Preconditioned conjugate gradient solver for symmetric lduMatrices using a run-time selectable preconditioner. More...

Inheritance diagram for PCG:

Collaboration diagram for PCG:

Public Member Functions
	TypeName ("PCG")
	Runtime type information. More...

	PCG (const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces, const dictionary &solverControls)
	Construct from matrix components and solver controls. More...

	PCG (const PCG &)=delete
	Disallow default bitwise copy construction. More...

virtual	~PCG ()
	Destructor. More...

virtual solverPerformance	solve (scalarField &psi, const scalarField &source, const direction cmpt=0) const
	Solve the matrix with this solver. More...

void	operator= (const PCG &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from lduMatrix::solver
virtual const word &	type () const =0
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, solver, symMatrix,(const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces, const dictionary &solverControls),(fieldName, matrix, interfaceBouCoeffs, interfaceIntCoeffs, interfaces, solverControls))

	declareRunTimeSelectionTable (autoPtr, solver, asymMatrix,(const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces, const dictionary &solverControls),(fieldName, matrix, interfaceBouCoeffs, interfaceIntCoeffs, interfaces, solverControls))

	solver (const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces, const dictionary &solverControls)

virtual	~solver ()
	Destructor. More...

const word &	fieldName () const

const lduMatrix &	matrix () const

const FieldField< Field, scalar > &	interfaceBouCoeffs () const

const FieldField< Field, scalar > &	interfaceIntCoeffs () const

const lduInterfaceFieldPtrsList &	interfaces () const

virtual void	read (const dictionary &)
	Read and reset the solver parameters from the given stream. More...

scalar	normFactor (const scalarField &psi, const scalarField &source, const scalarField &Apsi, scalarField &tmpField) const
	Return the matrix norm used to normalise the residual for the. More...

Additional Inherited Members
Static Public Member Functions inherited from lduMatrix::solver
static autoPtr< solver >	New (const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces, const dictionary &solverControls)
	Return a new solver. More...

Protected Member Functions inherited from lduMatrix::solver
virtual void	readControls ()
	Read the control parameters from the controlDict_. More...

Protected Attributes inherited from lduMatrix::solver
word	fieldName_

const lduMatrix &	matrix_

const FieldField< Field, scalar > &	interfaceBouCoeffs_

const FieldField< Field, scalar > &	interfaceIntCoeffs_

lduInterfaceFieldPtrsList	interfaces_

dictionary	controlDict_
	Dictionary of controls. More...

label	maxIter_
	Maximum number of iterations in the solver. More...

label	minIter_
	Minimum number of iterations in the solver. More...

scalar	tolerance_
	Final convergence tolerance. More...

scalar	relTol_
	Convergence tolerance relative to the initial. More...

Static Protected Attributes inherited from lduMatrix::solver
static const label	defaultMaxIter_ = 1000
	Default maximum number of iterations in the solver. More...

Detailed Description

Preconditioned conjugate gradient solver for symmetric lduMatrices using a run-time selectable preconditioner.

Source files

PCG.H
PCG.C

Definition at line 49 of file PCG.H.

Constructor & Destructor Documentation

◆ PCG() [1/2]

PCG	(	const word &	fieldName,
		const lduMatrix &	matrix,
		const FieldField< Field, scalar > &	interfaceBouCoeffs,
		const FieldField< Field, scalar > &	interfaceIntCoeffs,
		const lduInterfaceFieldPtrsList &	interfaces,
		const dictionary &	solverControls
	)

Construct from matrix components and solver controls.

Definition at line 41 of file PCG.C.

◆ PCG() [2/2]

PCG ( const PCG & )

delete

Disallow default bitwise copy construction.

◆ ~PCG()

virtual ~PCG ( )

inlinevirtual

Destructor.

Definition at line 78 of file PCG.H.

Member Function Documentation

◆ TypeName()

TypeName ( "PCG" )

Runtime type information.

◆ solve()

Foam::solverPerformance solve	(	scalarField &	psi,
		const scalarField &	source,
		const direction	cmpt = `0`
	)		const

virtual

Solve the matrix with this solver.

Implements lduMatrix::solver.

Definition at line 65 of file PCG.C.

References alpha(), UList< T >::begin(), SolverPerformance< Type >::checkConvergence(), SolverPerformance< Type >::checkSingularity(), Foam::endl(), SolverPerformance< Type >::finalResidual(), lduMatrix::preconditioner::getName(), SolverPerformance< Type >::great_, Foam::gSumMag(), Foam::gSumProd(), Foam::Info, SolverPerformance< Type >::initialResidual(), Foam::mag(), mesh, lduMatrix::preconditioner::New(), SolverPerformance< Type >::nIterations(), and psi.

Here is the call graph for this function:

◆ operator=()

void operator= ( const PCG & )
