Function object to collect the parcel mass- and mass flow rate over a set of polygons. The polygons can either be specified by sets of user- supplied points, or in a concentric circles arrangement. If a parcel is 'collected', it can be flagged to be removed from the domain using the removeCollected entry. More...

Inheritance diagram for ParticleCollector< CloudType >:

[legend]

Collaboration diagram for ParticleCollector< CloudType >:

[legend]

Public Types
enum	modeType { mtPolygon , mtConcentricCircle , mtUnknown }

Public Types inherited from CloudSubModelBase< CloudType >
typedef CloudType	cloudType
	Type of cloud this model was instantiated for. More...

Public Member Functions
	TypeName ("particleCollector")
	Runtime type information. More...

	ParticleCollector (const dictionary &dict, CloudType &owner, const word &modelName)
	Construct from dictionary. More...

	ParticleCollector (const ParticleCollector< CloudType > &pc)
	Construct copy. More...

virtual autoPtr< CloudFunctionObject< CloudType > >	clone () const
	Construct and return a clone. More...

virtual	~ParticleCollector ()
	Destructor. More...

const Switch &	resetOnWrite () const
	Return const access to the reset on write flag. More...

virtual void	postMove (parcelType &p, const scalar dt, const point &position0, bool &keepParticle)
	Post-move hook. More...

Public Member Functions inherited from CloudFunctionObject< CloudType >
	TypeName ("cloudFunctionObject")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, CloudFunctionObject, dictionary,(const dictionary &dict, CloudType &owner, const word &modelName),(dict, owner, modelName))
	Declare runtime constructor selection table. More...

	CloudFunctionObject (CloudType &owner)
	Construct null from owner. More...

	CloudFunctionObject (const dictionary &dict, CloudType &owner, const word &objectType, const word &modelName)
	Construct from dictionary. More...

	CloudFunctionObject (const CloudFunctionObject< CloudType > &ppm)
	Construct copy. More...

virtual	~CloudFunctionObject ()
	Destructor. More...

virtual void	preEvolve ()
	Pre-evolve hook. More...

virtual void	postEvolve ()
	Post-evolve hook. More...

virtual void	postPatch (const typename CloudType::parcelType &p, const polyPatch &pp)
	Post-patch hook. More...

virtual void	preFace (const typename CloudType::parcelType &p)
	Pre-face hook. More...

virtual void	postFace (const typename CloudType::parcelType &p)
	Post-face hook. More...

const fileName &	outputDir () const
	Return the output path. More...

fileName	writeTimeDir () const
	Return the output time path. More...

Public Member Functions inherited from CloudSubModelBase< CloudType >
	CloudSubModelBase (CloudType &owner)
	Construct null from owner cloud. More...

	CloudSubModelBase (CloudType &owner, const dictionary &dict, const word &baseName, const word &modelType, const word &dictExt="Coeffs")
	Construct from owner cloud without name. More...

	CloudSubModelBase (const word &modelName, CloudType &owner, const dictionary &dict, const word &baseName, const word &modelType)
	Construct from owner cloud with name. More...

	CloudSubModelBase (const CloudSubModelBase< CloudType > &smb)
	Copy constructor. More...

virtual	~CloudSubModelBase ()
	Destructor. More...

const CloudType &	owner () const
	Return const access to the owner cloud. More...

virtual bool	writeTime () const
	Flag to indicate when to write a property. More...

CloudType &	owner ()
	Return non-const access to the owner cloud for manipulation. More...

virtual void	write (Ostream &os) const
	Write. More...

Public Member Functions inherited from subModelBase
	subModelBase (dictionary &properties)
	Construct null. More...

	subModelBase (dictionary &properties, const dictionary &dict, const word &baseName, const word &modelType, const word &dictExt="Coeffs")
	Construct from components without name. More...

	subModelBase (const word &modelName, dictionary &properties, const dictionary &dict, const word &baseName, const word &modelType)
	Construct from components with name. More...

	subModelBase (const subModelBase &smb)
	Copy constructor. More...

virtual	~subModelBase ()
	Destructor. More...

const word &	modelName () const
	Return const access to the name of the sub-model. More...

const dictionary &	dict () const
	Return const access to the cloud dictionary. More...

const word &	baseName () const
	Return const access to the base name of the sub-model. More...

const word &	modelType () const
	Return const access to the sub-model type. More...

const dictionary &	coeffDict () const
	Return const access to the coefficients dictionary. More...

const dictionary &	properties () const
	Return const access to the properties dictionary. More...

virtual bool	defaultCoeffs (const bool printMsg) const
	Returns true if defaultCoeffs is true and outputs on printMsg. More...

virtual void	cacheFields (const bool store)
	Cache dependent sub-model fields. More...

template<class Type >
Type	getBaseProperty (const word &entryName, const Type &defaultValue=pTraits< Type >::zero) const
	Retrieve generic property from the base model. More...

template<class Type >
void	getBaseProperty (const word &entryName, Type &value) const
	Retrieve generic property from the base model. More...

template<class Type >
void	setBaseProperty (const word &entryName, const Type &value)
	Add generic property to the base model. More...

template<class Type >
void	getModelProperty (const word &entryName, Type &value) const
	Retrieve generic property from the sub-model. More...

template<class Type >
Type	getModelProperty (const word &entryName, const Type &defaultValue=pTraits< Type >::zero) const
	Retrieve generic property from the sub-model. More...

template<class Type >
void	setModelProperty (const word &entryName, const Type &value)
	Add generic property to the sub-model. More...

void	operator= (const subModelBase &)=delete
	Disallow default bitwise assignment. More...

