Time-dependent external force restraint using Function1. More...

Inheritance diagram for externalForce:

Collaboration diagram for externalForce:

Public Member Functions
	TypeName ("externalForce")
	Runtime type information. More...

	externalForce (const word &name, const dictionary &dict, const rigidBodyModel &model)
	Construct from components. More...

virtual autoPtr< restraint >	clone () const
	Construct and return a clone. More...

virtual	~externalForce ()
	Destructor. More...

virtual void	restrain (scalarField &tau, Field< spatialVector > &fx, const rigidBodyModelState &state) const
	Accumulate the retraint internal joint forces into the tau field and. More...

virtual bool	read (const dictionary &dict)
	Update properties from given dictionary. More...

virtual void	write (Ostream &) const
	Write. More...

Public Member Functions inherited from restraint
	TypeName ("restraint")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, restraint, dictionary,(const word &name, const dictionary &dict, const rigidBodyModel &model),(name, dict, model))

	restraint (const word &name, const dictionary &dict, const rigidBodyModel &model)
	Construct from the dict dictionary and Time. More...

virtual	~restraint ()
	Destructor. More...

const word &	name () const
	Return the name. More...

label	bodyIndex () const

const dictionary &	coeffDict () const
	Return access to coeffs. More...

Additional Inherited Members
Static Public Member Functions inherited from restraint
static autoPtr< restraint >	New (const word &name, const dictionary &dict, const rigidBodyModel &model)
	Select constructed from the dict dictionary and Time. More...

Protected Member Functions inherited from restraint
point	bodyPoint (const point &p) const
	Transform the given point on the restrained body to the global frame. More...

spatialVector	bodyPointVelocity (const point &p) const
	Transform the velocity of the given point on the restrained body. More...

Protected Attributes inherited from restraint
word	name_
	Name of the restraint. More...

label	bodyIndex_
	Index of the body the restraint is applied to. More...

label	masterBodyIndex_
	Index of the master body the restraint is applied to. More...

dictionary	coeffs_
	Restraint model specific coefficient dictionary. More...

const rigidBodyModel &	model_
	Reference to the model. More...

Detailed Description

Time-dependent external force restraint using Function1.

Usage

Example applying a constant force to the floatingObject:

restraints
{
    force
    {
        type        externalForce;
        body        floatingObject;
        location    (0 0 0);
        force       (100 0 0);
    }
}

Source files

Definition at line 68 of file externalForce.H.
