MRFslipFvPatchVectorField Class Reference

Rotating wall-velocity condition to be used for a slip-wall rotating with the moving frame in an MRF (multi-reference frame) or SRF (single reference frame) case. More...

Inheritance diagram for MRFslipFvPatchVectorField:

Collaboration diagram for MRFslipFvPatchVectorField:

Public Member Functions
	TypeName ("MRFslip")
	Runtime type information. More...
	MRFslipFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &, const dictionary &)
	Construct from patch, internal field and dictionary. More...
	MRFslipFvPatchVectorField (const MRFslipFvPatchVectorField &, const fvPatch &, const DimensionedField< vector, volMesh > &, const fieldMapper &)
	Construct by mapping given MRFslipFvPatchVectorField. More...
	MRFslipFvPatchVectorField (const MRFslipFvPatchVectorField &)=delete
	Disallow copy without setting internal field reference. More...
	MRFslipFvPatchVectorField (const MRFslipFvPatchVectorField &, const DimensionedField< vector, volMesh > &)
	Copy constructor setting internal field reference. More...
virtual tmp< fvPatchVectorField >	clone (const DimensionedField< vector, volMesh > &iF) const
	Construct and return a clone setting internal field reference. More...
virtual void	updateCoeffs ()
	Update the coefficients associated with the patch field. More...
virtual void	write (Ostream &) const
	Write. More...
Public Member Functions inherited from MRFPatchField
	MRFPatchField ()
	Construct null. More...
	MRFPatchField (const dictionary &)
	Construct from dictionary. More...
const MRFZone &	MRFzone (const objectRegistry &obr) const
void	makeAbsolute (fvPatchField< vector > &Up) const
void	makeRelative (fvPatchField< vector > &Up) const
void	write (Ostream &) const

Detailed Description

Rotating wall-velocity condition to be used for a slip-wall rotating with the moving frame in an MRF (multi-reference frame) or SRF (single reference frame) case.

SRF cases are simply MRF cases with a single MRF zone which covers the entire domain.

Usage

Example of the boundary condition specification for an SRF case or MRF case with a single zone:

<patchName>
{
    type            MRFslip;
}

or if the case has several MRF zones the particular zone this patch is in must be named explicitly, e.g.:

<patchName>
{
    type            MRFslip;
    MRFZoneName     rotor;
}

See also

Foam::MRFPatchField Foam::MRFZone

Source files

• MRFslipFvPatchVectorField.H
• MRFslipFvPatchVectorField.C

Definition at line 77 of file MRFslipFvPatchVectorField.H.

Constructor & Destructor Documentation

MRFslipFvPatchVectorField() [1/4]

MRFslipFvPatchVectorField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const dictionary &	dict
	)

Construct from patch, internal field and dictionary.

Definition at line 32 of file MRFslipFvPatchVectorField.C.

References dict, DimensionedField< Type, GeoMesh, PrimitiveField >::dimensions(), fvPatchField< Type >::operator=(), p, and Foam::Zero.

Referenced by MRFslipFvPatchVectorField::clone().

Here is the call graph for this function:

Here is the caller graph for this function:

MRFslipFvPatchVectorField() [2/4]

MRFslipFvPatchVectorField	(	const MRFslipFvPatchVectorField &	pvf,
		const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const fieldMapper &	mapper
	)

Construct by mapping given MRFslipFvPatchVectorField.

onto a new patch

Definition at line 56 of file MRFslipFvPatchVectorField.C.

MRFslipFvPatchVectorField() [3/4]

MRFslipFvPatchVectorField ( const MRFslipFvPatchVectorField &  )

delete

Disallow copy without setting internal field reference.

MRFslipFvPatchVectorField() [4/4]

MRFslipFvPatchVectorField	(	const MRFslipFvPatchVectorField &	pvf,
		const DimensionedField< vector, volMesh > &	iF
	)

Copy constructor setting internal field reference.

Definition at line 69 of file MRFslipFvPatchVectorField.C.

Member Function Documentation

TypeName()

TypeName

(

"MRFslip"

)

Runtime type information.

clone()

virtual tmp<fvPatchVectorField> clone ( const DimensionedField< vector, volMesh > &  iF ) const

inlinevirtual

Construct and return a clone setting internal field reference.

Definition at line 123 of file MRFslipFvPatchVectorField.H.

References MRFslipFvPatchVectorField::MRFslipFvPatchVectorField().

Here is the call graph for this function:

updateCoeffs()

void updateCoeffs ( )

virtual

Update the coefficients associated with the patch field.

Definition at line 82 of file MRFslipFvPatchVectorField.C.

References Foam::I, Foam::fvc::makeAbsolute(), Foam::fvc::makeRelative(), Field< vector >::operator=(), Foam::sqr(), and Foam::transform().

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Write.

Definition at line 107 of file MRFslipFvPatchVectorField.C.

References MRFPatchField::write(), fvPatchField< Type >::write(), and Foam::writeEntry().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/finiteVolume/cfdTools/general/MRF/derivedFvPatchFields/MRFslip/MRFslipFvPatchVectorField.H
• src/finiteVolume/cfdTools/general/MRF/derivedFvPatchFields/MRFslip/MRFslipFvPatchVectorField.C