Protected Member Functions
void	write ()
	Write post-processing info. More...

Protected Member Functions inherited from subModelBase
bool	inLine () const
	Flag to indicate whether data is/was read in-line. More...

Additional Inherited Members
Static Public Member Functions inherited from CloudFunctionObject< CloudType >
static autoPtr< CloudFunctionObject< CloudType > >	New (const dictionary &dict, CloudType &owner, const word &objectType, const word &modelName)
	Selector. More...

Protected Attributes inherited from CloudSubModelBase< CloudType >
CloudType &	owner_
	Reference to the cloud. More...

Protected Attributes inherited from subModelBase
const word	modelName_
	Name of the sub-model. More...

dictionary &	properties_
	Reference to properties dictionary e.g. for restart. More...

const dictionary	dict_
	Copy of dictionary used during construction. More...

const word	baseName_
	Name of the sub-model base class. More...

const word	modelType_
	Type of the sub-model. More...

const dictionary	coeffDict_
	Coefficients dictionary. More...

Detailed Description

template<class CloudType>
class Foam::ParticleCollector< CloudType >

Function object to collect the parcel mass- and mass flow rate over a set of polygons. The polygons can either be specified by sets of user- supplied points, or in a concentric circles arrangement. If a parcel is 'collected', it can be flagged to be removed from the domain using the removeCollected entry.

Example usage:

particleCollector1
{
    type            particleCollector;

    mode            concentricCircle;
    origin          (0.05 0.025 0.005);
    radius          (0.01 0.025 0.05);
    nSector         10;
    refDir          (1 0 0);
    normal          (0 0 1);

    negateParcelsOppositeNormal no;
    removeCollected no;
    surfaceFormat   vtk;
    resetOnWrite    no;
    log             yes;
}

particleCollector2
{
    type            particleCollector;

    mode            polygon;
    polygons
    (
        (
            (0 0 0)
            (1 0 0)
            (1 1 0)
            (0 1 0)
        )
        (
            (0 0 1)
            (1 0 1)
            (1 1 1)
            (0 1 1)
        )
    );
    normal          (0 0 1);

    negateParcelsOppositeNormal no;
    removeCollected no;
    surfaceFormat   vtk;
    resetOnWrite    no;
    log             yes;
}

Source files

Definition at line 107 of file ParticleCollector.H.

Member Enumeration Documentation

◆ modeType

enum modeType

Enumerator
mtPolygon
mtConcentricCircle
mtUnknown

Definition at line 113 of file ParticleCollector.H.

Constructor & Destructor Documentation

◆ ParticleCollector() [1/2]

ParticleCollector	(	const dictionary &	dict,
		CloudType &	owner,
		const word &	modelName
	)

Construct from dictionary.

Definition at line 495 of file ParticleCollector.C.

References subModelBase::coeffDict(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, UList< T >::first(), forAll, Foam::mag(), Foam::mode(), List< T >::setSize(), and List< T >::size().

Here is the call graph for this function:

◆ ParticleCollector() [2/2]

ParticleCollector ( const ParticleCollector< CloudType > & pc )

Construct copy.

Definition at line 582 of file ParticleCollector.C.

◆ ~ParticleCollector()

~ParticleCollector

virtual

Destructor.

Definition at line 614 of file ParticleCollector.C.

Member Function Documentation

◆ write()

void write

protectedvirtual

Write post-processing info.

Reimplemented from CloudFunctionObject< CloudType >.

Definition at line 380 of file ParticleCollector.C.

References alpha(), Foam::endl(), forAll, Foam::Info, fvMesh::mesh(), mesh, dimensioned< Type >::name(), Foam::compressible::New(), Foam::nl, List< T >::size(), Foam::sum(), Foam::tab, fvMesh::time(), Foam::type(), and dimensioned< Type >::value().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "particleCollector" )

Runtime type information.

◆ clone()

virtual autoPtr<CloudFunctionObject<CloudType> > clone ( ) const

inlinevirtual

Construct and return a clone.

Reimplemented from CloudFunctionObject< CloudType >.

Definition at line 257 of file ParticleCollector.H.

◆ resetOnWrite()

const Foam::Switch & resetOnWrite

inline

Return const access to the reset on write flag.

Definition at line 28 of file ParticleCollectorI.H.

◆ postMove()

void postMove	(	parcelType &	p,
		const scalar	dt,
		const point &	position0,
		bool &	keepParticle
	)

virtual

Post-move hook.

Reimplemented from CloudFunctionObject< CloudType >.

Definition at line 621 of file ParticleCollector.C.

References forAll, Foam::mag(), and p.

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/lagrangian/parcel/submodels/CloudFunctionObjects/ParticleCollector/ParticleCollector.H
src/lagrangian/parcel/submodels/CloudFunctionObjects/ParticleCollector/ParticleCollector.C
src/lagrangian/parcel/submodels/CloudFunctionObjects/ParticleCollector/ParticleCollectorI.H
