Multi-component thermo implementation. More...

Inheritance diagram for MulticomponentThermo< BaseThermo >:

Collaboration diagram for MulticomponentThermo< BaseThermo >:

Public Member Functions
	MulticomponentThermo (const fvMesh &, const word &phaseName)
	Construct from mesh and phase name. More...

	MulticomponentThermo (const MulticomponentThermo< BaseThermo > &)=delete
	Disallow default bitwise copy construction. More...

virtual	~MulticomponentThermo ()
	Destructor. More...

virtual scalar	WiValue (const label speciei) const
	Molecular weight [kg/kmol]. More...

virtual dimensionedScalar	Wi (const label speciei) const
	Molecular weight [kg/kmol]. More...

virtual scalar	rhoi (const label speciei, const scalar p, const scalar T) const
	Density [kg/m^3]. More...

virtual tmp< volScalarField >	rhoi (const label speciei, const volScalarField &p, const volScalarField &T) const
	Density [kg/m^3]. More...

virtual scalar	Cpi (const label speciei, const scalar p, const scalar T) const
	Heat capacity at constant pressure [J/kg/K]. More...

virtual tmp< volScalarField >	Cpi (const label speciei, const volScalarField &p, const volScalarField &T) const
	Heat capacity at constant pressure [J/kg/K]. More...

virtual scalar	hei (const label speciei, const scalar p, const scalar T) const
	Enthalpy/Internal energy [J/kg]. More...

virtual tmp< scalarField >	hei (const label speciei, const scalarField &p, const scalarField &T) const
	Enthalpy/Internal energy [J/kg]. More...

virtual tmp< volScalarField::Internal >	hei (const label speciei, const volScalarField::Internal &p, const volScalarField::Internal &T) const
	Enthalpy/Internal energy [J/kg]. More...

virtual tmp< volScalarField >	hei (const label speciei, const volScalarField &p, const volScalarField &T) const
	Enthalpy/Internal energy [J/kg]. More...

virtual scalar	hsi (const label speciei, const scalar p, const scalar T) const
	Sensible enthalpy [J/kg]. More...

virtual tmp< scalarField >	hsi (const label speciei, const scalarField &p, const scalarField &T) const
	Sensible enthalpy [J/kg]. More...

virtual tmp< volScalarField::Internal >	hsi (const label speciei, const volScalarField::Internal &p, const volScalarField::Internal &T) const
	Sensible enthalpy [J/kg]. More...

virtual tmp< volScalarField >	hsi (const label speciei, const volScalarField &p, const volScalarField &T) const
	Sensible enthalpy [J/kg]. More...

virtual scalar	hai (const label speciei, const scalar p, const scalar T) const
	Absolute enthalpy [J/kg]. More...

virtual tmp< scalarField >	hai (const label speciei, const scalarField &p, const scalarField &T) const
	Absolute enthalpy [J/kg]. More...

virtual tmp< volScalarField::Internal >	hai (const label speciei, const volScalarField::Internal &p, const volScalarField::Internal &T) const
	Absolute enthalpy [J/kg]. More...

virtual tmp< volScalarField >	hai (const label speciei, const volScalarField &p, const volScalarField &T) const
	Absolute enthalpy [J/kg]. More...

virtual scalar	hfiValue (const label speciei) const
	Enthalpy of formation [J/kg]. More...

virtual dimensionedScalar	hfi (const label speciei) const
	Enthalpy of formation [J/kg]. More...

virtual scalar	kappai (const label speciei, const scalar p, const scalar T) const
	Thermal conductivity [W/m/K]. More...

virtual tmp< volScalarField >	kappai (const label speciei, const volScalarField &p, const volScalarField &T) const
	Thermal conductivity [W/m/K]. More...

template<class Method , class ... Args>
Foam::tmp< Foam::volScalarField >	volScalarFieldPropertyi (const word &psiName, const dimensionSet &psiDim, Method psiMethod, const label speciei, const Args &... args) const

template<class Method , class ... Args>
Foam::tmp< Foam::volScalarField::Internal >	volInternalScalarFieldPropertyi (const word &psiName, const dimensionSet &psiDim, Method psiMethod, const label speciei, const Args &... args) const

template<class Method , class Arg , class ... Args>
Foam::tmp< Foam::scalarField >	scalarFieldPropertyi (Method psiMethod, const label speciei, const Arg &arg, const Args &... args) const

Protected Member Functions
template<class Method , class ... Args>
tmp< volScalarField >	volScalarFieldPropertyi (const word &psiName, const dimensionSet &psiDim, Method psiMethod, const label speciei, const Args &... args) const
	Return a volScalarField of the given property. More...

template<class Method , class ... Args>
tmp< volScalarField::Internal >	volInternalScalarFieldPropertyi (const word &psiName, const dimensionSet &psiDim, Method psiMethod, const label speciei, const Args &... args) const
	Return a volScalarField::Internal of the given property. More...

template<class Method , class Arg , class ... Args>
tmp< scalarField >	scalarFieldPropertyi (Method psiMethod, const label speciei, const Arg &arg, const Args &... args) const
	Return a scalarField of the given property. More...

Detailed Description

template<class BaseThermo>
class Foam::MulticomponentThermo< BaseThermo >

Multi-component thermo implementation.

Source files

Definition at line 49 of file MulticomponentThermo.H.

Constructor & Destructor Documentation

◆ MulticomponentThermo() [1/2]

MulticomponentThermo	(	const fvMesh &	mesh,
		const word &	phaseName
	)

Construct from mesh and phase name.

Definition at line 147 of file MulticomponentThermo.C.

◆ MulticomponentThermo() [2/2]

MulticomponentThermo ( const MulticomponentThermo< BaseThermo > & )

delete

Disallow default bitwise copy construction.

◆ ~MulticomponentThermo()

~MulticomponentThermo

virtual

Destructor.

Definition at line 160 of file MulticomponentThermo.C.

Member Function Documentation

◆ volScalarFieldPropertyi() [1/2]

tmp<volScalarField> volScalarFieldPropertyi	(	const word &	psiName,
		const dimensionSet &	psiDim,
		Method	psiMethod,
		const label	speciei,
		const Args &...	args
	)		const

protected

Return a volScalarField of the given property.

◆ volInternalScalarFieldPropertyi() [1/2]

tmp<volScalarField::Internal> volInternalScalarFieldPropertyi	(	const word &	psiName,
		const dimensionSet &	psiDim,
		Method	psiMethod,
		const label	speciei,
		const Args &...	args
	)		const

protected

Return a volScalarField::Internal of the given property.

◆ scalarFieldPropertyi() [1/2]

tmp<scalarField> scalarFieldPropertyi	(	Method	psiMethod,
		const label	speciei,
		const Arg &	arg,
		const Args &...	args
	)		const

protected

Return a scalarField of the given property.

◆ WiValue()

Foam::scalar WiValue ( const label speciei ) const

virtual

Molecular weight [kg/kmol].

Definition at line 167 of file MulticomponentThermo.C.

◆ Wi()

Foam::dimensionedScalar Wi ( const label speciei ) const

virtual

Molecular weight [kg/kmol].

Definition at line 177 of file MulticomponentThermo.C.

References Foam::dimMass, Foam::dimMoles, and Foam::W().

Here is the call graph for this function:

◆ rhoi() [1/2]

Foam::scalar rhoi	(	const label	speciei,
		const scalar	p,
		const scalar	T
	)		const

virtual

Density [kg/m^3].

Definition at line 193 of file MulticomponentThermo.C.

References p, and Foam::T().

Here is the call graph for this function:

◆ rhoi() [2/2]

Foam::tmp< Foam::volScalarField > rhoi	(	const label	speciei,
		const volScalarField &	p,
		const volScalarField &	T
	)		const

virtual

Density [kg/m^3].

Definition at line 206 of file MulticomponentThermo.C.

References Foam::dimDensity, p, rho, and Foam::T().

Here is the call graph for this function:

◆ Cpi() [1/2]

Foam::scalar Cpi	(	const label	speciei,
		const scalar	p,
		const scalar	T
	)		const

virtual

Heat capacity at constant pressure [J/kg/K].

Definition at line 226 of file MulticomponentThermo.C.

References p, and Foam::T().

Here is the call graph for this function:

◆ Cpi() [2/2]

Foam::tmp< Foam::volScalarField > Cpi	(	const label	speciei,
		const volScalarField &	p,
		const volScalarField &	T
	)		const

virtual

Heat capacity at constant pressure [J/kg/K].

Definition at line 239 of file MulticomponentThermo.C.

References Cp(), Foam::dimEnergy, Foam::dimMass, Foam::dimTemperature, p, and Foam::T().

