Public Member Functions | List of all members
PairSpringSliderDashpot< CloudType > Class Template Reference

Pair forces between particles colliding with a spring, slider, damper model. More...

Inheritance diagram for PairSpringSliderDashpot< CloudType >:
Inheritance graph
[legend]
Collaboration diagram for PairSpringSliderDashpot< CloudType >:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("pairSpringSliderDashpot")
 Runtime type information. More...

 PairSpringSliderDashpot (const dictionary &dict, CloudType &cloud)
 Construct from dictionary. More...

virtual ~PairSpringSliderDashpot ()
 Destructor. More...

scalar volumeFactor () const
 Return the volumeFactor. More...

scalar overlapArea (scalar rA, scalar rB, scalar rAB) const

virtual bool controlsTimestep () const
 Whether the PairModel has a timestep limit that will. More...

virtual label nSubCycles () const
 For PairModels that control the timestep, calculate the. More...

virtual void evaluatePair (typename CloudType::parcelType &pA, typename CloudType::parcelType &pB) const
 Calculate the pair interaction between parcels. More...

- Public Member Functions inherited from PairModel< CloudType >
 TypeName ("pairModel")
 Runtime type information. More...

 declareRunTimeSelectionTable (autoPtr, PairModel, dictionary,(const dictionary &dict, CloudType &owner),(dict, owner))
 Declare runtime constructor selection table. More...

 PairModel (const dictionary &dict, CloudType &owner, const word &type)
 Construct from components. More...

virtual ~PairModel ()
 Destructor. More...

const CloudType & owner () const
 Return the owner cloud object. More...

const dictionary & dict () const
 Return the dictionary. More...

const dictionary & coeffDict () const
 Return the coefficients dictionary. More...


Additional Inherited Members

- Static Public Member Functions inherited from PairModel< CloudType >
static autoPtr< PairModel< CloudType > > New (const dictionary &dict, CloudType &owner)
 Selector. More...


Detailed Description

template<class CloudType>
class Foam::PairSpringSliderDashpot< CloudType >

Pair forces between particles colliding with a spring, slider, damper model.

Definition at line 47 of file PairSpringSliderDashpot.H.

Constructor & Destructor Documentation

◆ PairSpringSliderDashpot()

PairSpringSliderDashpot ( const dictionary &  dict,
CloudType &  cloud
)

Construct from dictionary.

Definition at line 84 of file PairSpringSliderDashpot.C.

References PairModel< CloudType >::coeffDict(), DSMCCloud< ParcelType >::constProps(), Foam::constant::universal::G, Foam::mag(), PairModel< CloudType >::owner(), and Foam::sqr().

Here is the call graph for this function:

◆ ~PairSpringSliderDashpot()

~PairSpringSliderDashpot
virtual

Destructor.

Definition at line 131 of file PairSpringSliderDashpot.C.

Member Function Documentation

◆ TypeName()

TypeName ( "pairSpringSliderDashpot"  )

Runtime type information.

◆ volumeFactor()

scalar volumeFactor ( ) const
inline

Return the volumeFactor.

Definition at line 133 of file PairSpringSliderDashpot.H.

◆ overlapArea()

scalar overlapArea ( scalar  rA,
scalar  rB,
scalar  rAB
) const
inline

Definition at line 140 of file PairSpringSliderDashpot.H.

References Foam::constant::mathematical::pi(), and Foam::sqr().

Here is the call graph for this function:

◆ controlsTimestep()

bool controlsTimestep
virtual

Whether the PairModel has a timestep limit that will.

require subCycling

Implements PairModel< CloudType >.

Definition at line 138 of file PairSpringSliderDashpot.C.

◆ nSubCycles()

Foam::label nSubCycles
virtual

For PairModels that control the timestep, calculate the.

number of subCycles needed to satisfy the minimum allowable timestep

Implements PairModel< CloudType >.

Definition at line 145 of file PairSpringSliderDashpot.C.

References Foam::pow(), and Foam::sqrt().

Here is the call graph for this function:

◆ evaluatePair()

void evaluatePair ( typename CloudType::parcelType &  pA,
typename CloudType::parcelType &  pB
) const
virtual

Calculate the pair interaction between parcels.

Implements PairModel< CloudType >.

Definition at line 167 of file PairSpringSliderDashpot.C.

References Foam::cbrt(), TimeState::deltaTValue(), M, Foam::mag(), fvMesh::mesh(), mesh, Foam::pow(), Foam::pow025(), Foam::R(), Foam::sqrt(), fvMesh::time(), and Foam::Zero.

Here is the call graph for this function:
The documentation for this class was generated from the following files:
