
	)

Definition at line 35 of file ReactingPhaseModel.C.

~ReactingPhaseModel()

~ReactingPhaseModel

virtual

Destructor.

Definition at line 51 of file ReactingPhaseModel.C.

Member Function Documentation

correctReactions()

void correctReactions

virtual

Correct the reaction rates.

Definition at line 58 of file ReactingPhaseModel.C.

R() [1/2]

Foam::tmp< Foam::volScalarField::Internal > R ( const label  speciei ) const

virtual

Return the consumption rate for a specie.

Definition at line 68 of file ReactingPhaseModel.C.

R() [2/2]

Foam::tmp< Foam::fvScalarMatrix > R ( volScalarField &  Yi ) const

virtual

Return consumption rate matrix for a specie.

Definition at line 76 of file ReactingPhaseModel.C.

Qdot()

Foam::tmp< Foam::volScalarField > Qdot

virtual

Return heat release rate.

Definition at line 84 of file ReactingPhaseModel.C.

Member Data Documentation

reaction_

autoPtr<combustionModel> reaction_

protected

Reaction model.

Definition at line 61 of file ReactingPhaseModel.H.

---

The documentation for this class was generated from the following files:

• applications/modules/multiphaseEuler/phaseSystem/phaseModels/ReactingPhaseModel/ReactingPhaseModel.H
• applications/modules/multiphaseEuler/phaseSystem/phaseModels/ReactingPhaseModel/ReactingPhaseModel.C