Here is the call graph for this function:

◆ hei() [1/4]

Foam::scalar hei	(	const label	speciei,
		const scalar	p,
		const scalar	T
	)		const

virtual

Enthalpy/Internal energy [J/kg].

Definition at line 259 of file MulticomponentThermo.C.

References p, and Foam::T().

Here is the call graph for this function:

◆ hei() [2/4]

Foam::tmp< Foam::scalarField > hei	(	const label	speciei,
		const scalarField &	p,
		const scalarField &	T
	)		const

virtual

Enthalpy/Internal energy [J/kg].

Definition at line 271 of file MulticomponentThermo.C.

References he(), p, and Foam::T().

Here is the call graph for this function:

◆ hei() [3/4]

Foam::tmp< Foam::volScalarField::Internal > hei	(	const label	speciei,
		const volScalarField::Internal &	p,
		const volScalarField::Internal &	T
	)		const

virtual

Enthalpy/Internal energy [J/kg].

Definition at line 290 of file MulticomponentThermo.C.

References Foam::dimEnergy, Foam::dimMass, he(), p, and Foam::T().

Here is the call graph for this function:

◆ hei() [4/4]

Foam::tmp< Foam::volScalarField > hei	(	const label	speciei,
		const volScalarField &	p,
		const volScalarField &	T
	)		const

virtual

Enthalpy/Internal energy [J/kg].

Definition at line 311 of file MulticomponentThermo.C.

References Foam::dimEnergy, Foam::dimMass, he(), p, and Foam::T().

Here is the call graph for this function:

◆ hsi() [1/4]

Foam::scalar hsi	(	const label	speciei,
		const scalar	p,
		const scalar	T
	)		const

virtual

Sensible enthalpy [J/kg].

Definition at line 331 of file MulticomponentThermo.C.

References p, and Foam::T().

Here is the call graph for this function:

◆ hsi() [2/4]

Foam::tmp< Foam::scalarField > hsi	(	const label	speciei,
		const scalarField &	p,
		const scalarField &	T
	)		const

virtual

Sensible enthalpy [J/kg].

Definition at line 343 of file MulticomponentThermo.C.

References hs(), p, and Foam::T().

Here is the call graph for this function:

◆ hsi() [3/4]

Foam::tmp< Foam::volScalarField::Internal > hsi	(	const label	speciei,
		const volScalarField::Internal &	p,
		const volScalarField::Internal &	T
	)		const

virtual

Sensible enthalpy [J/kg].

Definition at line 362 of file MulticomponentThermo.C.

References Foam::dimEnergy, Foam::dimMass, hs(), p, and Foam::T().

Here is the call graph for this function:

◆ hsi() [4/4]

Foam::tmp< Foam::volScalarField > hsi	(	const label	speciei,
		const volScalarField &	p,
		const volScalarField &	T
	)		const

virtual

Sensible enthalpy [J/kg].

Definition at line 383 of file MulticomponentThermo.C.

References Foam::dimEnergy, Foam::dimMass, hs(), p, and Foam::T().

Here is the call graph for this function:

◆ hai() [1/4]

Foam::scalar hai	(	const label	speciei,
		const scalar	p,
		const scalar	T
	)		const

virtual

Absolute enthalpy [J/kg].

Definition at line 403 of file MulticomponentThermo.C.

References p, and Foam::T().

Here is the call graph for this function:

◆ hai() [2/4]

Foam::tmp< Foam::scalarField > hai	(	const label	speciei,
		const scalarField &	p,
		const scalarField &	T
	)		const

virtual

Absolute enthalpy [J/kg].

Definition at line 415 of file MulticomponentThermo.C.

References ha(), p, and Foam::T().

Here is the call graph for this function:

◆ hai() [3/4]

Foam::tmp< Foam::volScalarField::Internal > hai	(	const label	speciei,
		const volScalarField::Internal &	p,
		const volScalarField::Internal &	T
	)		const

virtual

Absolute enthalpy [J/kg].

Definition at line 434 of file MulticomponentThermo.C.

References Foam::dimEnergy, Foam::dimMass, ha(), p, and Foam::T().

Here is the call graph for this function:

◆ hai() [4/4]

Foam::tmp< Foam::volScalarField > hai	(	const label	speciei,
		const volScalarField &	p,
		const volScalarField &	T
	)		const

virtual

Absolute enthalpy [J/kg].

Definition at line 455 of file MulticomponentThermo.C.

References Foam::dimEnergy, Foam::dimMass, ha(), p, and Foam::T().

Here is the call graph for this function:

◆ hfiValue()

Foam::scalar hfiValue ( const label speciei ) const

virtual

Enthalpy of formation [J/kg].

Definition at line 491 of file MulticomponentThermo.C.

◆ hfi()

Foam::dimensionedScalar hfi ( const label speciei ) const

virtual

Enthalpy of formation [J/kg].

Definition at line 475 of file MulticomponentThermo.C.

References Foam::dimEnergy, and Foam::dimMass.

◆ kappai() [1/2]

Foam::scalar kappai	(	const label	speciei,
		const scalar	p,
		const scalar	T
	)		const

virtual

Thermal conductivity [W/m/K].

Definition at line 501 of file MulticomponentThermo.C.

References p, and Foam::T().

Here is the call graph for this function:

◆ kappai() [2/2]

Foam::tmp< Foam::volScalarField > kappai	(	const label	speciei,
		const volScalarField &	p,
		const volScalarField &	T
	)		const

virtual

Thermal conductivity [W/m/K].

Definition at line 514 of file MulticomponentThermo.C.

References Foam::dimThermalConductivity, Foam::constant::electromagnetic::kappa, p, and Foam::T().

Here is the call graph for this function:

◆ volScalarFieldPropertyi() [2/2]

Foam::tmp<Foam::volScalarField> volScalarFieldPropertyi	(	const word &	psiName,
		const dimensionSet &	psiDim,
		Method	psiMethod,
		const label	speciei,
		const Args &...	args
	)		const

Definition at line 34 of file MulticomponentThermo.C.

References args, forAll, Foam::compressible::New(), patchi, psi, tmp< T >::ref(), and thermo.

Here is the call graph for this function:

◆ volInternalScalarFieldPropertyi() [2/2]

Foam::tmp<Foam::volScalarField::Internal> volInternalScalarFieldPropertyi	(	const word &	psiName,
		const dimensionSet &	psiDim,
		Method	psiMethod,
		const label	speciei,
		const Args &...	args
	)		const

Definition at line 84 of file MulticomponentThermo.C.

References args, forAll, Foam::compressible::New(), psi, tmp< T >::ref(), and thermo.

Here is the call graph for this function:

◆ scalarFieldPropertyi() [2/2]

Foam::tmp<Foam::scalarField> scalarFieldPropertyi	(	Method	psiMethod,
		const label	speciei,
		const Arg &	arg,
		const Args &...	args
	)		const

Definition at line 120 of file MulticomponentThermo.C.

References args, forAll, psi, tmp< T >::ref(), scalarField(), and thermo.

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/thermophysicalModels/multicomponentThermo/multicomponentThermo/MulticomponentThermo.H
src/thermophysicalModels/multicomponentThermo/multicomponentThermo/MulticomponentThermo.C

Public Member Functions

Protected Member Functions

Detailed Description

template<class BaseThermo> class Foam::MulticomponentThermo< BaseThermo >

Constructor & Destructor Documentation

◆ MulticomponentThermo() [1/2]

◆ MulticomponentThermo() [2/2]

◆ ~MulticomponentThermo()

Member Function Documentation

◆ volScalarFieldPropertyi() [1/2]

◆ volInternalScalarFieldPropertyi() [1/2]

◆ scalarFieldPropertyi() [1/2]

◆ WiValue()

◆ Wi()

◆ rhoi() [1/2]

◆ rhoi() [2/2]

◆ Cpi() [1/2]

◆ Cpi() [2/2]

◆ hei() [1/4]

◆ hei() [2/4]

◆ hei() [3/4]

◆ hei() [4/4]

◆ hsi() [1/4]

◆ hsi() [2/4]

◆ hsi() [3/4]

◆ hsi() [4/4]

◆ hai() [1/4]

◆ hai() [2/4]

◆ hai() [3/4]

◆ hai() [4/4]

◆ hfiValue()

◆ hfi()

◆ kappai() [1/2]

◆ kappai() [2/2]

◆ volScalarFieldPropertyi() [2/2]

◆ volInternalScalarFieldPropertyi() [2/2]

◆ scalarFieldPropertyi() [2/2]

template<class BaseThermo>
class Foam::MulticomponentThermo< BaseThermo >
